Chapter 1
INTRODUCTION
The ATX LX4 Dual-P mainboard is a high-performance dual-processor
personal computer mainboard based on the Intel
The mainboard uses the highly integrated Intel
which optimize the system bandwidth and concurrency with the
implementation of Quad Port Acceleration (QPA). QPA provides 4-port
concurrent arbitration of the processor bus, graphics, PCI bus and SDRAM.
®
The Intel
82371AB chipset integrates all system control functions such as
ACPI (Advanced Configuration and Power Interface). The ACPI provides
more Energy Saving Features for the OSPM(OS Direct Power Management)
function. The Intel
supporting Ultra DMA/33 IDE that transfers data at the rate of 33MB/s.
The mainboard also supports the LM78 System Hardware Monitor
Controller as an optional function. The LM78 function includes: CPU /
power supply/chassis fan revolution detect, CPU/system voltage monitor,
system temperature monitor, and chassis intrusion detect(optional).
®
82371AB chipset also improves the IDE transfer rate by
®
Pentium
®
82440LX AGP chipset
1-1
INTRODUCTION
INTRODUCTION
INTRODUCTION
INTRODUCTION
INTRODUCTION
®
II processor.
