SCP-AMU912-010-06H
S/W DNLD— Start a Download (Continued)
Step
4
A message is displayed that informs you the system is ready and the applicable steps to follow to
continue the software download.
5
Instruct the terminal emulator to begin an XMODEM download.
The file to be downloaded from the terminal to the AMU-912 has a .DWN extension and a prefix that
identifies the card to which it should be downloaded. For example, if a AMU-912 was the target card, the
file name would be similar to AMUAPPL.DWN, indicating that AMU-912 Application Code is to be
transferred. Most terminal emulators indicate the progress of the download until completion. The AMU-
912 provides a visual indication of download activity from the terminal to the AMU-912 by alternately
blinking each of the front panel LEDs, except for the PWR LED.
Do not interrupt the download process, unplug the system units or the cable connecting the
VT-100 terminal to the system unit.
Upon completion, the AMU-912 displays a message of success or failure of the download. If the
download failed, see
104
Download Retry on page 106
Action
and
Table 35 on page 108
July 19, 2004
for further instructions.
ADC Telecommunications, Inc.
