Summary of Contents for Greenlee ESC85
- Page 1 INSTRUCTION MANUAL Serialnummer GATOR Plus ® ESC85 Battery-powered Cable Cutter Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. 52020651 REV 3 © 2008 Greenlee Textron Inc. 3/08...
-
Page 2: Table Of Contents
Replacement manuals are available upon request at no charge. All specifications are nominal and may change as design improvements occur. Greenlee Textron Inc. shall not be liable for damages resulting from misapplication or misuse of its products. GATOR is a trademark of Greenlee Textron Inc. -
Page 3: Important Safety Information
Failure to observe this warning could result in severe injury or death. Greenlee / A Textron Company ESC85 Battery-powered Cable Cutter • Electric shock hazard: The owner of this cutter must be certain that all users of this tool are trained... - Page 4 Store the tool in the case when not in use. Failure to observe these precautions may result in injury or property damage. Greenlee / A Textron Company ESC85 Battery-powered Cable Cutter Do not allow anything to contact the battery terminals.
-
Page 5: Identification
Maximum Cable Cutting Diameter ...85 mm (3.3") Cutting Cycles per Charge ...approximately 50 Battery Charging Voltage ... 12 V Charging Time ... 1 hour Greenlee / A Textron Company ESC85 Battery-powered Cable Cutter 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070 T 15 ®... -
Page 6: Operation
Protect the tool from rain and moisture. Water will damage the tool and battery. Failure to observe these precautions may result in injury or property damage. Greenlee / A Textron Company ESC85 Battery-powered Cable Cutter Charging the Battery Read the instructions supplied with the battery charger. -
Page 7: Maintenance
2. Check the oil level. 3. Oil the bolt joints. Annually or Every 8000 Cutting Cycles 1. Change the hydraulic oil. 2. Return the tool to an authorized Greenlee service center for inspection. Keep hands away from closing blades. Failure to observe this warning could result in severe injury or death. -
Page 8: Troubleshooting
Cutting blades stop during operation. Battery load display flashes constantly. Tool loses oil. Greenlee / A Textron Company ESC85 Battery-powered Cable Cutter Probable Cause Dirt, contaminants, etc., in ram area or wedged between the blades of tool. Tool battery contacts damaged. -
Page 9: Disassembly
(111). 14. Remove screws (100) and separate the gear housing/motor subassembly from the pump housing. Greenlee / A Textron Company ESC85 Battery-powered Cable Cutter Pump 1. Use a hooked tool to remove the reservoir O-ring (80). Gently tug it over the reservoir. -
Page 10: Assembly
Using a hooked tool, carefully slip the O-ring over the lip of the pump housing. 7. Insert the plug (76) into the reservoir. Greenlee / A Textron Company ESC85 Battery-powered Cable Cutter Main Components 1. Remove the protective plastic bag from the electronics subassembly. -
Page 11: Illustrations
ESC85 Battery-powered Cable Cutter Illustration Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 12 ESC85 Battery-powered Cable Cutter Illustration Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
- Page 13 ESC85 Battery-powered Cable Cutter Illustration Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 14: Parts List
52020639 50019210 52020638 52020646 50013459 50042203 50042211 50042076 Greenlee / A Textron Company ESC85 Battery-powered Cable Cutter Description Bushing LED ... 1 Circuit board, programmed ... 1 Decal, identification ... 1 Decal, warning ... 1 Decal, pinch hazard ... 1 Screw ... - Page 15 106 ** 107 ** 108 † 109 † 110 † 111 † Greenlee / A Textron Company ESC85 Battery-powered Cable Cutter Description Pump housing, reservoir assembly (includes items 70–83) Ring tie ... 1 Cable tie ... 1 Threaded bushing ... 1 O-ring ...
- Page 16 4455 Boeing Drive • Rockford, IL 61109-2988 • USA • 815-397-7070 An ISO 9001 Company www.greenlee.com 800-435-0786 Fax: 800-451-2632 815-397-7070 Fax: 815-397-1865 800-435-0786 Fax: 800-524-2853 Fax: +1-815-397-9247 • Greenlee Textron Inc. is a subsidiary of Textron Inc. Printed in USA...
