Summary of Contents for Greenlee GATOR EK210
- Page 1 INSTRUCTION MANUAL Serialnummer GATOR EK210 ® Battery-powered Crimping Tool Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. 99947986 REV 13 © 2007 Greenlee Textron Inc. 11/07...
-
Page 2: Table Of Contents
All specifications are nominal and may change as design improvements occur. Greenlee Textron Inc. shall not be liable for damages resulting from misapplication or misuse of its products. GATOR and Kwik Cycle are registered trademarks of Greenlee Textron Inc. -
Page 3: Important Safety Information
Failure to observe this warning could result in severe injury or death. Greenlee / A Textron Company EK210 Battery-powered Crimping Tool Wear eye protection when operating or servicing this tool. Failure to wear eye protection could result in serious eye injury from flying debris or hydraulic oil. - Page 4 Use this tool for the manufacturer’s intended purpose only. Failure to observe these precautions may result in injury or property damage. Greenlee / A Textron Company EK210 Battery-powered Crimping Tool Do not allow anything to contact the battery terminals. •...
-
Page 5: Identification
Average Crimping Time ...2 seconds Average Crimps per Charge ...approximately 150 Battery Charging Voltage ... 9.6 V Charging Time ...45 min Greenlee / A Textron Company EK210 Battery-powered Crimping Tool 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070 T 15 ®... -
Page 6: Operation
Keep hands away from the crimping head when crimping. Failure to observe this warning could result in severe injury or death. Greenlee / A Textron Company EK210 Battery-powered Crimping Tool • Do not operate the tool without dies. Damage to the ram or crimping head can result. - Page 7 SIDE B First Compression SIDE A First Compression Crimping Direction SIDE A Greenlee / A Textron Company EK210 Battery-powered Crimping Tool Crimping Cable 1. Insert the properly assembled connector into the crimping head. 2. Pull the trigger to make the crimp.
-
Page 8: Maintenance
3. Charge the battery. Monthly Thoroughly clean all surfaces. Annually or After 10,000 Crimps Return the tool to an authorized Greenlee service center for inspection. 2. Use a nonflammable contact cleaner or pencil eraser to clean the electrical contacts on the battery and crimping tool. -
Page 9: Illustrations
EK210 Battery-powered Crimping Tool Illustrations—Main Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 10: Piston Pump
EK210 Battery-powered Crimping Tool Illustrations (cont’d) Pump Housing Unit, Relief Valve Unit, and Piston Pump Assembly Motor Assembly Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 11: Parts List
Disc housing ...1 50019627 Disc ...2 50019791 Screw ...2 50019740 Gear lube, 1.5 g ...1 50109332 Motor adapter ...1 50018965 Motor, electric ...1 Greenlee / A Textron Company EK210 Battery-powered Crimping Tool Part No. 50019228 50019155 50019163 50019120 50019112 50109367 50019716 50109898... - Page 12 Fax: Canada 800-435-0786 Fax: International +1-815-397-7070 Fax: +1-815-397-9247 4455 Boeing Drive • Rockford, IL 61109-2988 • USA • 815-397-7070 • An ISO 9001 Company Greenlee Textron Inc. is a subsidiary of Textron Inc. www.greenlee.com 800-451-2632 815-397-1865 800-524-2853 Printed in USA...
