Summary of Contents for Fisher & Paykel EB76PSX1
- Page 1 BUILT-IN COFFEE MAKER PROFESSIONAL EB76PSX1 models INSTALLATION GUIDE NZ AU...
-
Page 3: Important Safety Instructions
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! If the power socket does not match the plug on the appliance, have the socket replaced ● with a suitable type by a qualified professional. To comply with safety directives, an omnipolar switch with a minimum contact distance of 3 mm must be installed. Do not use multiple sockets or extensions. -
Page 4: During Installation
INSTALLATION CONSIDERATIONS COMPONENTS REQUIRED PRIOR TO INSTALLATION PARTS SUPPLIED Prior to installing your coffee maker, ensure the following: Keep all packing materials until the unit has been inspected. Inspect the product to ensure there is no shipping damage. If any damage is detected The countertop and coffee maker cavity are square and level, and are the contact the dealer or retailer you bought the product from to report the damage. -
Page 5: Product Dimensions
PRODUCT DIMENSIONS EB76 MODELS PRODUCT DIMENSIONS A Overall height B Overall width PLAN ISOMETRIC C Overall depth D Height of chassis E Width of chassis F Depth of chassis G Depth of coffee maker frame and control panel H Height of stepdown from top of control panel to top of chassis I Height of stepdown from bottom of chassis to bottom of lower trim... -
Page 6: Cavity Dimensions
CABINETRY DIMENSIONS (FLUSH INSTALL) Ventilation of 50x560mm or totalling 280cm is required for companion products. The air vent must be located at the rear of cabinet, it can be positioned at the base, top, sides, or back of the cavity. Additional sidewalls for securing coffee maker Additional... - Page 7 CABINETRY DIMENSIONS (PROUD INSTALL) Ventilation of 50x560mm or totalling 280cm is required for companion products. The air vent must be located at the rear of cabinet, it can be positioned at the base, top, sides, or back of the cavity. Additional sidewalls for securing coffee maker Additional...
-
Page 8: Electrical Connection
ELECTRICAL CONNECTION ATTACH THE TRIM TO THE COFFEE MAKER Before placing the coffee maker into the cavity: Before installing the coffee maker in the cabinetry, the side trims and lower trim need to be attached. Route the power cord into the back of the cavity and plug it in to the switched socket. The switched socket should be in an easily accessible area within 900mm of the centre rear of the product. - Page 9 SECURE THE COFFEE MAKER TO THE CABINETRY Position the rails on the sides of If necessary, correct alignment of the cabinet. min 560mm the appliance by positioning the Fix with the screws provided, spacers supplied under or at the then extract them completely. sides of the support.
-
Page 10: Installer Checklist
INSTALLER CHECKLIST TO BE COMPLETED BY THE INSTALLER … … Make sure the coffee maker is level and securely fitted to the cabinetry. Turn the power to the coffee maker on. The display should turn on. … … Check the lower trim is undamaged. Fill the water tank to the indicated level. - Page 12 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2021. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
