- Page 1 COMPANION PRODUCTS Coffee Maker EB60 Steam Oven OS60 Microwave Oven OM60 models INSTALLATION GUIDE NZ AU GB IE 591587E 11.19...
-
Page 2: Table Of Contents
CONTENTS Coffee maker Steam oven Microwave oven Safety and warnings Safety and warnings Safety and warnings Parts supplied Prior to installation Prior to installation Prior to installation After installation After installation After installation Product dimensions Product dimensions Product dimensions 5A Cabinetry dimensions (460mm high cavity) 5A Cabinetry dimensions (460mm high cavity) 6A Cabinetry dimensions (460mm high cavity) 5B Cabinetry dimensions (480mm cavity trim kit) -
Page 3: Coffee Maker
COFFEE MAKER EB60 models 560.00 20.25... -
Page 4: Safety And Warnings
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! Installation WARNING! Cut Hazard Take care – some edges are sharp. Failure to use caution could result in injury or cuts. Checking for transport damage After removing the packaging, make sure the product is complete and undamaged and that all accessories are present. -
Page 5: Parts Supplied
PARTS SUPPLIED Screws Rails (2) Clip (1) (28) Spacers (4) for side (4) for bottom PRIOR TO INSTALLATION The countertop and coffee maker cavity are square and level, and are the required dimensions. ● ● The installation will comply with all clearance requirements and applicable standards and regulations. 560.00 ●... -
Page 6: Product Dimensions
PRODUCT DIMENSIONS SIDE EB60 MODELS PRODUCT DIMENSIONS Overall height of product Overall width of product Overall depth of product Height of chassis Width of chassis Depth of chassis Depth of coffee maker frame and control panel FRONT Stepdown control panel to chassis Height of control panel 4 | ... -
Page 7: Cabinetry Dimensions (460Mm High Cavity)
CABINETRY DIMENSIONS (460mm HIGH CAVITY) Verify the minimum measurements required for correct installation of the appliance. The coffee maker must be installed in a column and the column must be firmly fixed to the wall with commercially available brackets. IMPORTANT! PROUD INSTALL All installation or maintenance operations must be performed with the appliance disconnected ●... -
Page 8: Cabinetry Dimensions (480Mm Cavity Trim Kit)
CABINETRY DIMENSIONS (480mm CAVITY TRIM KIT) Verify the minimum measurements required for correct installation of the appliance. The coffee maker must be installed in a column and the column must be firmly fixed to the wall with commercially available brackets. IMPORTANT! All installation or maintenance operations must be performed with the appliance disconnected ●... -
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS (2mm) approx. 350mm Position the rails on the sides of the cabinet. Fix with the screws provided, then extract Fix the power cable with the clip. The power cable must be long enough to allow them completely. the appliance to be pulled out from the cabinet to fill the coffee bean container. If the coffee maker is installed over a warmer drawer, use the top surface of this as The appliance must be earthed in compliance with legislation. -
Page 10: Connect The Warming Drawer To The Mains Supply
CONNECT THE WARMING DRAWER TO THE MAINS SUPPLY IMPORTANT! All electrical work may only be carried out by suitably qualified and competent persons in accordance with national and ● ● local safety regulations. This warming drawer must be earthed. ● ●... -
Page 11: Final Checklist
FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Make sure the coffee maker is level and securely fitted to the cabinetry. Check the lower trim is undamaged. Check there is adequate clearance. This is to ensure correct air circulation. Make sure any cable ties and internal packaging has been removed from the coffee maker cavity. Make sure all coffee maker vents and openings are clear and free of any obstruction or damage. -
Page 12: Steam Oven
STEAM OVEN OS60 models 556.00 565.30 22.00... -
Page 13: Safety And Warnings
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! Installation WARNING! To avoid hazard, follow these instructions carefully before installing or using this appliance. Electrical Shock Hazard Before carrying out any work on the electrical section of the appliance, Save these instructions for the local inspectors use. ●... -
Page 14: Prior To Installation
PRIOR TO INSTALLATION The countertop and oven cavity are square and level, and are the required dimensions. ● ● 560.00 The installation will comply with all clearance requirements and applicable standards and regulations. ● ● The isolating switch will be easily accessible to the customer with the oven installed. ●... -
Page 15: Product Dimensions
PRODUCT DIMENSIONS SIDE OS60 MODELS PRODUCT DIMENSIONS Overall height of product Overall width of product Overall depth of product (excluding handle and dials) Height of chassis Width of chassis Depth of chassis Depth of oven frame and control panel FRONT (=distance between front of chassis and front of oven door, excl. -
Page 16: Cabinetry Dimensions (460Mm High Cavity)
CABINETRY DIMENSIONS (460mm HIGH CAVITY) The oven can be installed under a cooktop, in a column. ● ● The cabinet material must be able to withstand heat. ● ● The oven must be centered within the walls of the cabinet and fixed with the screws and bushings that are provided. ●... -
Page 17: Cabinetry Dimensions (480Mm Cavity Trim Kit)
CABINETRY DIMENSIONS (480mm CAVITY TRIM KIT) The oven must be installed under a cook top, in a column. ● ● The cabinet material must be able to withstand heat. ● ● The oven must be centered within the walls of the cabinet and fixed with the screws and bushings that are provided. ●... -
Page 18: Electrical Hook-Up
ELECTRICAL HOOK-UP Before connecting to the electricity, make sure that the: specifications of the electrical system match with what is detailed on the serial number plate applied to the front of the oven. ● ● system has an effective earth connection compliant with current standards and laws. ●... -
Page 19: Final Checklist
FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Make sure the oven is level and securely fitted to the cabinetry. Check the lower trim is undamaged. Open the (lower) oven door slowly until it is fully open and check there is adequate clearance between the bottom of the door and the lower trim. This is to ensure correct air circulation. -
Page 20: Microwave Oven
MICROWAVE OVEN OM60 models 556.00 565.30 22.00... -
Page 21: Safety And Warnings
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! Installation WARNING! To avoid hazard, follow these instructions carefully before installing or using this appliance. Electrical Shock Hazard Before carrying out any work on the electrical section of the appliance, Save these instructions for the local inspectors use. ●... -
Page 22: Prior To Installation
PRIOR TO INSTALLATION The countertop and oven cavity are square and level, and are the required dimensions. ● ● 560.00 The installation will comply with all clearance requirements and applicable standards and regulations. ● ● The isolating switch will be easily accessible to the customer with the oven installed. ●... -
Page 23: Product Dimensions
PRODUCT DIMENSIONS SIDE OM60 MODELS PRODUCT DIMENSIONS Overall height of product Overall width of product Overall depth of product (excluding handle and dials) Height of chassis Width of chassis Depth of chassis Depth of oven frame and control panel FRONT (=distance between front of chassis and front of oven door, excl. -
Page 24: Cabinetry Dimensions (460Mm High Cavity)
CABINETRY DIMENSIONS (460mm HIGH CAVITY) The oven can be installed under a cooktop, in a column ● ● The cabinet material must be able to withstand heat. ● ● The oven must be centered within the walls of the cabinet and fixed with the screws and bushings that are provided. ●... -
Page 25: Cabinetry Dimensions (480Mm Cavity Trim Kit)
CABINETRY DIMENSIONS (480mm CAVITY TRIM KIT) The oven must be installed under a cook top, in a column. ● ● The cabinet material must be able to withstand heat. ● ● The oven must be centered within the walls of the cabinet and fixed with the screws and bushings that are provided. ●... -
Page 26: Electrical Hook-Up
ELECTRICAL HOOK-UP Before connecting to the electricity, make sure that the: specifications of the electrical system match with what is detailed on the serial number plate applied to the front of the oven. ● ● system has an effective earth connection compliant with current standards and laws. ●... -
Page 27: Final Checklist
FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Make sure the oven is level and securely fitted to the cabinetry. Check the lower trim is undamaged. Open the oven door (lower) slowly until it is fully open and check there is adequate clearance between the bottom of the door and the lower trim. This is to ensure correct air circulation. - Page 28 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2019. All rights reserved. The product specifications in this document apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time.
