ADTRAN NETVANTA OCTAL POE Quick Start

N V O
ET ANTA
P/N 4200825G1#120, 4200825G1#240
G S
ETTING TARTED
The NetVanta Power over Ethernet (PoE) Upgrade provides the ability to detect attached
powered devices (PDs) and deliver 48 VDC to the PDs via existing CAT 5 cabling. The NetVanta
PoE Upgrade bundle is shipped with the Octal PoE module, two standoffs, the PoE power supply,
and appropriate power cords.
I
NSTALLING THE
1. Remove power and all connecting cables from the unit.
2. Remove any installed network interface modules (NIMs), the screws holding the base unit
and the cover together, the two jack screws from the back panel (if necessary), and the two
mounting brackets (if necessary).
3. Carefully lift and remove the unit's cover to expose the main circuit board.
4. Remove and retain the two PC board mounting screws (highlighted in
5. Thread and secure the two standoffs (supplied with the Octal PoE module) into the two
holes from which you removed the PC board mounting screws (see
6. Carefully align the 34-pin receptacle on the Octal PoE module with the 34-pin header
located on the circuit board. Applying even pressure, press the module until it is well seated.
7. Align the holes in the standoffs with the holes in the Octal PoE module. Attach the module to
the standoffs using the two previously removed PC board mounting screws.
8. Replace the unit cover, screws, mounting brackets, NIMs, and all connecting cables.
9. If wall mounting the power supply, skip to steps given in
Supply (Optional).
10. Restore power to the unit following the instructions in
Switchports.
Installation of the NetVanta Octal PoE module is not required on factory-
installed upgrades.
The NetVanta Octal PoE module is intended to be installed only by
qualified service personnel.
Quick Start Guide, 61200825G1-13A, February 2011
P E U
CTAL O
O P E M
CTAL O
PGRADE
ODULE
Wall Mounting the PoE Power
Powering the NetVanta and PoE
Figure 1).
Figure 1).
