Gigabyte GA-6WXM7(-E) User Manual

6wxm7 series intel 810 socket 370 motherboard

Advertisement

Quick Links

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
Model Number:
GA-6WXM7
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
Dec. 3, 1999
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device ,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection against harmful interference in
residential
installations.
generates,
uses,
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
This
equipment
and
can
radiate
radio

Advertisement

Table of Contents
loading

Summary of Contents for Gigabyte GA-6WXM7(-E)

  • Page 1 DECLARATION OF CONFORMITY Per FCC Part 2 Section 2. 1077(a) Responsible Party Name: G.B.T. INC. Address: 18305 Valley Blvd., Suite#A LA Puent, CA 91744 Phone/Fax No: (818) 854-9338/ (818) 854-9339 hereby declares that the product Product Name: Mother Board Model Number: GA-6WXM7 Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),...
  • Page 2: Declaration Of Conformity

    Ausschlager Weg 41, 1F, 20537 Hamburg, Germany ( description of the apparatus, system, installation to which it refers) (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive EN 55011 Limits and methods of measurement of radio disturbance characteristics of industrial, scientific and medical (ISM high frequency equipment...
  • Page 3 6WXM7 Series Intel 810 Socket 370 Motherboard USER'S MANUAL INTEL 810 Socket 370 Processor MAINBOARD REV. 2.0 First Edition R-20-01-091201...
  • Page 5 How this manual is organized This manual is divided into the following sections: 1) Revision List 2) Item Checklist 3) Features 4) Hardware Setup 5) Performance & Block Diagram 6) Suspend to RAM & Dual BIOS 7) BIOS Setup 8) Appendix Manual revision information Product item list Product information &...
  • Page 6: Table Of Contents

    Revision History Item Checklist Summary of Features 6WXM7 Series Motherboard Layout Page Index for CPU Speed Setup / Connectors / Panel and Jumper Definition P.6 Performance List Block Diagram Suspend RAM Installation Introduce Dual BIOS (Optional) Memory Installation Page Index for BIOS Setup Appendix Table Of Content P.29...
  • Page 8: Revision History

    6WXM7 Series Motherboard Revision History Revision Revision Note Initial release of the 6WXM7 Series motherboard user’s manual. Initial release of the 6WXM7 Series motherboard user’s manual. The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein.
  • Page 9: Item Checklist

    Item Checklist Item Checklist þThe 6WXM7 Series Motherboard þCable for IDE / Floppy device þDiskettes or CD (IUCD) for motherboard utilities þInternal COM2 Cable (Optional) oInternal USB Cable oCable for SCSI device þ6WXM7 Series User’s Manual þInternal DFP and TV-Out Cable (Optional)
  • Page 10: Summary Of Features

    6WXM7 Series Motherboard Summary of Features Form factor Ÿ Motherboard Ÿ Ÿ Ÿ Chipset Intel 810 ,consisting of: Ÿ Ÿ Clock Generator Ÿ Memory Ÿ Ÿ Ÿ I/O Control Ÿ Slots Ÿ Ÿ Ÿ On-Board IDE Ÿ Ÿ On-Board Ÿ Peripherals Ÿ...
  • Page 11 PS/2 Connector Ÿ BIOS Ÿ Additional Features Ÿ Ÿ Ÿ Ÿ Ÿ Drivers & Utilities Ÿ Ÿ Ÿ Ÿ Ÿ PS/2 Keyboard interface and PS/2 Mouse interface Licensed AWARD BIOS, 4M bit FLASH ROM Internal/External Modem Wake up Keyboard Password Wake up System after AC back Support Dual BIOS Function (Optional) Support STR Function...
  • Page 12: 6Wxm7 Series Motherboard Layout

    6WXM7 Series Motherboard 6WXM7 Series Motherboard Layout PS/2 JP25 JP26 JP27 PGA 370 TV/DFP JP17 AC97 PCISLOT1 JP29 JP30 PCISLOT2 PCISLOT3 AU8810 PCISLOT4 JP28 PCISLOT5 PCISLOT6 ISA1 ATX Power JP31 GMCH 82810 6WXM7 JP11 JP32 82801 IT8888 IDE2 BAT1 JP23 Main BIOS JP33...
  • Page 13: Page Index For Cpu Speed Setup / Connectors / Panel And Jumper Definition

    Page Index for CPU Speed Setup / Connectors / Panel and Jumper Definition CPU Speed Setup Connectors COMA / COMB / VGA / LPT Port Game & Audio Port USB Connector TV/DFP PS/2 Keyboard & PS/2 Mouse Connector CPU Cooling FAN Power Connector Power / System Cooling FAN Power Connector ATX Power Front Panel USB Port...
  • Page 14 6WXM7 Series Motherboard JP21 (Top Block Lock) P.26...
  • Page 15 JP33 (FWH Write Protection) JP12 (Onboard Sound Function Selection) [Optional] JP24 (Buzzer Enable)[Optional] BAT 1 6WXM7 Series Motherboard Layout P.27 P.27 P.28 P.28...
  • Page 17: Cpu Speed Setup

    CPU Speed Setup The system bus frequency can be switched at 66MHz, 100MHz, 133MHz(For Intel 810E)(Optional) and Auto by adjusting JP11/JP32 (See Figure-1). The CPU Frequency is control by BIOS. The CPU speed must match with the frequency RATIO. It will cause system hanging up if the frequency RATIO is higher than that of CPU.
  • Page 18: Connectors

    6WXM7 Series Motherboard Connectors COM A / COM B / VGA / LPT Port LPT PORT COM A COM B Game & Audio Port GAME Port MIC In Line Out Line In...
  • Page 19: Usb Connector

    USB Connector TV/DFP : TV-Out / Digital Flat Panel Daughter card connector. Pin No. Definition USB V0 USB D0- USB D0+ USB V1 1 2 3 4 USB D1- USB D1+ RED LINE Connectors...
  • Page 20: Ps/2 Keyboard & Ps/2 Mouse Connector

    6WXM7 Series Motherboard PS/2 Keyboard & PS/2 Mouse Connector CPU Cooling FAN Power Connector PS/2 Mouse PS/2 Mouse/ Keyboard Pin No. PS/2 Keyboard Pin No. Definition Control +12V SENSE Definition Data VCC(+5V) Clock...
  • Page 21: Power / System Cooling Fan Power Connector

    Power Cooling FAN Power Connector System Cooling FAN Power Connector Pin No. Definition Control +12V SENSE Pin No. Definition Control +12V SENSE Connectors...
  • Page 22: Atx Power

    6WXM7 Series Motherboard ATX Power Front Panel USB Port Pin No. Definition 3,5,7,13, 15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB stand by+5V PS-ON(Soft On/Off) Pin No. Definition 1,4,5,10 3,7,9 USBP0+ USBP0-...
  • Page 23: Ir/Cir

    IR/CIR Floppy Port Pin No. 2,6,9 RED LINE Connectors Definition IRRX IRTX CIRRX KBVcc CIRTX...
  • Page 24: Ide1(Primary) , Ide2 (Secondary) Port

    6WXM7 Series Motherboard IDE1(Primary) , IDE2 (Secondary) Port J10 : Wake on LAN IDE 2 IDE 1 RED LINE Pin No. Definition +5V SB Signal...
  • Page 25: J11(Ring Power On)

    J11 : Ring Power On (Internal Modem Card Wake Up) J6 : CD Audio Line In (Optional) Pin No. Definition Signal Pin No. Definition CD-L CD-R Connectors...
  • Page 26: Jp8(Aux In) [Optional]

    6WXM7 Series Motherboard JP8 : AUX IN (Optional) JP7 : TEL : The connector is for Modem with internal voice connector (Optional) Pin No. Definition AUX-L AUX-R Pin No. Definition Signal-In Signal-Out...
  • Page 27: J13 (Smbus)

    JP6 : SPDIF(The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dobly digital decoder.)(Optional) J13 : SMBUS Pin No. Definition SPD OUT Pin No. Definition SMB CLK SMB DATA Connectors...
  • Page 28: Jp10 (Str Led Connector & Dimm Led)

    6WXM7 Series Motherboard JP10 : STR LED Connector & DIMM LED STR LED Connector External. RAM Indicator LED1...
  • Page 29: Panel And Jumper Definition

    Panel and Jumper Definition J9 : For 2X11 Pins Jumper GN (Green Switch) GD (Green LED) HD (IDE Hard Disk Active LED) SPK (Speaker Connector) RE (Reset Switch) P+P P (Power LED) PW (Soft Power Connector) Panel and Jumper Definition Open: Normal Operation Close: Entering Green Mode Pin 1: LED anode(+)
  • Page 30: Jp2 (Keyboard Power On)

    6WXM7 Series Motherboard JP2 : Keyboard Power On JP25 : USB Device Wake up Selection (If you want to use “USB KB Wake from S3” function, you have to set the BIOS setting “USB KB Wake from S3” enabled, and the jumper “JP25”...
  • Page 31: Jp26/Jp27 (Usb Port Selection)

    JP26/JP27 : USB Port Selection Front Panel USB Enable Back Panel USB Enable FPUSB JP26 1-2close JP27 1-2close JP31 : Over Voltage CPU Speed Up (Magic Booster) (When JP31 set “Open”, CPU Voltage is rising 10%) Panel and Jumper Definition BPUSB 2-3close 2-3close...
  • Page 32: Jp18 (Case Open)

    6WXM7 Series Motherboard JP18 : Case Open JP9 : Clear CMOS Function Pin No. Definition Signal Pin No. Definition 1-2 close Clear CMOS 2-3 close Normal (Default)
  • Page 33: Jp17 (Amr Selection) [Optional]

    JP17 : AMR Selection (Optional) JP1 : STR Function Selection Panel and Jumper Definition Pin No. Definition 1-2close AMR Secondary AC’97 Disabled 2-3close (Disabled Onboard CODEC) Pin No. Definition Close STR Enabled Open STR Disabled(Default)
  • Page 34: Jp29 & Jp30 (Quad Speaker) [Optional]

    6WXM7 Series Motherboard JP29 & JP30 : Quad Speaker (Optional) JP23 : Safe mode/Recovery/Normal Pin No. Definition 1-2 close Normal Sound 2-3 close Quad Speaker Pin No. Definition 1-2close Normal(Default) 2-3close Safe mode 1-2-3open Recovery...
  • Page 35: Jp19 (Timeout Reboot Function)

    JP19 : Timeout Reboot Function JP21 : Top Block Lock Panel and Jumper Definition Pin No. Definition Open Timeout Reboot Close No Reboot on Timeout (Default) Pin No. Definition Open TBL Lock Close Unlock (Default)
  • Page 36 6WXM7 Series Motherboard JP33 : FWH Write Protection JP28 : Onboard Sound Function Selection (Optional) Pin No. Definition Close Write Protect Open Normal (Default) Pin No. Definition Enabled Onboard Sound 1-2 close (Default) 2-3 close Disabled Onboard Sound...
  • Page 37 JP24 : Buzzer Enabled (Optional) BAT1 : Battery Panel and Jumper Definition Pin No. Definition Open Internal Buzzer Disabled Internal Buzzer Enabled Close (Default) + Danger of explosion if battery is incorrectly replaced. + Replace only with the same or equivalent type recommended by the manufacturer.
  • Page 38: Performance List

    6WXM7 Series Motherboard Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Intel Celeron Intel Coppermine 600MHz processor...
  • Page 39: Block Diagram

    Block Diagram Display Display Cache ATA66 IDE Channels 2 USB Ports COM Ports Winbond LPT Ports W83627 IR Floppy PS/2 INTEL Celeron 66/100/133 MHz Coppermine Host Bus 66/100/133MHz GMCH 82810E 82810DC100 82810 14.318/33/48/66 MHz Interface PCI Bus 33MHz 82801AA AC’97 Link AU8810 AC’97 Game Port...
  • Page 40: Suspend Ram Installation

    6WXM7 Series Motherboard Suspend to RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 41 Step 2: (If you want to use STR Function, please set jumper JP1 Closed.) Step 3 : Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup. Select the item “POWER MANAGEMENT SETUP”, then select “ACPI Suspend Type: S3(Suspend to RAM)”.
  • Page 42 6WXM7 Series Motherboard A.3 How to put your system into STR mode? There are two ways to accomplish this: 1. Choose the “Stand by” item in the “Shut Down Windows” area. Press the “Start” button and then select “Shut Down” B.
  • Page 43 Suspend to RAM Installation...
  • Page 44 6WXM7 Series Motherboard Define the system ”power on” button to initiate STR sleep mode: Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 45 C. Select the “Advanced” tab and “Standby” mode in Power Buttons. Step 4: Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button.. A.4 How to recover from the STR sleep mode? There are seven ways to “wake up”...
  • Page 46 6WXM7 Series Motherboard A.5 Notices : In order for STR to function properly, several hardware and software requirements must be satisfied: A. Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). B.
  • Page 48: Introduce Dual Bios (Optional)

    6WXM7 Series Motherboard Introduce Dual BIOS (Optional) What is Dual BIOS Technology? Dual BIOS means that there are two system BIOS (ROM) on the motherboard, one is the Main BIOS and the other is Backup BIOS. Under the normal circumstances, the system works on the Main BIOS.
  • Page 49 Dual BIOS Utility V6.60.g.01K (C) 1999, Gigabyte Technology Co., LTD. Wide Range Protection Halt On BIOS Defects Auto Recovery Boot From BIOS Recovery F3: Load Default F7: Save And Restart Use <Space> key to toggle setup b. Dual BIOS Utility c.
  • Page 50 6WXM7 Series Motherboard Halt On BIOS Defects : Disabled(Default), Enabled If the BIOS occurs a checksum error or the Main BIOS occurs a WIDE RANGE PROTECTION error and Halt On BIOS Defects set to Enable, the PC will show messages on the boot screen, and the system will pause and wait for the user’s instruction.
  • Page 51 Introduce Dual BIOS DualBIOS Technology FAQ GIGABYTE Technology is pleased to introduce DualBIOS technology, a hot spare for your system BIOS. This newest “Value-added” feature, in a long series of innovations from GIGABYTE, is available on GA-6WXM7 Series motherboard. Future GIGABYTE motherboards will also incorporate this innovation.
  • Page 52 6WXM7 Series Motherboard I. Q: What is DualBIOS technology? Answer: DualBIOS technology is a patented technology from Giga-Byte Technology. The concept of this technology is based on the redundancy and fault tolerance theory. DualBIOS simply means there are two system BIOSes (ROM) integrated onto the motherboard. One is a main BIOS, and the other is a backup BIOS.
  • Page 53 III. Q: How does DualBIOS Answer: 1. DualBIOS technology provides a wide range of protection during the boot up procedure. It protects your BIOS during system POST, ESCD update, and even all the way to PNP detection/assignment. 2. DualBIOS provides automatic recovery for the BIOS. When the first BIOS used during boot up does not complete or if a BIOS checksum error occurs, boot-up is still possible.
  • Page 54 6WXM7 Series Motherboard 2. During or after a BIOS upgrade, if DualBIOS backup BIOS will take over the boot-up process automatically. Moreover, it will verify the main and backup BIOS checksums when booting-up. DualBIOS checksum of the main and backup BIOS while the system is powered on to guarantee your BIOS operates properly.
  • Page 55: Memory Installation

    Memory Installation The motherboard has 4 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
