Configuring the Unit
The NetVanta may be initially accessed and managed either via a console session or
through a Telnet session. See step 1a for console session instructions. Initiating a Tel-
net session requires using a hub and two Ethernet cables (one for the PC and one for
the unit). The default Ethernet IP address is 10.10.10.1. Refer to step 9 to change Tel-
net session settings.
1a
Initiating a Console Session
1. Connect a VT100 terminal (or PC with VT100 emulation software) to the NetVanta
CONSOLE port using a DB-9 (male) to DB-9 (female) straight-through serial cable.
2. Configure the COM port with the following parameters:
Data Rate:
Data Bits:
Parity Bits:
Stop Bits:
Flow Control:
3. Open a VT100 terminal session. (Please refer to the appropriate VT100 terminal
software documentation for detailed instructions.)
4. Press the <Enter> key.
5. Enter enable at the > prompt.
6. Enter the password when prompted. The default password is password. You are
now at the # prompt. At the # prompt, enter config terminal to enter the global
configuration mode.
The configuration parameters used in the example outlined in this document are for
instructional purposes only. Please replace all underlined entries (example) with your
specific parameters to configure your application
2
9600
8
None
1
None
Technical Support 1-888-4ADTRAN (1-888-423-8726)
64200866L1-42A
