Summary of Contents for Fisher & Paykel EB24MSB1
- Page 1 COFFEE MAKER EB24MSB1 & EB24DSX1 models INSTALLATION GUIDE US CA...
-
Page 3: Table Of Contents
CONTENTS Safety and warnings Parts supplied Prior to installation After installation Product dimensions Cabinetry dimensions (18 1/8" (460mm) high cavity) Installation instructions Final checklist... -
Page 4: Safety And Warnings
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! To protect against fire, electric shock and injury to persons do not submerge the cord or ● plugs in water or other liquids. To reduce the risk of injury, do not drape cord over the counter top or table top where it ●... -
Page 5: Parts Supplied
PARTS SUPPLIED Screws Rails (2) Clip (1) (28) Spacers (4) for side (4) for bottom PRIOR TO INSTALLATION The countertop and coffee maker cavity are square and level, and are the required dimensions. ● The installation will comply with all clearance requirements and applicable standards and regulations. ●... -
Page 6: Product Dimensions
PRODUCT DIMENSIONS SIDE EB24 MODELS PRODUCT DIMENSIONS inches (mm) Overall height of product 18" (458) Overall width of product 23 1/2" (596) Overall depth of product ( 18 7/8" (480) excluding dials) Height of chassis 17 1/2" (445) Width of chassis 22 1/16"... -
Page 7: Cabinetry Dimensions (18 1/8" (460Mm) High Cavity)
CABINETRY DIMENSIONS (18 1/8" (460mm) HIGH CAVITY) Verify the minimum measurements required for correct installation of the appliance. The coffee maker must be installed in a column and the column must be firmly fixed to the wall with commercially available brackets. IMPORTANT! 5/8–13/16"... -
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS If required, the alignment of the coffee maker can be adjusted by placing the Align the rails to the sides of the cabinet before securing using the provided screws. supplied spacers either under or to the sides of the rails. Extending both rails fully. -
Page 9: Final Checklist
FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Make sure the coffee maker is level and securely fitted to the cabinetry. Check the lower trim is undamaged. Check there is adequate clearance. This is to ensure correct air circulation. Make sure any cable ties and internal packaging has been removed from the coffee maker cavity. Make sure all coffee maker vents and openings are clear and free of any obstruction or damage. - Page 10 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2022. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
