Summary of Contents for Hunter Sea Point
- Page 1 Sea Point Installation Manual Model: 51681 Flat Matte Black 51682 Matte Silver Fan weight ±2 lbs: 22.5 lbs (10.2 kg) ©2022 Hunter Fan Co. PG4070 r061322...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 1886 Here is what comes in your box: Hunter Pro Tip: We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Do not discard the hardware bags or mix parts from parts.
- Page 4 1886 Choosing the Right Installation Location You probably bought this fan with a location in mind. Let’s check below to make sure it is a good fit. Check the room dimensions: Check the outlet box: 30 inches You must be able to secure the fan to building from blade tip to structure or fan-rated...
-
Page 5: Installing The Ceiling Bracket
Installing the Ceiling Bracket You have two options for installation. Pick which one works best for your location. Remove any existing bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. Hunter Pro Tip:... -
Page 6: Hanging The Fan
Follow below if you are using the downrod that came pre-assembled in your box. Need to install a longer or shorter downrod? Check out the guide at the end of this manual. Hunter Pro Tip: The ground wire attached to the downrod is approximately 8 inches. - Page 7 If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualified electrician. You are going to need these: Hunter Pro Tip: Here is how to connect the wires: 4 Wire Nuts (these are in the...
-
Page 8: Installing The Blades
1886 Installing the Canopy Insert the two canopy screws found in the hardware bag. Canopy Screw Lift the canopy into place so that the screw holes are aligned. Note: Fan style may vary. Installing the Blades: Secure each blade to a blade iron as shown using the blade nuts, found in the hardware bag, and the blade assembly screws, found in the hardware bag. - Page 9 1886 Assembling the Light 2 of 3 Light Kit Screw Feed the 9-pin plug connector coming from the bottom of the motor housing Partially install two light kit screws, through the center hole in the light kit found in the hardware bag, through assembly.
- Page 10 1886 Installing the Pull Chains The fan pull chain The light pull chain controls the speed: controls the light Repeat x2 from high to off. fixture: on and off. Remove and discard the plastic connectors from the ends of the short pull chain. Feed the pull chains from the fan switch and the light switch down through the holes in the upper switch housing as shown.
-
Page 11: Troubleshooting
Hunter instructions, accidental damage caused by the fan owner or related parties, Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. modifications to the fan, improper or incorrectly performed maintenance or repair,... - Page 12 1886 Downrod If you need a different downrod length follow these steps: Follow steps 1-5 to remove standard downrod pipe Here is another view of the downrod assembly unassembled. Follow steps 6-10 to reassemble with new downrod WARNING • VERIFY the downrod •...
