565 Filter
-Taste and Odor (TO)
- Multimedia (MM)
- nextSand
- Neutralizer (NU)
- Birm (BM)
1. Read all instructions carefully before operation.
2. Avoid pinched o-rings during installation by applying (providedwith install kit) NSF certified lubricant to all seals.
3. This system is not intended for treating water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after
the system.
Canada West
855 Park St., Unit 1
7503 35th St. SE
Regina, SK S4N 6M1
Calgary, AB T2C 1V3
Canada East
U.S.A.
490 Pinebush Rd., Unit 1
7229 University Avenue, NE
Cambridge, ON N1T 0A5
Fridley, MN 55432
56 Lightcap Road
Pottstown, PA 19464
9760 Mayflower Park Drive
4655 McDowell Rd. W
Suite 110
Phoenix, AZ 85035
Carmel, IN 46032
Advertisement
Table of Contents
Related Manuals for Canature WaterGroup HT 565BM-75
Summary of Contents for Canature WaterGroup HT 565BM-75
- Page 1 565 Filter -Taste and Odor (TO) - Multimedia (MM) - nextSand - Neutralizer (NU) - Birm (BM) 1. Read all instructions carefully before operation. 2. Avoid pinched o-rings during installation by applying (providedwith install kit) NSF certified lubricant to all seals. 3.
-
Page 3: Table Of Contents
READ THIS MANUAL FIRST SPECIFICATION SYSTEM DIMENSIONS / BASIC PRINCIPLES UNPACKING / INSPECTION BEFORE INSTALLATION INSTALLATION INSTALLATION STEPS PREPARATIONS STARTUP INSTRUCTIONS SYSTEM CHECK LIST / DURING REGENERATION / PLUMBING SYSTEM CLEAN-UP WATER BYPASS / OPERATING CONDITIONS / MAINTENANCE INSTRUCTIONS BACKWASHING INSTRUCTIONS SERVICING 565 VALVE TIMER REPLACEMENT / PISTON ASSEMBLY REPLACEMENT METER ASSEMBLY REPLACEMENT... -
Page 4: Read This Manual First
This publication is based on information available when approved for printing. Continuing design refinement could cause changes that may not be included in this publication. Canature WaterGroup™ reserves the right to change the specifications referred to in this literature at any time, without prior notice. -
Page 5: Specification
Service Peak Backwash Working Temperature = 34-110°F (1-43°C) Iron Filters - Birm (Do not subject the unit to freezing temperatures) Working Pressure = 30-125 PSIG (137-861 kPa) HT 565BM-75 0.75 8 x 44 3/4” and 1” Voltage = 120V / 60 Hz Pipe Size = 3/4”... -
Page 6: System Dimensions / Basic Principles
SYSTEM DIMENSIONS Models A (Inches) B (Inches) C (Inches) 51.5 13" 8" 55.5 15" 9" 61.5 16" 10" BASIC PRINCIPLES The success of the installation will depend, to a great extent, on advanced planning and preparation. Careful attention to the location of the unit, accessibility to electrical and drain facilities, and the availability of the proper tools will ensure a professional-looking installation. - Page 7 BM Filter This media acts as a catalyst for the removal of iron and manganese from the water but require pre-oxidation. This media removes the iron and manganese from the water. This is not recommended to remove hydrogen sulfide from the water and requires high pH water. The media is not sacrificial hence no replenishment is required. CAUTION! Do not use where the water is microbiologically unsafe or with water of unknown quality without adequate disinfection before or after the unit.
-
Page 8: Unpacking / Inspection
UNPACKING / INSPECTION Be sure to check the entire unit for any shipping damage or parts loss. Also note damage to the shipping cartons. Contact the transportation company for all damage and loss claims. The manufacturer is not responsible for damages in transit. Small parts, needed to install the filter, are in a parts box. - Page 9 For Models2 0,30, the media and Control Valve is packaged separately in carton and bags What is included with 20,30 models? 1. Tank (Model 30 will get an Adapter and Oring attached to the tank) 2. Control Valve with Parts Box 3.
- Page 10 Check Valve Type and Valve Serial # Check to make sure Valve Type if Downflow (DF) (left Sticker shown below). The right Sticker shows the serial # of the control valve. The middle Sticker is dataplate which provides information of Serial # and Date of Manufacture of complete system. Both Serial # labels are important for troubleshooting. Complete System Serial # Valve Serial # Valve Serial #:...
-
Page 11: Before Installation
BEFORE INSTALLATION Contact your local distributor to use Canature WaterGroup™ laboratory for complete water analysis free of cost and no obligation to you. The laboratory addresses can be found on the front page of the manual. All government codes and regulations governing the installation of these devices must be observed. - Page 12 NOTE: If your pumping rate is inadequate, do not install your filter until the problem is solved. Tools Required for Installation: Two adjustable wrenches Additional tools may be required if modification to home plumbing is required. Plastic inlet and outlet fittings are included with the filter. To maintain full valve flow, 3/4” or 1” pipes to and from the filter fittings are recommended. You should maintain the same, or larger, pipe size as the water supply pipe, up to the filter inlet and outlet.
-
Page 13: Installation
INSTALLATION Proper installation sequence of water conditioning equipment is very important. Refer to the diagrams following for your particular water supply. All government codes and regulations governing the installation of these devices must be observed. CAUTION! If the ground from the electrical panel or breaker box to the water meter or underground copper pipe is tied to the copper water lines and these lines are cut during installation of the Noryl bypass valve and/or poly pipe, an approved grounding strap must be used between the two lines that have been cut in order to maintain continuity. - Page 14 Figure 1b: Birm (BM) Typical Installation: Figure 1b Cold Soft Water Hard Filtered Electrical Panel Water Hard Soft Water Ground Strap Raw Water To Outdoors Drain Drain Water Meter Softener Birm Water Heater (BM) Filter Figure 1c: Multi Media Filter (MM or nextSand) Typical Installation: Figure 1c Hard Cold Soft Water...
-
Page 15: Installation Steps
Figure 1d: Neutralizing Filter (NF) Typical Installation: Figure 1d Hard Cold Soft Water Filtered Water Electrical Panel Hard Soft Water Ground Strap Raw Water To Outdoors Drain Drain Water Meter Multi Media Multi Media Taste and Odor Softener Water Heater Filter (MM or neXtSand) Filter (NU) (TO) Filter... -
Page 16: Preparations
PREPARATIONS Media Installation (When Necessary). Models including and higher than (Models 20,30,) of media are shipped with separate media in pails or boxes. Models lower than 1.5 CF of media come loaded with media and this step can be skipped for new installation. CAUTION! The unit should be de-pressurized before installing or replacing media The riser (distributor) - Page 17 Birm Filter Multi Media Filter (BM) Media (MM or nextSand) Media Bed Birm nextSand (Black) (Black) Support Bed Support Bed (when supplied) (when supplied) Fine, Medium Fine, Medium and/or Coarse and/or Coarse Gravel Gravel NOTE: Some medias like those used in NU Models are sacrificial and deplete faster depending on inlet water conditions and usage.
- Page 18 3. Outside faucets used to water lawns and gardens should not supply untreated water. A new water line is often required to be connected to supply untreated water to the inlet of the water filter and to the outside faucets. Cut the water line between where it enters the house and before any lines that branch off to feed the hot water heater or other fixtures in the house and as near the desired location of the water filter as possible.
- Page 19 6. Connect Filter to the house plumbing. Any solder joints near the valve must be done before connecting any piping to the valve. Always leave at least 6” (152 mm) between the valve and joints when soldering pipes that are connected to the valve. Failure to do this could cause damage to the valve. Correct Installation of the Check Valve: Install 1”...
-
Page 20: Startup Instructions
STARTUP INSTRUCTIONS 1. Connect the transformer to the valve. Plug the Key Pad Configuration: 12-volt transformer into a 120 VAC 60 Hz outlet. MENU SET/REGEN 1. Plug the valve into an approved power source. Power the Valve and Configure to Filter 2. - Page 21 Automatic Raw Water Bypass During Regeneration The regeneration cycle can last 80 minutes after which filtered water service will be restored. During regeneration, un-filtered water is automatically bypassed for use in the household. Hot water should be used as little as possible during this time to prevent un-filtered water from filling the water heater.
-
Page 22: System Check List / During Regeneration / Plumbing System Clean-Up
New Sounds You may notice new sounds as your water softener operates. The regeneration cycle lasts approximately 2-1/2 hours. During this time, you may hear water running intermittently to the drain. PLUMBING SYSTEM CLEAN-UP The following procedures are guidelines only but have proven successful in most instances. Under no circumstances should any procedure outlined below be followed if contrary to the appliance manufacturer’s instructions. -
Page 23: Water Bypass / Operating Conditions / Maintenance Instructions
OPERATING CONDITIONS Water Heater If the water heater has been exposed to both iron and hardness for a long period of time, replacement of the heater tank maybe the only practical solution to prevent continued staining originating from this source. After completing the installation of the chemical free iron filter system, clean the water heater by following these instructions: 1. -
Page 24: Backwashing Instructions
Replacing Media Bed The media bed in a neutralizing Model NU filter is slowly dissolved and has to be replaced. The frequency of replacement varies, depending on water quality - consult your dealer to determine the expected life of your media bed. NU - the media bed in a neutralizing filter is slowly dissolved and has to be replaced. -
Page 25: Servicing 565 Valve
SERVICING 565 VALVE Before Servicing 1. Turn off water supply to conditioner : a. If the conditioner installation has a 3 valve bypass system first open the valve in the bypass line, then close the valves at the conditioner inlet & outlet. b. -
Page 26: Timer Replacement / Piston Assembly Replacement
PISTON AND/OR BRINE VALVE ASSEMBLY REPLACEMENT Remove 3 X Piston Seal and Screws Assembly Spacer Plate Brine Valve Assembly 1. Follow steps 1 to 6 of timer /Powerhead 3. Remove the plate from the valve body and pull the 5. Replace piston assembly followed by timer assembly. replacement. -
Page 27: Clean Injector Assembly
CLEAN INJECTOR ASSEMBLY 1. Remove two screws of the injector cap. 2. Pull the Injector Cap Out, Remove the injector assembly, oring and screen, Clean the injectors and replace cap REPLACE METER ASSEMBLY Meter Cable 1. Disconnect the meter cable from the meter. 2. -
Page 28: Replace Motor / Replace Microswitches
REPLACE MOTOR Motor Screws 1. Remove the powerhead front cover 2. Remove all connections from the circuit board 3. Remove the cover from the powerhead 4. Remove the motor screws and pull the motor out from powerhead REPLACE DRAIN LINE FLOW CONTROL 1. -
Page 29: Circuit Board Replacement / Drain Washer Replacement / After Servicing
REPLACING PCBS Remove front Remove PCBs cover by removing the screws shown in the picture... -
Page 30: Parts Breakdown
PARTS BREAKDOWN Control Valve Upper Cone (18280) Distributor Bypass - 60095097 Model Mineral Tank Size Tank # (Natural Color) Tank # Tank # Distrubutor# Valve # Media Bed # (Black Color) (Blue Color) TP-75 8 x 44 25010025 25010027 25010026 50010005 10010043 95401... - Page 31 PARTS BREAKDOWN 565 power head parts list Part # Description (Water group) 60095084 BNT365 Cover 60010055 Piston Stem Holder 60018054 Screw-ST3.5×13 60010658 Screw-M3×5 92393 Motor-12v/2rpm 60010659 Motor Mounting Plate 60010660 Motor Pin 60010664 Bnt165 Drive Gear 60010677 Idler Gear 60010099 Screw-ST2.9×13(Large Wafer) 60010100 Washer-3x13...
- Page 32 PARTS BREAKDOWN Valve Body Parts List Part # Part Description Qty 60010076 SCREW M5×16 60010075 SCREW M5×12 60010645 END PLUG RETAINER 13446 END PLUG 13001 65 PISTON ROD 60010646 PISTON RETAINER 60010647 60010648 PISTON 14241 SPACER 13242-02 SEAL 13755-1 BNT 65 VALVE BODY 60010095 AIR DISPENSER 12638...
- Page 33 PARTS BREAKDOWN 565 bypass parts list Part # Description (WaterGroup) 60010006 Bypass Tool 063 Bypass Body 60010026 O-ring( 22.4×3.55) 60010020 Connector 3/4”NPT Connector Clip Bypass Shaft( Outlet) Bypass Shaft( Inlet) O-ring(30×2.65) Shaft Seal 92846 Plug Clip Shaft Clip 60010209 Bypass Plug 60010044 O-ring(12×2) 60010126...
- Page 34 TROUBLE SHOOTING GUIDE Problem Cause Correction 1. Filter bleeds taste and odor or A. Bypass valve is open A. Close bypass valve sediment B. Electrical service to unit has been interrupted B. Assure permanent electrical service (check fuse, plug or switch) C.
-
Page 35: Trouble Shooting Guide / Master Programming Guide
MASTER PROGRAMMING GUIDE Power the Valve and Configure to Filter Hold Up and Down Key for 3 Seconds. Press Set/Regen to Select the Value and Up/ Down Arrow to Change it. Refer to the values on the blocks that need to be set. Press Down Key to move to the next screen. SYSTEM LANGAUAGE REGEN DAYS Key Pad Configuration:... - Page 36 Seven Year Complete Parts Warranty Canature WaterGroup™ will replace any part which fails within 84 months from date of manufacture, as indicated by the serial number, provided the failure is due to a defect in material or workmanship. The only exception shall be when proof of purchase or installation is provided and then the warranty period shall be from the date thereof.
