Hardware Requirements
Table 2 lists the CWI client hardware requirements.
Table 2 CWI Client Hardware Requirements
System
Requirement CPU and CPU Speed MHz
IBM PC-compatible 500 MHz PentiumIII minimum,
Windows-based
PC 1.20 GHz Pentium IV recommended
Solaris 550 MHz minimum,
UNIX
1.2 GHz recommended
Linux-based PC IBM PC-compatible 500 MHz PentiumIII minimum,
1.20 GHz Pentium IV recommended
Macintosh 500 MHz minimum,
1.20 GHz recommended
Software Requirements
Table 3 lists the CWI client software requirements.
Table 3 CWI Client Software Requirements
System Requirement Operating System
Windows-based PC Windows 2000 or Windows XP
Linux-based PC Red Hat Linux Release 7.1 or any Linux operating
system on which JRE
Macintosh MAC OS X 10
1. JRE = Java Runtime Environment
4

Configuring the Router and CWI Client

To install CWI and for CWI to manage a router, specific configuration pieces must be active on the router. If you want to use
the serial port or terminal server connection method after installation, no further router configuration is required. For all other
connection methods, ensure that the router is configured, as described in this section.
The "Troubleshooting Basic IP Connectivity" section on page 24 provides information on resolving connectivity problems. See
Cisco IOS XR System Management Configuration Guide for information on the capabilities of, installation of
Cisco IOS XR software packages on, and bootup of the router.
These sections describe how to set up client connections on the router:
• Enabling the HTTP Server, page 5
• Setting Up the Common Configuration for IP Connection Methods, page 5
• Connection Methods, page 6
• Setting Up the Minimum Crypto Requirements, page 6
4
1
1.5 runs
RAM Drive Space
256 MB minimum, CWI=5MB,
512 MB recommended JRE=48MB.
256 MB minimum, CWI=5MB,
512 MB recommended JRE=48MB
256 MB minimum, CWI=5MB,
512 MB recommended JRE=48MB
256 MB minimum, CWI=5MB,
512 MB recommended JRE=48MB
Additional Software
One of these browsers:
• Microsoft Internet Explorer 5.0 or higher
• Netscape Navigator 7.0 or higher
JRE version 1.5
Netscape Navigator
JRE version 1.5
See the Sun website for the latest minimum system
requirements for the JRE on Linux.
Safari version 1.2.3
JRE version 1.5
Monitor Display
Settings
1024 by
768 pixels
1024 by
768 pixels
1024 by
768 pixels
1024 by
768 pixels
