Page 1 ..........1-1 Instrument Panel .
Page 2 Front Axle ........6-47 Headlamp Aiming .
Page 3 For vehicles first sold in Canada, substitute the name General Motors of Canada Limited for Chevrolet Motor Division wherever it appears in this manual. Keep this manual in the vehicle for quick reference.
Page 4: Service
Warning messages found on vehicle labels and in this manual describe hazards and what to do to avoid or reduce them. indicates a hazard with a high level of risk which will result in serious injury or death. indicates a hazard that could result in injury or death.
Page 5: Fuel
Here are some additional symbols that may be found on the vehicle and what they mean. For more information on the symbol, refer to the index. Adjustable Pedals Airbag Readiness Light Air Conditioning Antilock Brake System (ABS) Audio Steering Wheel Controls or OnStar Brake System Warning Light Charging System Cruise Control...
Page 209: Instrument Panel
......4-3 Hazard Warning Flashers ..... . . 4-3 Horn .
Page 210 Tow/Haul Mode Light ......4-41 Fuel Gage ........4-41 Low Fuel Warning Light .
Page 211 Press this button located on top of the steering column, to make the front and rear turn signal lamps flash on and off. This warns others that you are having trouble. Press again to turn the flashers off. When the hazard warning flashers are on, the vehicle's turn signals will not work.
Page 212 The lever on the left side of the steering column includes the following: Turn and Lane Change Signals Headlamp High/Low-Beam Changer Windshield Wipers Windshield Washer Flash-to-Pass. Exterior Lamps. Information for these features is on the pages following. An arrow on the instrument panel cluster flashes in the direction of the turn or lane change.
Page 213 If the turn signal is left on for more than 3/4 of a mile (1.2 km), a chime sounds at each flash of the turn signal and the message TURN SIGNAL ON also appears in the DIC. See . To turn the chime and message off, move the turn signal lever to the off position.
Page 214 Turn the band with the wiper symbol to control the windshield wipers. Single wipe, turn to Several wipes, hold the band on Turns the windshield wipers off. Turn the band up for more frequent wipes or down for less frequent wipes. Slow wipes.
Page 215 Cruise control can be dangerous where you cannot drive safely at a steady speed. So, do not use the cruise control on winding roads or in heavy traffic. Cruise control can be dangerous on slippery roads. On such roads, fast changes in tire traction can cause excessive wheel slip, and you could lose control.
Page 216 Cruise control will not work if the parking brake is set, or if the master cylinder brake fluid level is low. The cruise control light on the instrument panel cluster will come on after the cruise control has been set to the desired speed.
Page 217 To reduce your speed while using cruise control: Press and hold the SET button on the steering wheel until the desired lower speed is reached, then release it. To slow down in small amounts, press the SET button on the steering wheel briefly. Each time this is done, the vehicle goes about 1.6 km/h (1 mph) slower.
Page 218 The exterior lamps control is located on the instrument panel to the left of the steering wheel. It controls the following systems: Headlamps Taillamps Parking Lamps License Plate Lamps Instrument Panel Lights The exterior lamps control has four positions: Turns off the automatic headlamps and daytime running lamps (DRL).
Page 219: Keys
When the headlamps are turned on while the vehicle is on, the headlamps turn off automatically 10 minutes after the ignition is turned off. When the headlamps are turned on while the vehicle is off, the headlamps will stay on for 10 minutes before automatically turning off to prevent the battery from being drained.
Page 220 When it is dark enough outside and the headlamp switch is in AUTO, the automatic headlamp system turns on the headlamps along with other lamps such as the taillamps, sidemarker, parking lamps, roof marker lamps, and the instrument panel lights. The radio lights will also be dim.
Page 221 If your vehicle has fog lamps you can use them for better vision in foggy or misty conditions. Your parking lamps and/or low-beam headlamps must be on for your fog lamps to work. The fog lamp button is located on the left side of your instrument panel.
Page 222: Driver Information Center (Dic)
The dome lamps come on when any door is opened. They turn off after all the doors are closed. The dome lamps can also be turned on by turning the instrument panel brightness knob, located on the instrument panel to the left of the steering column, clockwise to the farthest position.
Page 223: Windows
A high electrical load occurs when several of the following are on, such as: headlamps, high beams, fog lamps, rear window defogger, climate control fan at high speed, heated seats, engine cooling fans, trailer loads, and loads plugged into accessory power outlets. EPM works to prevent excessive discharge of the battery.
Page 224 For vehicles with an ashtray it is located in the center console or on the instrument panel. Pull up on the ashtray door to open it if it is in the console or pull the door open it if it is on the instrument panel. To remove the ashtray, pull it out from the console or from the slide out door.
Page 225 Turn clockwise or counterclockwise to increase or decrease the fan speed. Turn the knob all the way counterclockwise to turn the front system off. Turn clockwise or counterclockwise to change the direction of the airflow inside the vehicle. The knob can be positioned between two modes, for a combination of those modes.
Page 226 Press to turn the outside air mode on. An indicator light comes on to show that outside air is on. Air from outside the vehicle is circulated throughout the vehicle. The outside air mode can be used with all modes, but it cannot be used with the recirculation mode.
Page 227 The heating, cooling, and ventilation in the vehicle can be controlled with this system. The vehicle also has a flow-through ventilation system described later in this section. A. Driver and Passenger G. Air Delivery Temperature Controls B. Fan Control H. Display C.
Page 228 The driver and passenger side temperature buttons are used to adjust the temperature of the air coming through the system on the driver or passenger's side of the vehicle. The temperature can be adjusted even if the system is turned off. This is possible since outside air always flows through the system as the vehicle is moving forward unless it is set to recirculation mode.
Page 229 2. Set the driver and passenger temperature. To find your comfort setting, start with a 23°C (74°F) temperature setting and allow about 20 minutes for the system to regulate. Use the driver or passenger temperature buttons to adjust the temperature setting as necessary. If a temperature setting of 15°C (60°F) is chosen, the system remains at the maximum cooling setting.
Page 230 Air is directed to the floor outlets, with some to the windshield, side window outlets, and second row floor outlets. In this mode, the system automatically selects outside air. This mode clears the windows of fog or moisture. Air is directed to the windshield, floor outlets, and side window vents.
Page 231 Press to turn the recirculation mode on. An indicator light comes on to show that the recirculation is on. This mode recirculates and helps to quickly cool the air inside the vehicle. It can be used to help prevent outside air and odors from entering the vehicle. The recirculation mode cannot be used with floor, defog, or defrost modes.
Page 232 The solar sensor, located in the defrost grille, middle of the instrument panel, monitors the solar heat. Do not cover the solar sensor or the system will not work properly. 4-24 There is also an interior temperature sensor located next to the steering wheel that measures the temperature of the air inside your...
Page 233: Front Seats
Your vehicle has air outlets located in the center and on the side of your instrument panel that allow you to adjust the direction and amount of airflow inside the vehicle. Move the louvers up or down. Use the thumbwheel next to or underneath the outlet to close the louvers.
Page 234 4-26...
Page 235 The speedometer shows the vehicle's speed in both kilometers per hour (km/h) and miles per hour (mph). The odometer shows how far the vehicle has been driven, in either kilometers (used in Canada) or miles (used in the United States). The trip odometer can show how far the vehicle has been driven since the trip odometer was last set to zero.
Page 236 For vehicles equipped with the passenger safety belt reminder light, several seconds after the engine is started, a chime sounds for several seconds to remind the front passenger to buckle their safety belt. The passenger safety belt light, located on the overhead console, comes on and stays on for several seconds, flashes for several more seconds and then comes on solid for several more.
Page 237 If there is a problem with the airbag system, an airbag Driver Information Center (DIC) message can also come on. See for more information. If the vehicle has the airbag status indicator pictured in the following illustration, then the vehicle has a passenger sensing system for the right front passenger position.
Page 238 If the word ON or the on symbol is lit on the passenger airbag status indicator, it means that the right front passenger frontal airbag is enabled (may inflate). If the word OFF or the off symbol is lit on the airbag status indicator, it means that the passenger sensing system has turned off the right front passenger frontal airbag.
Page 239 When the engine is not running, but the ignition is on, this gage shows the battery's state of charge in DC volts. When the engine is running, the gage shows the condition of the charging system. The charging system regulates voltage based on the state of the battery for improved fuel economy and battery life.
Page 240 If the warning light comes on and a chime sounds there could be a brake problem. Have the brake system inspected right away. This light can also come on due to low brake fluid. for more information. This light comes on briefly when the ignition key is turned to ON/RUN.
Page 241 For vehicles with the Antilock Brake System (ABS), this light comes on briefly when the engine is started. If it does not, have the vehicle serviced by your dealer/ retailer. If the system is working normally the indicator light then goes off. If the ABS light stays on, turn the ignition off.
Page 242 This gage shows the engine coolant temperature. It also provides an indicator of how hard the vehicle is working. During a majority of the operation, the gage will read 210°F (100°C) or less. If the vehicle is pulling a 4-34 load or going up hills, it is normal for the temperature to fluctuate and approach the 250°F (122°C) mark.
Page 243 This indicates that one or more of the tires is significantly underinflated. A tire pressure message in the Driver Information Center (DIC), can accompany the light. See information. Stop and check the tires as soon as it is safe to do so. If underinflated, inflate to the proper pressure.
Page 244: Towing
Malfunctions often are indicated by the system before any problem is apparent. Being aware of the light can prevent more serious damage to the vehicle. This system assists the service technician in correctly diagnosing any malfunction. 4-36 This light comes on during a malfunction in one of two ways: A misfire condition has been detected.
Page 245 An emission control system malfunction has been detected on the vehicle. Diagnosis and service might be required. An emission system malfunction might be corrected by doing the following: Make sure the fuel cap is fully installed. See . The diagnostic system can determine if the fuel cap has been left off or improperly installed.
Page 246 Some state/provincial and local governments have or might begin programs to inspect the emission control equipment on the vehicle. Failure to pass this inspection could prevent getting a vehicle registration. Here are some things to know to help the vehicle pass an inspection: The vehicle will not pass this inspection if the check engine light is on with the engine running,...
Page 247 This light comes on briefly while starting the engine. If it does not, have the vehicle serviced by your dealer/retailer. If the system is working normally the indicator light then goes off. If the light comes on and stays on, it means that oil is not flowing through the engine properly.
Page 248 For information regarding this light and the vehicle's security system, see The fog lamp light comes on when the fog lamps are in use. The light goes out when the fog lamps are turned off. for more information. 4-40 The light goes out when the cruise control is turned off. for more information.
Page 249 For vehicles with the tow/haul mode feature, this light comes on when the Tow/Haul mode has been activated. For more information, see When the ignition is on, the fuel gage shows how much fuel the vehicle has left in the tank. An arrow on the fuel gage indicates the side of the vehicle the fuel door is on.
Page 250 The gage first indicates empty before the vehicle is out of fuel, and the fuel tank should be filled soon. When the fuel tank is low, the FUEL LEVEL LOW message appears in the Driver Information Center (DIC). See for more information. Here are some situations customers may experience with the fuel gage.
Page 251 Your vehicle has a Driver Information Center (DIC). The DIC displays information about your vehicle. It also displays warning messages if a system problem is detected. All messages will appear in the DIC display located below the tachometer in the instrument panel cluster. The DIC comes on when the ignition is on.
Page 252 The buttons are the trip/fuel, vehicle information, customization, and set/reset buttons. The button functions are detailed in the following pages. Press this button to display the odometer, trip odometer, fuel range, average economy, fuel used, timer, instantaneous economy and Active Fuel Management indicator, and transmission temperature.
Page 253 Press this button to scroll through the following menu items: Press the trip/fuel button until ODOMETER displays. This display shows the distance the vehicle has been driven in either miles (mi) or kilometers (km). Pressing the trip odometer reset stem will also display the odometer.
Page 254 Press the trip/fuel button until FUEL RANGE displays. This display shows the approximate number of remaining miles (mi) or kilometers (km) the vehicle can be driven without refueling. The display will show LOW if the fuel level is low. The fuel range estimate is based on an average of the vehicle's fuel economy over recent driving history and the amount of fuel remaining in the fuel tank.
Page 255: Maintenance Schedule
Press the trip/fuel button until TRANS TEMP displays. This display shows the temperature of the automatic transmission fluid in either degrees Fahrenheit (°F) or degrees Celsius (°C). If your vehicle has this display, press the trip/fuel button until INST ECON V8 displays. This display shows the current fuel economy at a particular moment and will change frequently as driving conditions change.
Page 256 Remember, you must reset the OIL LIFE display yourself after each oil change. It will not reset itself. Also, be careful not to reset the OIL LIFE display accidentally at any time other than when the oil has just been changed. It cannot be reset accurately until the next oil change.
Page 257 This display allows you to match Remote Keyless Entry (RKE) transmitters to your vehicle. This procedure will erase all previously learned transmitters. Therefore, they must be relearned as additional transmitters. To match an RKE transmitter to your vehicle: 1. Press the vehicle information button until PRESS TO RELEARN REMOTE KEY displays.
Page 258 Press the trip odometer reset stem until TRIP displays. This display shows the current distance traveled in either miles (mi) or kilometers (km) since the last reset for the trip odometer. The trip odometer can be reset to zero by pressing and holding the trip odometer reset stem while the trip odometer is displayed.
Page 259 If your vehicle does not have DIC buttons, the information below explains the operation of this system. The DIC has different displays which can be accessed by pressing the trip odometer reset stem located on the instrument panel cluster. Pressing the trip odometer reset stem will also turn off, or acknowledge, DIC messages.
Page 260 Press the trip odometer reset stem until TRIP displays. This display shows the current distance traveled in either miles (mi) or kilometers (km) since the last reset for the trip odometer. The trip odometer can be reset to zero by pressing and holding the trip odometer reset stem while the trip odometer is displayed.
Page 261 This display allows for setting the compass zone. This display allows for calibrating the compass. To access this display, the vehicle must be in P (Park). Press the trip odometer reset stem until OIL LIFE REMAINING displays. This display shows an estimate of the oil's remaining useful life.
Page 262 To access this display, the vehicle must be in P (Park). This display allows you to match Remote Keyless Entry (RKE) transmitters to your vehicle. This procedure will erase all previously learned transmitters. Therefore, they must be relearned as additional transmitters. To match an RKE transmitter to your vehicle: 1.
Page 263 Your vehicle may have a compass in the Driver Information Center (DIC). The zone is set to zone eight upon leaving the factory. Your dealer/retailer will set the correct zone for your location. Under certain circumstances, such as during a long distance cross-country trip or moving to a new state or province, it will be necessary to compensate for compass variance by resetting the zone through the...
Page 264 2. Find the vehicle's current location and variance zone number on the map. Zones 1 through 15 are available. 3. Press the set/reset button to scroll through and select the appropriate variance zone. 4-56 4. Press the trip/fuel button until the vehicle heading, for example, N for North, is displayed in the DIC.
Page 265 To calibrate the compass, use the following procedure: 1. Before calibrating the compass, make sure the compass zone is set to the variance zone in which the vehicle is located. See Compass Variance (Zone) Procedure earlier in this section. Do not operate any switches such as window, sunroof, climate controls, seats, etc.
Page 266 When the vehicle s battery is severely discharged, this message will display and four chimes will sound. Start the vehicle immediately. If the vehicle is not started and the battery continues to discharge, the climate controls, heated seats, and audio systems will shut off and the vehicle may require a jump start.
Page 267 As soon as it is safe to do so, carefully pull your vehicle over to the side of the road and turn the ignition off. Check the wiring connection to the trailer and turn the ignition back on. This message clears if the trailer is reconnected.
Page 268 This message displays when the engine coolant temperature is too hot. Stop and allow the vehicle to idle until it cools down. See for information on driving to a safe place in an emergency. This message displays and a chime sounds if the engine cooling system reaches unsafe temperatures for operation.
Page 269 This message displays when ice conditions are possible. This message displays and a chime sounds if the driver side rear door is not fully closed and the vehicle is shifted out of P (Park). Stop and turn off the vehicle, check the door for obstructions, and close the door again.
Page 270 This message displays while you are matching a Remote Keyless Entry (RKE) transmitter to your vehicle. See Matching Transmitter(s) to Your Vehicle under information. This message displays if a Remote Keyless Entry (RKE) transmitter battery is low. The battery needs to be replaced in the transmitter.
Page 271: Theft-Deterrent Systems
This message displays along with the brake system warning light if there is a problem with the brake system. See . If this message appears, stop as soon as possible and turn off the vehicle. Restart the vehicle and check for the message on the DIC display. If the message is still displayed or appears again when you begin driving, the brake system needs service as soon as possible.
Page 272 On vehicles with the Tire Pressure Monitor System (TPMS), this message displays if a part on the TPMS is not working properly. The tire pressure light also flashes and then remains on during the same ignition cycle. conditions may cause this message to appear. See information.
Page 273 There are several conditions that can cause this message to appear. One condition is overheating, which could occur if StabiliTrak activates continuously for an extended period of time. The message also displays if the brake system warning light is on. See The message could display if the stability system takes longer than usual to complete its diagnostic checks due to driving conditions.
Page 274 On vehicles with the Tire Pressure Monitor System (TPMS), this message displays when the pressure in one or more of the vehicle's tires needs to be checked. This message also displays LEFT FRT (left front), RIGHT FRT (right front), LEFT RR (left rear), or RIGHT RR (right rear) to indicate the location of the low tire.
Page 275 This message displays along with a sound if the transmission fluid in the vehicle gets hot. Driving with the transmission fluid temperature high can cause damage to the vehicle. Stop the vehicle and let it idle to allow the transmission to cool. This message clears and the chime stops when the fluid temperature reaches a safe level.
Page 276 Your vehicle may have customization capabilities that allow you to program certain features to one preferred setting. Customization features can only be programmed to one setting on the vehicle and cannot be programmed to a preferred setting for two different drivers.
Page 277 This feature allows you to select the language in which the DIC messages will appear. Press the customization button until the DISPLAY LANGUAGE screen appears on the DIC display. Press the set/reset button once to access the settings for this feature.
Page 278 This feature allows you to select whether or not to turn off the automatic door unlocking feature. It also allows you to select which doors and when the doors will automatically unlock. See for more information. Press the customization button until AUTO DOOR UNLOCK appears on the DIC display.
Page 279 No change will be made to this feature. The current setting will remain. To select a setting, press the set/reset button while the desired setting is displayed on the DIC. This feature allows you to select the type of feedback you will receive when unlocking the vehicle with the Remote Keyless Entry (RKE) transmitter.
Page 280 This feature allows you to select the amount of time you want the exterior lamps to remain on when it is dark enough outside. This happens after the key is turned from ON/RUN to LOCK/OFF. Press the customization button until EXIT LIGHTING appears on the DIC display.
Page 281: Mirrors
This feature allows you to select the volume level of the chime. Press the customization button until CHIME VOLUME appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: The chime volume will be set to a normal level.
Page 282 If your vehicle has this feature, it allows you to select your preference for the automatic easy exit seat feature. for more information. Press the customization button until EASY EXIT RECALL appears on the DIC display. Press the set/ reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: No automatic seat exit recall...
Page 283 If your vehicle has this feature, it allows you to select your preference for the remote memory seat recall feature. See for more information. Press the customization button until MEMORY SEAT RECALL appears on the DIC display. Press the set/ reset button once to access the settings for this feature.
Page 284 This feature allows you to set all of the customization features back to their factory default settings. Press the customization button until FACTORY SETTINGS appears on the DIC display. Press the set/ reset button once to access the settings for this feature. Then press the customization button to scroll through the following settings: The customization features...
Page 285 Determine which radio the vehicle has and read the following pages to become familiar with its features. Taking your eyes off the road for extended periods could cause a crash resulting in injury or death to you or others. Do not give extended attention to entertainment tasks while driving.
Page 286 To set the time and date: 1. Turn the ignition key to ACC/ACCESSORY or ON/RUN, then press the radio on. 2. Press the button to display HR, MIN, MM, DD, YYYY (hour, minute, month, day, and year). 3. Press the softkey located under any one of the tabs to change that setting.
Page 287 The vehicle has one of these radios as its audio system. 4-79...
Page 288: Rear Seats
Radios with CD/MP3/DVD and USB may have a Bose Surround Sound System. Some of its features are explained later in this section under, Adjusting the Speakers (Balance/Fade) . If the vehicle has a Rear Seat Entertainment (RSE) system, it has a CD/MP3/DVD and USB radio. See The DVD player is the top slot on the radio faceplate.
Page 289 ® LTZ package and a Bose Audio System include the ® Bose AudioPilot noise compensation technology. ® When turned on, AudioPilot continuously adjusts the audio system equalization, to compensate for background noise, so that music always sounds the same at the set volume level. This feature is most effective at lower radio volume settings where background noise can affect how well the music is heard.
Page 290 Drivers are encouraged to set up their radio station favorites while the vehicle is stopped. Tune to favorite stations using the softkeys, favorites button, and steering wheel controls, if the vehicle has this feature. A maximum of 36 stations can be programmed as favorites using the six softkeys below the radio station frequency tabs and by using the radio favorites page button (FAV button).
Page 291 adjust bass, midrange, or treble, press the the tone control tabs display. Continue pressing to highlight the desired tab, or press the softkey below the tab. Turn the knob clockwise or counterclockwise to adjust the highlighted setting. Adjust the highlighted setting by pressing either SEEK arrow, (forward), or REV (reverse) button until the desired...
Page 292 To adjust balance or fade, press the knob until the speaker control tabs display. Continue pressing to highlight the desired tab, or press the softkey under the tab. Turn the counterclockwise to adjust the highlighted setting. Adjust the highlighted setting by pressing either SEEK arrow, FWD, or REV button until the...
Page 293 Undesired XM categories can be removed through the setup menu. To remove an undesired category: 1. Press the MENU button. 2. Press the softkey below the XM CAT tab. 3. Turn the knob to display the category to be removed. 4.
Page 294 section for further detail. Do not add any label to a CD. It could get caught in the CD or DVD player. If a CD is recorded on a personal computer and a description label is needed, try labeling the top of the recorded CD with a marking pen. The use of CD lens cleaners for CDs is not advised, due to the risk of contaminating the lens of the CD optics with lubricants internal to the CD and DVD player...
Page 295 Insert a CD partway into the slot, label side up. The player pulls it in and the CD should begin playing. Insert a CD partway into the slot, label side up. The player pulls it in and the CD should begin playing in 5 to 20 seconds for a CD, and in 30 seconds for a DVD, depending on media type and format ranges.
Page 296 Turn to select tracks on the CD that is currently playing. Press the left arrow to go to the start of the current track, if more than ten seconds on the CD have played. Press the right arrow to go to the next track.
Page 297 Press this button to cycle through DVD, CD, or Auxiliary when listening to the radio. The DVD/CD text label and a message showing the track or chapter number displays when a disc is in either slot. Press this button again and the system automatically searches for an auxiliary input device, such as a portable audio player.
Page 298 Radios with a Single CD player have the capability of playing an MP3 CD-R or CD-RW disc. For more information on how to play an MP3 CD-R or CD-RW disc, see Using an MP3 in the index. Radios with a CD and DVD player have the capability of playing an MP3/WMA CD-R or CD-RW disc.
Page 299 The DVD player is controlled by the buttons on the remote control, or by the RSA system, or by the buttons on the radio faceplate. See Remote Control , under information. The DVD player is only compatible with DVDs of the appropriate region code that is printed on the jacket of most DVDs.
Page 300 Press the button on the radio to eject the disc. If a disc is ejected from the radio, but not removed, the radio reloads the disc after a short period of time. The disc is stored in the radio. The radio does not resume play of the disc automatically.
Page 301 Turn to change tracks on a CD or DVD. arrow to return to the start of the current track or chapter. Press the left arrow again to go to the previous track or chapter. This button might not work when the DVD is playing the copyright information or the previews.
Page 302 Some DVDs begin playing after the previews have finished, although there could be a delay of up to 30 seconds. If the DVD does not begin playing the movie automatically, press the softkey under the play/pause tab on the radio. If the DVD still does not play, refer to the on-screen instructions, if available.
Page 303 To stop playing a DVD without turning off the system, press the button on the remote control, or press the softkey under the stop or the play/pause tab displayed on the radio. If the radio head is sourced to something other than DVD-V, press the DVD/CD AUX button to make DVD-V the active source.
Page 304 Drivers are encouraged to set up any auxiliary device while the vehicle is in P (Park). See for more information on driver distraction. To use a portable audio player, connect a 3.5 mm (1/8 in) cable to the radio's front auxiliary input jack. When a device is connected, press the radio CD/AUX button to begin playing audio from the device over the vehicle speakers.
Page 305 Radios with a USB port can control a USB storage ® device or an iPod using the radio buttons and knobs. for information about how to connect and control a USB storage device or an iPod. The USB connector is located on the instrument panel or in the center console, and uses the USB 2.0 standard.
Page 306 The radio can play discs that contain both uncompressed CD audio and MP3 files. If both formats are on the disc, the radio reads all MP3 files first, then the uncompressed CD audio files. The radio supports: Up to 50 folders. Up to 8 folders in depth.
Page 307 Folders that do not contain files are skipped, and the player advances to the next folder that contains files. Compressed audio files are accessed in the following order: Playlists (Px). Files stored in the root directory. Files stored in folders in the root directory. Tracks are played in the following order: Play begins from the first track in the first playlist and continues sequentially through all tracks in...
Page 308 Playlists can be changed by using the (next) folder buttons, the SEEK arrows. MP3 CD-R or CD-RW that have been recorded without using file folders can be played. If a CD-R or CD-RW contains more than the maximum of 50 folders, 15 playlists, and 512 folders and files, the player allows access and navigates up to the maximum, but all items over the maximum are not accessible.
Page 309 To listen to files by another artist, press the softkey located below either arrow tab. The disc goes to the next or previous artist in alphabetical order. Continue pressing either softkey below the arrow tab until the desired artist displays. To change from playback by artist to playback by album: 1.
Page 310 The radio can control a USB storage device or an iPod using the radio buttons and knobs and display song information on the radio s display. Turn to select files. Press to go to the start of the track, if more than ten seconds have played.
Page 311 Press the softkey below the contents of the current folder on the USB drive. To browse and select files: 1. Press the softkey below 2. Turn to scroll through the list of folders. 3. Press to select the desired folder. If there is more then one folder, repeat Steps 1 and 2 until the desired folder is reached.
Page 312 To skip through large lists, the five softkeys can be used to navigate in the following order: First softkey, first item in the list. Second softkey, 1% through the list each time the softkey is pressed. Third softkey, 5% through the list each time the softkey is pressed.
Page 313 The radio can play .mp3 or .wma files that were recorded onto a CD-R or CD-RW disc. The USB port can play .mp3 and .wma files that are stored on a USB storage device as well as AAC files ® that are stored on an iPod The radio plays discs that contain both uncompressed CD audio and MP3/WMA files depending on which slot...
Page 314 The radio supports: Up to 700 folders. Up to 8 folders in depth. Up to 65,535 files. Folder and file names up to 64 bytes. Files with an .mp3 or .wma file extension. AAC files stored on an iPod. FAT16 FAT32 The root directory of the disc is treated as a folder.
Page 315 Compressed audio files are accessed in the following order: Playlists. Files stored in the root directory. Files stored in folders in the root directory. Tracks are played in the following order: Play begins from the first track in the first playlist and continues sequentially through all tracks in each playlist.
Page 316 If a disc is inserted into the top DVD slot, the rear seat operator can turn on the video screen and use the remote control to navigate the CD (tracks only). Turn to select MP3/WMA files. Press to go to the start of the track, if less than five seconds have played.
Page 317 When the scan is finished, the disc begins playing files in order by artist. The current artist playing is shown on the second line of the display. Once all songs by that artist are played, the player moves to the next artist in alphabetical order and begins playing files by that artist.
Page 318 The radio can control a USB storage device or an iPod using the radio buttons and knobs and display song information on the radio s display. Turn to select files. Press to go to the start of the track, if more than ten seconds have played.
Page 319 Press the softkey below the contents of the current folder on the USB drive. To browse and select files: 1. Press the softkey below 2. Turn to scroll through the list of folders. 3. Press to select the folder. If there is more than one folder, repeat Steps 1 and 2 until the folder is reached.
Page 320 To skip through large lists, the five softkeys can be used to navigate in the following order: First softkey, first item in the list. Second softkey, 1% through the list each time the softkey is pressed. Third softkey, 5% through the list each time the softkey is pressed.
Page 321 The system is functioning correctly, but the vehicle is in a location that is blocking the XM signal. When the vehicle is moved into an open area, the signal should return. The audio system is acquiring and processing audio and text data. No action is needed. This message should disappear shortly.
Page 322 For vehicles with a navigation radio system, see the separate Navigation System manual. Vehicles with a Bluetooth system can use a Bluetooth capable cell phone with a Hands Free Profile to make and receive phone calls. The system can be used while the key is in ON/RUN or ACC/ACCESSORY position.
Page 323 A Bluetooth enabled cell phone must be paired to the in vehicle Bluetooth system first and then connected to the vehicle before it can be used. See the cell phone manufacturers user guide for Bluetooth functions before pairing the cell phone. If a Bluetooth phone is not connected, calls will be made using OnStar Hands Free Calling, if available.
Page 324 1. Press and hold for two seconds. The system responds with Ready followed by a tone. 2. Say Bluetooth . The system responds with Bluetooth ready followed by a tone. 3. Say List . The system lists all the paired Bluetooth devices.
Page 325 The store command allows a phone number to be stored without entering the digits individually. 1. Press and hold for two seconds. The system responds with Ready followed by a tone. 2. Say Store . The system responds with Store, number please followed by a tone.
Page 326 3. Say the first digit to be stored. The system will repeat back the digit it heard followed by a tone. Continue entering digits until the number to be stored is complete. If an unwanted number is recognized by the system, say Clear at any time to clear the last number.
Page 327 The delete command allows specific name tags to be deleted. To use the delete command: 1. Press and hold for two seconds. The system responds with Ready followed by a tone. 2. Say Delete . The system responds with Delete, please say the name tag followed by a tone.
Page 328 1. Press and hold for two seconds. The system responds with Ready followed by a tone. 2. Say Dial . The system responds with Dial using <phone name> . Number please followed by a tone. 3. Say the entire number without pausing. If the system recognizes the number, it responds with OK, Dialing and dials the number.
Page 329 1. Press and hold for two seconds. The system responds with Ready followed by a tone. 2. Say Call . The system responds with Call using <phone name>. Please say the name tag followed by a tone. 3. Say the name tag of the person to call. If the system clearly recognizes the name tag it responds with OK, calling, <name tag>...
Page 330 Call waiting must be supported on the Bluetooth phone and enabled by the wireless service carrier to work. Press to answer an incoming call when another call is active. The original call is placed on hold. Press again to return to the original call. To ignore the incoming call, continue with the original call with no action.
Page 331 Audio can be transferred between the in vehicle Bluetooth system and the cell phone. During a call with the audio in the vehicle: 1. Press . The system responds with Ready followed by a tone. 2. Say Transfer Call. The system responds with Transferring call and the audio will switch from the vehicle to the cell phone.
Page 332 1. Press . The system responds with Ready followed by a tone. 2. Say Dial . The system responds with Say a number to send tones followed by a tone. 3. Say the number to send. If the system clearly recognizes the number it responds with OK, Sending Number and the dial tones are sent and the call continues.
Page 333 Unless information is deleted out of the in vehicle Bluetooth system, it will be retained indefinitely. This includes all saved name tags in the phonebook and phone pairing information. For information on how to delete this information, see the above sections on Deleting a Paired Phone and Deleting Name Tags.
Page 334 Parental Control can also be turned off by inserting or ejecting any disc, pressing the play icon on the radio DVD display menu, or changing an ignition position. The RSE includes two 2-channel wireless headphones that are dedicated to this system. Channel 1 is dedicated to the DVD player, while Channel 2 is dedicated to RSA selections.
Page 335 To change the batteries on the headphones, do the following: 1. Turn the screw to loosen the battery door located on the left side of the headphones. Slide the battery door open. 2. Replace the two batteries in the compartment. Make sure that they are installed correctly, using the diagram on the inside of the battery compartment.
Page 336 To use the auxiliary inputs of the RSE system, connect an external auxiliary device to the color-coded A/V jacks and turn both the auxiliary device and the video screen power on. If the video screen is in the DVD player mode, pressing the AUX (auxiliary) button on the remote control switches the video screen from the DVD player mode to the auxiliary device.
Page 337 The video screen is located in the overhead console. To use the video screen, do the following: 1. Push the release button located on the overhead console. 2. Move the screen to the desired position. When the video screen is not in use, push it up into its locked position.
Page 338 Press this button to turn the video screen on and off. Press this button to turn the remote control backlight on. The backlight automatically turns off after seven to ten seconds if no other button is pressed while the backlight is on. Press this button to return the DVD to the main menu of the DVD.
Page 339 Press this button to go to the beginning of the next chapter or track. This button might not work when the DVD is playing the copyright information or the previews. Press this button to fast reverse the DVD or CD. To stop fast reversing a DVD video, press the play button.
Page 340 To change the remote control batteries, do the following: 1. Slide the rear cover back on to the remote control. 2. Replace the two batteries in the compartment. Make sure that they are installed correctly, using the diagram on the inside of the battery compartment.
Page 341 The auxiliary source is Check that the RSE video running but there is no screen is in the auxiliary picture or sound. source mode. Check the auxiliary input connections at both devices. Sometimes the wireless Check for obstructions, low headphone audio cuts out batteries, reception range, or buzzes.
Page 342 When cleaning the RSE overhead console surface, use only a clean cloth dampened with clean water. When cleaning the video screen, use only a clean cloth dampened with clean water. Use care when directly touching or cleaning the screen, as damage could result.
Page 343 Press this button to turn RSA on and off. Turn this knob to increase or to decrease the volume of the wired headphones. The left knob controls the left wired headphones and the right knob controls the right wired headphones. Press this button to switch between the radio FM, AM, or XM (if equipped), CD, and if the...
Page 344: Vehicle Identification
Press this button to go to the next preset radio station or channel set on the main radio. This function is inactive, with some radios, if the front seat passengers are listening to the radio. When a CD or DVD audio disc is playing, press this button to go to the beginning of the CD or DVD audio.
Page 345 To select preset or favorite radio stations: Press and release to go to the next or previous radio station stored as a preset or favorite. To select tracks on a CD/DVD: Press and release to go to the next or previous track.
Page 346 Press and release to select the next or previous track within the selected category. Press and hold to move quickly through the tracks. Press and release to move up one track within the selected category. Press and release to select the next or previous track within the selected category.
Page 347 For vehicles with a navigation system: 1. Press and hold until a beep is heard, to place the radio into SCAN mode, a station will play for five seconds before moving to the next station. 2. To stop the SCAN function, press While listening to a CD/DVD, press and hold quickly move forward through the tracks.
Page 348: Sunroof
XM Satellite Radio Service gives digital radio reception from coast-to-coast in the 48 contiguous United States, and in Canada. Just as with FM, tall buildings or hills can interfere with satellite radio signals, causing the sound to fade in and out. In addition, traveling or standing under heavy foliage, bridges, garages, or tunnels may cause loss of the XM signal for a period of time.
