PCI Wake on LAN Token Ring Adapter
86H1880
Installation Guide

Advertisement

loading

Related Manuals for HP Vectra VE6 8

Summary of Contents for HP Vectra VE6 8

  • Page 1 PCI Wake on LAN Token Ring Adapter 86H1880 Installation Guide...
  • Page 2 Microsoft®, Windows® and MS-DOS® are registered trademarks of Microsoft Corporation. is a trademark of Intel Corporation. Pentium® is a registered trademark of Intel Corporation. Hewlett-Packard France Commercial Desktop Computing Division 38053 Grenoble Cedex 9 France © 1998 Hewlett Packard Company...
  • Page 3 Windows for Requirements Workgroups • HP Vectra with DOS and MS-Windows for Workgroups 3.11 installed. • IBM Token-Ring 16/4 PCI adapter and drivers CD ver 1. • Driver Name: IBMTRPO.LAN Size: 65KB Date: 7/26/96 • Novell Netware server that supports Net BEUI, NWLink IPX/SPX, and NWLink NetBIOS transfer protocols.
  • Page 4 1 Connecting to a Netware 3.12 Server Windows for Workgroups double-click the “NetWare User Login” icon. 9 Login into the current server to verify connection. (If you do not have the required information to Login, contact your system administrator)
  • Page 5 Interrupt I/O Address Procedure 1 With the HP Vectra turned off, install the IBM 16/4 PCI TR adapter card into a PCI slot. 2 Boot the machine to Windows 95, and the Token-Ring card will automatically be recognized. Click on “Next.”...
  • Page 6 10 In the “Copying Files…” dialogue box, set the path to “D:\DOS\” (Where “D” is the drive letter assigned to your CD-ROM) and click “OK.” (If you have an HP preloaded HDD, set the path to “C:\MASTERS\LAN \TRPCI.WOL\DOS\”) 11 When prompted for the file “IBMTRP.VXD”, set the path to “D:\WIN95\”...
  • Page 7 Windows for Requirements Workgroups • HP Vectra with DOS and MS-Windows for Workgroups 3.11 installed. • IBM Token-Ring 16/4 PCI adapter and drivers CD ver 1. • Driver Name: IBMTRPO.LAN Size: 65KB Date: 7/26/96 • Novell Netware server 4.1 that supports Net BEUI, NWLink IPX/SPX, and NWLink NetBIOS transfer protocols.
  • Page 8 2 Connecting to a Netware 4.11 Server Windows for Workgroups (If you do not have the required information to Login, contact your system administrator)
  • Page 9 Interrupt I/O Address Procedure 1 With the HP Vectra turned off, install the IBM 16/4 PCI TR adapter card into a PCI slot. 2 Boot the machine to Windows 95, and the Token-Ring card will automatically be recognized. Click on “Next.”...
  • Page 10 10 In the “Copying Files…” dialogue box, set the path to “D:\DOS\” (Where “D” is the drive letter assigned to your CD-ROM) and click “OK.” (If you have an HP preloaded HDD, set the path to “C:\MASTERS\LAN \TRPCI.WOL\DOS\”) 11 When prompted for the file “IBMTRP.VXD”, set the path to “D:\WIN95\”...
  • Page 11 Interrupt I/O Address Procedure 1 With the HP Vectra turned off, install the IBM 16/4 PCI TR adapter card into a PCI slot. 2 Power on the machine and boot to Windows 3.11. 3 After Windows loads, open the “NETWORK” folder, and double-click the “NETWORK SETUP”...
  • Page 12 3 Connecting to a Windows NT 3.51 Server Windows for Workgroups 9 Verify that “IBM PCI Token-Ring Adapter, NDIS2/3” is listed under “Network Drivers” and click on “Close.” 10 Click on “OK” in the “Network Setup” window. 11 Specify your User Name, Workgroup Name, Computer Name, and click on “OK.”...
  • Page 13 Interrupt I/O Address Procedure 1 With the HP Vectra turned off, install the IBM 16/4 PCI TR adapter card into a PCI slot. 2 Boot the machine to Windows 95, and the Token-Ring card will automatically be recognized. Click on “Next.”...
  • Page 14 10 In the “Copying Files…” dialogue box, set the path to “D:\DOS\” (Where “D” is the drive letter assigned to your CD-ROM) and click “OK.” (If you have an HP preloaded HDD, set the path to “C:\MASTERS\LAN \TRPCI.WOL\DOS\”) 11 When prompted for the file “IBMTRP.VXD”, set the path to “D:\WIN95\”...
  • Page 15 Interrupt I/O Address Procedure 1 With the HP Vectra turned off, install the IBM 16/4 PCI TR adapter card into a PCI slot. 2 Power on the machine and boot to Windows NT 3.51. 3 After Windows loads, open the “MAIN” program group , and double-click on “Control Panel”...
  • Page 16 10 Set the path to “D:\NT” (Where “D:\” represents the drive letter assigned to the CD-ROM) in the “Insert Disk” dialog box, and then insert the IBM Token-Ring 16/4 PCI adapter and drivers CD. (If you have an HP preloaded HDD, set path to “C:\Masters\LanDrv \DISK4\NT\”) 11 Click “OK”...
  • Page 17 Interrupt I/O Address Procedure 1 With the HP Vectra turned off, install the IBM 16/4 PCI TR adapter card into a PCI slot. 2 Power on the machine and boot to Windows NT Workstation 4.0. 3 Click on “Start”, up to “Settings”, and open “Control Panel.”...
  • Page 18 15 In the “Windows NT Setup” enter the path to your NT files, and click on the “Continue” button. (If you have an HP preloaded HDD, set path to “C:\I386”) 16 Click on the “OK” button in the “IBM PCI Token-Ring Adapter” dialog box.

  • Page 19: Connecting To A Windows Nt 4.0 Server

    Interrupt I/O Address Procedure 1 With the HP Vectra turned off, install the IBM 16/4 PCI TR adapter card into a PCI slot. 2 Power on the machine and boot to Windows 3.11. 3 After Windows loads, open the “NETWORK” folder, and double-click the “NETWORK SETUP”...
  • Page 20 4 Connecting to a Windows NT 4.0 Server Windows for Workgroups 8 Select “IBM PCI Token-Ring Adapter, NDIS2/3” and click on “OK.” 9 Verify that “IBM PCI Token-Ring Adapter, NDIS2/3” is listed under “Network Drivers” and click on “Close.” 10 Click on “OK” in the “Network Setup” window. 11 Specify your User Name, Workgroup Name, Computer Name, and click on “OK.”...
  • Page 21 Interrupt I/O Address Procedure 1 With the HP Vectra turned off, install the IBM 16/4 PCI TR adapter card into a PCI slot. 2 Boot the machine to Windows 95, and the Token-Ring card will automatically be recognized. Click on “Next.”...
  • Page 22 10 In the “Copying Files…” dialogue box, set the path to “D:\DOS\” (Where “D” is the drive letter assigned to your CD-ROM) and click “OK.” (If you have an HP preloaded HDD, set the path to “C:\MASTERS\LAN \TRPCI.WOL\DOS\”) 11 When prompted for the file “IBMTRP.VXD”, set the path to “D:\WIN95\”...
  • Page 23 Interrupt I/O Address Procedure 1 With the HP Vectra turned off, install the IBM 16/4 PCI TR adapter card into a PCI slot. 2 Power on the machine and boot to Windows NT 3.51. 3 After Windows loads, open the “MAIN” program group , and double-click on “Control Panel”...
  • Page 24 10 Set the path to “D:\NT” (Where “D:\” represents the drive letter assigned to the CD-ROM) in the “Insert Disk” dialog box, and then insert the IBM Token-Ring 16/4 PCI adapter and drivers CD. (If you have an HP preloaded HDD, set path to “C:\Masters\LanDrv \DISK4\NT\”) 11 Click “OK”...
  • Page 25 Interrupt I/O Address Procedure 1 With the HP Vectra turned off, install the IBM 16/4 PCI TR adapter card into a PCI slot. 2 Power on the machine and boot to Windows NT Workstation 4.0. 3 Click on “Start”, up to “Settings”, and open “Control Panel.”...
  • Page 26 15 In the “Windows NT Setup” enter the path to your NT files, and click on the “Continue” button. (If you have an HP preloaded HDD, set path to “C:\I386”) 16 Click on the “OK” button in the “IBM PCI Token-Ring Adapter” dialog box.
  • Page 28 Version Number IBM PC WOL 16/4 Rev.1...
