Removal of Outdoor Fan / Fan Motor
2. Removal of Outdoor Fan / Fan Motor
Procedure
Step
Pull out the 2 terminals
1
[A1] [B1] from the fan
capacitor (C12R).
2
Pull out the terminal [5]
from the magnetic
contactor (K1M).
Release the fan motor
3
lead wire from the hook.
Remove the screw of
4
the fan motor fixing
plate.
5
Remove the fan motor
fixing plate.
4
Warning
Be sure to wait for 10 minutes or more after turning off all power
supplies before disassembling work.
Procedure
Fan capacitor
Fan motor lead wire
Fan motor
fixing plate
Fan capacitor (C12R)
Magnetic contactor
Magnetic contactor (K1M)
(R15157)
(R15158)
Be careful so as not to
damage the top part of the
outdoor heat exchanger fins.
Put the lead wire through the
back of the motor when
reassembling so as not to be
entangled with the outdoor
fan.
(R15159)
Lead wire
Si011193
Points
to fan motor
(red)
B1 B2
A1 A2
to fan motor
(R15394)
(white)
A2
14
6
4
2
A1
13
5
3
1
to fan motor
(black)
(R15395)
Outdoor fan
(R3249)
Removal Procedure
