Screen Snapshot: When Screen Snapshot is enabled (from the Accessories
menu tab), pressing the MARK key creates a saved screen capture (when
you have an optional-purchase MMC/SD card installed). Once you have
created a screen capture, a screen capture thumbnail is added to the Screen
Snapshot View, and is available to view at a later date. See the full-sized
image by highlighting a thumbnail (using the Up or Down 4-Way Cursor
keys), then using the Right 4-Way Cursor key to view the full image. A border
around the full-size screen snapshot indicates that it is just a screen
snapshot, not a "live" view. You can delete the selected image, or all
images, by selecting a thumbnail and using Delete Image, or using Delete
All Images from the Screen Snapshot X-Press™ menu.
Working with screen snapshots is a four-step process:
1. Enabling Screen Snapshot from the Accessories Menu.
2. Making a Screen Snapshot using the MARK key.
3. Viewing a Screen Snapshot using the Screen Snapshot View.
4. Deleting a Screen Snapshot using the Screen Snapshot X-Press™
menu.
For more information, see Accessories Menu Tab: Using Screen Snapshot
and Screen Snapshot X-Press™ Menu.
5:03 PM Page 31
When you start a screen snapshot, you will see a message that a waypoint
has been created at the point where your cursor is on the screen, and the
screen will freeze while the snapshot is being saved to the MMC/SD card. A
status dialog box will appear that shows the progress of the save as a
percentage, and that displays the numbered file name assigned to the .BMP
file that is being created. Snapshot filenames begin with the letter "S". For
more information, see the Accessories Menu Tab: Using Screen Snapshot
procedure and Screen Snapshot X-Press™ Menu.
