Humminbird 931C Installation And Operation Manual page 12

93x_Man_531370-1_A - vs4.qxd 2/18/2005
1 2
1
Power
2
Speed
5
3 Communications
4 Transducer
5
Cable Collector Insert
1
3
11:11 AM Page 12
3 4
2
10. Attach the cable collector insert to the cable collector cover using the 2 Phillip
11. Place the control head back onto the mounting bracket. Plug in the cable
4
5
NOTE: You may wish to dress the cabling with nylon wire ties in order to hold the cables
together and create a cleaner assembly.
The Humminbird® 900 Series™ control head is now ready for operation.
1 Cable Collector Insert
2 Screws
3
Cable Collector Cover
4
Tab on Insert
5 Slot on Cover
7
9. While holding cables in place in the cable
Plug Cable Connector Assembly to
Back of Control Head collector insert, thread the cables through
the slot in the bottom of the cable collector
cover, line up the cable collector insert and
cover, then slide the cover into place on the
insert.
NOTE: The tab on the Cable Collector insert goes
into the slot on the cover.
screws provided.
collector assembly to the back of the control head. Cable connectors and cable
sockets are keyed to prevent reverse installation, so be careful not to force the
connectors into the wrong sockets. Once the cable collector and all cables are
plugged into the back of the control head, lock the assembly into place by
threading the knurled screw into the threaded insert on the back of the housing.
Adjust the control head to the desired viewing angle and secure by tightening
the gimbal knobs.
