6. Box Field

Intermec EasyCoder 301 Direct Protocol 2.0 – Programmer's Guide Ed. 3
A box is a hollow square or rectangle that can be rotated with an
increment of 90 according to the print direction. If the line thick-
ness is sufficiently large, the box will appear to be filled (another
method is to print an extremely thick short line).
In addition to the general formatting commands, PRPOS, ALIGN
and DIR, a box field is specified by a single command.
Set Size of the Box
The size of the box is specified with regard to height, width and line
weight (thickness).
PRBOX | PX <height>,<width>,<line thickness>
<height>
<width>
<line thickness>
Default:
Summary
To create a box field, the following formatting commands must be
given (in most cases, default values may substitute missing para-
meters). Printing commands are explained in chapter 5.2.
Purpose Command
X/Y Position PRPOS | PP
Alignment ALIGN | AN
Direction DIR
Box size PRBOX | PX
Example:
PP 250,250:AN 1:DIR 3:PX 200,200,10
Chapter 4
the height of the box in dots perpendicular to
the selected direction.
the length of the box in dots along the se-
lected direction.
the line weight in dots.
None
Default
0,0
1
1
n.a.
Label Design
Remarks
Number of dots
Select ALIGN 1 – 9
Select DIR 1 – 4
Height, width and line
thickness in dots
30
