Clarion Co., Ltd.

2001/1 (D

•

Printed in China /

Imprimé en Chine

/ Impreso en China

Contents

English

1. PRECAUTIONS...........................................................2

2. CONTROLS.................................................................3

3. BUTTON TERMINOLOGY ..........................................4

4. FEATURES..................................................................5

5. HANDLING COMPACT DISCS...................................6

6. DCP .............................................................................7

7. REMOTE CONTROLL ................................................8

8. OPERATION..............................................................10

9. TROUBLESHOOTING ..............................................14

10.ERROR DISPLAYS ...................................................15

11.SPECIFICATIONS.....................................................16

Table des matières

Français

1. PRÉCAUTIONS.........................................................17

2. COMMANDES.............................................................3

3. NOMENCLATURE DES TOUCHES .........................18

4. CARACTÉRISTIQUES..............................................19

5. MANIPULATION DES DISQUES COMPACTS ........20

6. CLAVIER DE COMMANDE AMOVIBLE (DCP) .......21

7. TÉLÉCOMMANDE....................................................22

8. FONCTIONNEMENT.................................................24

9. DÉPISTAGE DES PANNES ......................................29

10.AFFICHAGE DES ERREURS...................................30

11.SPÉCIFICATIONS.....................................................31

Índice

Español

1. PRECAUCIONES......................................................33

2. CONTROLES ..............................................................3

3. NOMENCLATURA DE LOS BOTONES ...................34

4. CARACTERÍSTICAS ................................................35

5. MANEJO DE LOS DISCOS COMPACTOS ..............36

6. PANEL DE CONTROL DESMONTABLE (DCP) ......37

7. CONTROLADOR REMOTO......................................38

8. OPERACIÓN .............................................................40

9. SOLUCIÓN DE PROBLEMAS..................................45

10.INDICACIONES DE ERROR ....................................46

11.ESPECIFICACIONES ...............................................47

PE-2389B

280-7597-00

1. PRECAUTIONS

Owner's manual

Mode d'emploi

1. When the inside of the car is very cold and

Manual de instrucciones

the player is used soon after switching on

the heater, moisture may form on the disc

or the optical parts of the player and proper

playback may not be possible. If moisture

forms on the disc, wipe it off with a soft

cloth. If moisture forms on the optical parts

of the player, do not use the player for about

one hour and the condensation will disap-

pear naturally to allow normal operation.

2. Driving on extremely bumpy roads which

cause severe vibration may cause the

sound to skip.

3. This unit uses a precision mechanism.

Even in the event that trouble arises, never

open the case, disassemble the unit, or

lubricate the rotating parts.

DB415

USE OF CONTROLS, ADJUSTMENTS, OR PERFORMANCE OF PROCEDURES OTHER THAN

THOSE SPECIFIED HEREIN, MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

AM/FM CD PLAYER

THE COMPACT DISC PLAYER SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE

•

EXCEPT PROPERLY QUALIFIED SERVICE PERSONNEL.

RADIO AM/FM-LECTEUR CD

•

RADIO AM/FM Y REPRODUCTOR CD

Bottom View of Source Unit

INFORMATION FOR USERS:

CHANGES OR MODIFICATIONS TO THIS PRODUCT WILL VOID THE WARRANTY AND WILL

VIOLATE FCC APPROVAL.

This equipment has been tested and found to

comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reason-

able protection against harmful interference in

a residential installation. This equipment gen-

erates, uses, and can radiate radio frequency

energy and, if not installed and used in accor-

dance with the instructions, may cause harmful

interference

radio

communications.

However, there is no guarantee that interfer-

ence will not occur in a particular installation. If

this equipment does cause harmful interfer-

ence to radio or television reception, which can

be determined by turning the equipment off

and on, the user is encouraged to consult the

dealer or an experienced radio/TV technician

for help.

CAUTION

DRX5675

MODEL

12V

GROUND

AM 530-1710kHz/FM 87.9-107.9MHz

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.

OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,

INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED

OPERATION.

THIS PRODUCTION COMPLIES WITH DHHS RULES 21 CFR

SUBCHAPTER J APPLICABLE AT DATE OF MANUFACTURE.

CLARION CO.,LTD.

50 KAMITODA,TODA-SHI,SAITAMA-KEN,JAPAN

051 722 877

MANUFACTURED:

286- 324-00

SERIAL No.

Clarion Co.,Ltd.

MADE IN CHINA

PE-2310B

Be sure to unfold and read the next page.

Veuillez déployer et vous référer à la page suivante.

Cerciórese de desplegar y de leer la página siguiente.

DB415

Table of Contents

Summary of Contents for Clarion DB415

Page 1 Clarion Co., Ltd. PE-2389B All Rights Reserved. Copyright © 2001: Clarion Co., Ltd. 280-7597-00 2001/1 (D • Printed in China / Imprimé en Chine / Impreso en China Owner’s manual Mode d’emploi Manual de instrucciones Contents English 1. PRECAUTIONS...2 2. CONTROLS...3 3.
Page 2: Button Terminology
Remarque: Veuillez déplier cette page et vous référer aux schémas quand vous lisez chaque chapitre. Nota: Cuando lea los capítulos, despliegue esta página y consulte los diagramas. DB415 3. BUTTON TERMINOLOGY Note: • Be sure to read this chapter referring to the front diagrams of chapter 2. CONTROLS on page 3 (unfold).
Page 3: Flip Down Panel
4. When closing the FLIP DOWN PANEL, do not press the Open button 1. 5. Strong impacts to the operating or display section can cause damage or deformation. 6. If the flip down panel does not open fully, gently open it with your hand. DB415...
Page 4: Handling Compact Discs
Do not use commercially available CD protection sheets or discs equipped with stabilizers, etc. These • may get caught in the internal mechanism and damage the disc. DB415 Note on Compact Discs mark. Never stick labels on the surface of the compact disc or mark the surface with a pencil or pen.
Page 5 • The connector connecting the unit and the DCP is an extremely important part. Be careful not to damage it by pressing on it with fingernails, screwdrivers, etc. Note: • If the DCP is dirty, wipe off the dirt with a soft, dry cloth only. DB415...
Page 6: Remote Control
• Do not short-circuit, disassemble or heat batteries. • Do not dispose of batteries into fire or flames. • Dispose of spent batteries properly. DB415 Receiver for remote control unit Operating range: 30 in all directions Signal transmitter ¡ ¢...
Page 7: Functions Of Remote Control Unit Buttons
* Some of the corresponding buttons on the source unit and remote control unit have different functions. Radio Plays the first track. Top play. Moves tracks up and down. When pressed and held for 1 second: Fast-forward/ fast-backward. Switches between playback and pause. Switches between playback and pause. Scan play. Repeat play. Random play. DB415...
Page 8: Basic Operations
–6 to +6) 3) When the adjustment is complete, press A-M button 2 several times until the function mode is reached. DB415 Adjusting the Treble 1) Press A-M button 2 and select “TREB”. 2) Turning the Rotary knob # clockwise empha- sizes the treble;...
Page 9: Radio Mode Operations
BND button ! for 1 second or longer. When the “MANU” display is off, the Seek Selection function is on. 3) Press the SRCH Left/Right button @, then when it selects the station in which there is a broadcast, it automatically stops. ® DB415...
Page 10 1) Press the FNC button 3, then select the radio mode. 2) Select the radio station which you want to store in the memory. DB415 3) Press and hold the ISR button 4 for 2 sec- onds or longer. Recalling ISR Press the ISR button 4 then the display will show “ISR”, then the radio station previously...
Page 11: Cd Mode Operations
: To fast-backward Pressing the SRCH Left/Right button for 1 second or longer will move forward or backward 5 times faster than normal play, and pressing it for 3 seconds or longer will do the operation 30 times faster. DB415...
Page 12: Repeat Play
DB415 Repeat Play Press the RPT button 7, then the display shows “RPT”, then the track currently playing will be played repeatedly. Press the RPT button 7 again to disengage the unit from repeat play.
Page 13: Error Displays
A CD is loaded upside-down inside the CD deck and does not play. Measure This is a failure of CD deck’s mechanism and consult your store of purchase. Replace with a non-scratched, non-warped disc. Eject the disc then reload it properly. DB415...
Page 14: Specifications
± Bass Control Action (30 Hz): Treble Control Action (10 kHz): Line Output (with CD 1 kHz, 10 k ): 1.8 V DB415 General Power Supply Voltage: 14.4 V DC (10.8 V to 15.6 V allowable), negative ground Current Consumption: Less than 15 A Speaker Impedance: 4 Ω...
