Logon Screen - ADC HiGain H2TU-C-231 Manual

Provisioning
Monitor Performance
ID: xxxx--xxxx--xxxx—-xxxx
Circuit ID
Press this key: To access this menu:
Monitor
M
Performance
P
Event Log
E
Config
C
Inventory
I
Report
O
Rlogon / Rlogout
R
Help
H
12
Menu bar
Event Log Config
+------------------------------------------+
|
| ADC DSL Systems, Inc.
| HiGain HDSL2
|
| Voice: 800.638.0031
| Fax : 714.832.9924
+------------------------------------------+
09/01/2001 12:30:01
Date and Time
Figure 3. Logon Screen
Table 4. Logon Screen Menus
Menu Functions
Monitors loopbacks and alarms, and provides a graphical representation of circuit
activity, including ES, UAS, SES, and line code.
Provides performance and alarm histories for current, 25-hour, 48-hour, or 31-day
periods for either the DS1 or HDSL2 interface.
Identifies the 100 most recent system events and reports the origin, date and time of
occurrence, and message.
Provides standard configuration options, ADC options, date and time setting, and a reset
option (factory settings). Also provides a master clear option that clears all performance,
alarm, and event log entries.
Provides product information about the various devices that are in the system and lists
circuit and device identifications.
Provides four types of reports: Full Report, Short Report, System Information Report,
and Event Report.
Remote log on can be performed from the H2TU-C or H2TU-R. The screen displays
"Rlogout" when the H2TU-C or H2TU-R is remotely logged on to the other unit at the end
of the circuit.
To log off the remote unit, press
locally logged on until
Provides a glossary of terms used in the maintenance screens, a list of navigational keys,
print guide, and ADC contact information.
September 28, 2001
Inventory Report Rlogon
|
|
|
|
|
|
H2TU-C
Logon Device
R . "Rlogout" changes to "Rlogon". The unit is now
R is pressed again to reinitiate the remote log on.
LTPH-TP-1034-01, Issue 1
Help
System: OK___
System Status
H2TU-C-231 List 4E
