Error Message - Canon imagePROGRAF iPF8300S Basic Guide No.2 Basic Manual

Error Message

No x printhead (x is L, R, or not
displayed)
x printhead error (x is L, R, or not
displayed)
Wrong x printhead. (x is L, R, or
not displayed)
PHeads: wrong pos.
Execute printhead cleaning.
Cause
No Printhead is installed.
There is a problem with the
Printhead .
An incompatible Printhead has
been installed.
The printheads are installed in the
wrong positions.
The Printhead nozzles are
clogged.
Corrective Action
Install the Printhead L if " Printhead L " is displayed
and the Printhead R if " Printhead R " is displayed. If
neither left or right is indicated, install both Printhead
L and Printhead R .
(→ , Replacing the Printhead)
Follow these steps to replace the Printhead .
1. Open the Top Cover .
2. Replace the Printhead L with a new one if
" Printhead L " is displayed and the Printhead R if
" Printhead R " is displayed. If neither left or right is
indicated, replace both Printhead L and Printhead
R with new ones.
(→ , Replacing the Printhead)
Follow these steps to replace the Printhead .
1. Turn off the printer, wait a while, and then turn it on
again.
2. Replace the Printhead L with a new one if
" Printhead L " is displayed and the Printhead R if
" Printhead R " is displayed. If neither left or right is
indicated, replace both Printhead L and Printhead
R with new ones.
(→ , Replacing the Printhead)
Open the Top Cover . Replace the Printhead L
with a new one if " Printhead L " is displayed and the
Printhead R if " Printhead R " is displayed. If neither
left or right is indicated, replace both Printhead L and
Printhead R with new ones.
(→ , Replacing the Printhead)
Open the Top Cover and switch the Printhead used
once in the right side to the right side. Switch the
Printhead used once in the left side to the left side.
Follow these steps to clean the Printhead .
1. Stop printing by pressing ▲ or ▼ to select Stop
Printing .
2. Clean the Printhead .
(→ , If Printing is Faint)
If the message is still displayed when printing, replace
the Printhead .
(→ , Replacing the Printhead)
Press ▲ or ▼ to select Print , and then press the OK
button to resume printing. However, note that this
error may affect the printing quality.
If OK is shown on the Display Screen , clean the
Printhead .
1. Press the OK button on the Control Panel to stop
printing.
2. Clean the Printhead .
(→ , If Printing is Faint)
If the message is still displayed when printing, replace
the Printhead .
(→ , Replacing the Printhead)
41
Error Messages
