Gigabyte GS-SR101 User Manual

Socket 370 dual processors motherboard
Hide thumbs Also See for GS-SR101:

Advertisement

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
GA-6VXDR7
Model Number:
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
Nov. 22, 2000
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection
against
harmful
residential
installations.
generates,
uses,
and
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
interference
in
This
equipment
can
radiate
radio

Advertisement

Table of Contents
loading

Summary of Contents for Gigabyte GS-SR101

  • Page 1 FCC Compliance Statement: This equipment has been tested and found to DECLARATION OF CONFORMITY Per FCC Part 2 Section 2. 1077(a) comply with limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These Responsible Party Name: G.B.T. INC. limits are designed to provide reasonable Address: 18305 Valley Blvd., Suite#A LA Puent, CA 91744...
  • Page 2: Declaration Of Conformity

    Declaration of Conformity We, Manufacturer/Importer G.B.T. Technology Träding GMbH Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive EN 55011 Limits and methods of measurement...
  • Page 3 6VXDR7 Socket 370 Dual Processors Motherboard USER'S MANUAL Socket 370 Dual Processors Motherboard REV. 1.1 Second Edition R-11-02-001123...
  • Page 5 How This Manual Is Organized This manual is divided into the following sections: 1) Revision History 2) Item Checklist 3) Features 4) Hardware Setup 5) Performance & Block Diagram 6) Dual BIOS 7) BIOS Setup 8) Appendix Manual revision information Product item list Product information &...
  • Page 7: Table Of Contents

    Table Of Content Revision History Item Checklist Summary of Features 6VXDR7 Motherboard Layout Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition Performance List Block Diagram Dual BIOS Introduction Advanced Networking Services for Windows NT* 4 and Windows 2000 (Teaming) Memory Installation Page Index for BIOS Setup Appendix...
  • Page 8: Revision History

    6VXDR7 Motherboard Revision History Revision Revision Note Initial release of the 6VXDR7 motherboard user’s manual. Second release of the 6VXDR7 motherboard user’s manual. The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein. Third-party brands and names are the property of their respective owners.
  • Page 9: Item Checklist

    Item Checklist Item Checklist The 6VXDR7 motherboard Cable for IDE / floppy device Diskettes or CD (Driver CD) for motherboard driver & utility 6VXDR7 user’s manual...
  • Page 10: Summary Of Features

    6VXDR7 Motherboard Summary Of Features Form Factor 30.5 cm x 24.8 cm ATX size form factor, 6 layers PCB. 2 Socket 370 processor Intel Pentium L2 cache in CPU (Depend on CPU) Chipset VT82C694X (VIA Apollo Pro 133A) VT82C686A Clock Generator ICS 9248AF-63 100/133 MHz system bus speeds (PCI 33MHz) Memory...
  • Page 11 Hardware Monitor CPU / Power / System fan revolution detect CPU / Power / System temperature detect System voltage detect CPU overheat shutdown detect PS/2 Connector ® PS/2 BIOS Licensed AMI BIOS, 2M bits flash ROM Support Dual BIOS On-Board VGA Onboard AGP ATI RAGE XL 2X On-Board LAN Onboard INTEL 82559 Dual Ethernet...
  • Page 12: 6Vxdr7 Motherboard Layout

    6VXDR7 Motherboard 6VXDR7 Motherboard Layout PS/2 ATX Power PGA 370 CPU 1 PCI1 Main BIOS Back BIOS PGA 370 CPU 2 VT82C694X 6VXDR7 Rage VT82C686A BAT1 USB2 JP10...
  • Page 13: Page Index For Cpu Speed Setup/Connectors/Panel And Jumper Definition

    Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition CPU Speed Setup Connectors ATX Power COM 1 / VGA / LPT Port Floppy Port IDE 1(Primary) / IDE 2(Secondary) Port / IDE3,IDE4 Port J1 (Wake On LAN) J3 (Ring Power On) J4 (IR) J13 CPU2 FAN J14 Panel FAN...
  • Page 14: Cpu Speed Setup

    6VXDR7 Motherboard CPU Speed Setup The system bus speed is depended on the DIP switch (SW1) selection to set up the CPU speed for 500MHz – 1GHz processor. The CPU speed must match with the frequency ratio. It will cause system hanging up if the frequency ratio is higher than that of CPU.
  • Page 15 ® Pentium !!! 500/100MHz FSB ® Pentium !!! 667/133MHz FSB ® 2. Pentium !!! 550/100MHz FSB ® Pentium !!! 733/133MHz FSB 3. Pentium ® !!! 600/100MHz FSB ® Pentium !!! 800/133MHz FSB CPU Speed Setup You can change the DIP switch (SW1) selection to set up the CPU Speed.
  • Page 16 6VXDR7 Motherboard 4. Pentium ® !!! 650/100MHz FSB ® Pentium !!! 866/133MHz FSB 5. Pentium ® !!! 700/100MHz FSB ® Pentium !!! 933/133MHz FSB 6. Pentium ® !!! 750/100MHz FSB ® Pentium !!! 1GHz/133MHz FSB...
  • Page 17 7. Pentium ® !!! 800/100MHz FSB ® 8. Pentium !!! 850/100MHz FSB ® 9. Pentium !!! 533/133MHz FSB ® 10. Pentium !!! 600/133MHz FSB CPU Speed Setup...
  • Page 18: Connectors

    6VXDR7 Motherboard Connectors COM 1 / VGA / LPT Port USB 1 Connector LPT PORT COM 1 Pin No. Definition USB V0 USB D0- USB D0+ USB V1 USB D1- 5 6 7 8 USB D1+...
  • Page 19 PS/2 Keyboard & PS/2 Mouse Connector PS/2 Keyboard LAN Connector PS/2 PS/2 Mouse Mouse / Keyboard Pin No. Definition Data VCC(+5V) Clock LAN2 LAN1 (LAN Active LED) 1 – Yellow LED (LAN Active LED) 2 – Green LED (LAN Link LED) Connectors...
  • Page 20 6VXDR7 Motherboard J13 : CPU Fan 1 J15 : CPU Fan 2 Pin No. Definition Control +12V SENSE Pin No. Definition Control +12V SENSE...
  • Page 21 J16 : Power Fan 1 J20 : Power Fan 2 Connectors Pin No. Definition Control +12V Pin No. Definition Control +12V...
  • Page 22: Atx Power

    6VXDR7 Motherboard J14 : Panel Fan ATX Power Pin No. Definition Control +12V Pin No. Definition 3,5,7,13, 15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB stand by+5V PS-ON(Soft On/Off)
  • Page 23: Floppy Port

    Connectors Floppy Port Red Line FDD1 IDE1 (Primary), IDE2 (Secondary), IDE3/IDE4(ATA100 or IDE RAID) Red Line IDE1 IDE2 IDE3 IDE4...
  • Page 24: J1 (Wake On Lan)

    6VXDR7 Motherboard J3 : Ring Power On (Internal Modem Card Wake Up) J1 : Wake On LAN Pin No. Definition Signal Pin No. Definition +5V SB Signal...
  • Page 25: J4 (Ir)

    J4 : IR USB 2 Connector Connectors Pin No. Definition VCC (+5V) IR Data Input IR Data Output Pin No. Definition 1,10 USB D2- USB D2+ USB D3+ USB D3-...
  • Page 26: Panel And Jumper Definition

    6VXDR7 Motherboard Panel And Jumper Definition J2 : 2x11 Pins Jumper GN (Green Switch) GD (Green LED) HD (IDE Hard Disk Active LED) SPK (Speaker Connector) RE (Reset Switch) P+P−P−(Power LED) PW (Soft Power Connector) S P K P − P − P+ Open: Normal Operation Close: Entering Green Mode Pin 1: LED anode(+)
  • Page 27: Jp1 (Clear Cmos Function)

    JP1 : Clear CMOS Function JP7 : BIOS Flash ROM Write Protect (Optional) Panel and Jumper Definition Pin No. Definition 1-2 Close Normal (Default) 2-3 Close Clear CMOS Pin No. Definition Close BIOS Write Disabled Open Normal (Default) Please set Jumper JP7 to “Open” to enabled BIOS write function when you update new BIOS or new device.
  • Page 28: Jp3 (Usb Device Wake Up Selection)

    6VXDR7 Motherboard JP3 : USB device Wake up Selection (Optional) JP5 : Onboard LAN1 Selection (Optional) Pin No. Definition 1-2 close Normal (Default) Enabled USB Device 2-3 close Wake up Pin No. Definition Onboard LAN1 1-2 close Enabled Onboard LAN1 2-3 close Disabled...
  • Page 29: Jp6 (Onboard Lan2 Selection)

    JP6 : Onboard LAN2 Selection (Optional) JP4 : Onboard AGP Selection Panel and Jumper Definition Pin No. Definition Onboard LAN2 1-2 close Enabled Onboard LAN2 2-3 close Disabled Pin No. Definition Onboard AGP Open Disabled Onboard AGP Close Enabled...
  • Page 30: Jp10 (Ide Raid Selection)

    6VXDR7 Motherboard JP2 : Case Open JP10 : IDE RAID Selection Pin No. Definition Short Open Open Close Pin No. Definition 1-2 close IDE Raid Disabled 2-3 close IDE Raid Enabled...
  • Page 31: Bat1 (Battery)

    J19 : Panel LED Connector BAT1 : Battery Panel and Jumper Definition Pin No. Definition CPU FAN1 CPU FAN2 SYSTEM FAN SYSTEM EVENT LAN1 Active LAN1 Link 11-12 LAN1 Speed LAN2 Active LAN2 Link 15-16 LAN2 Speed 17-18 Power LED 19-20 Power Button CAUTION...
  • Page 32: Performance List

    128MB*2 (MT 48LC8M8A2 TG-75B) DRAM • 256KB include in CPU CACHE SIZE • Onboard ATI Rage XL DISPLAY • Onboard Promise RAID (IBM DTLA 307060) STORAGE • Windows NT O.S. • Display Driver at 1024x768x16bitx75MHz DRIVER Processor Winbench99 CPU mark 99...
  • Page 33: Block Diagram

    Block Diagram PGA370 AGPCLK (66MHz) Ati Rage XL 2X AGP AGP PCI Bus 33MHz Promise LAN x 2 82559 PDC20265 1 PCI PCI (33MHz) RAID /ATA 100 IDE Port Channels AGPCLK (66MHz) PCI (33MHz) 48MHz 14.318MHz 33MHz Block Diagram CPUCLK (100/133MHz) PGA370 System Bus 100/133MHz 3.3V SDRAM...
  • Page 34: Dual Bios Introduction

    6VXDR7 Motherboard Dual BIOS Introduction Introduce Dual BIOS What is Dual BIOS Technology? Dual BIOS means that there are two system BIOS (ROM) on the motherboard, one is the Main BIOS and the other is Backup BIOS. Under the normal circumstances, the system works on the Main BIOS.
  • Page 35 b. AMI Dual BIOS Flash ROM Programming Utility AMI Dual BIOS Flash ROM Programming Utility V1.01 Boot From……………………….. Main BIOS Main ROM Type………………… SST 39SF020 Backup ROM Type……………… SST 39SF020 Wide Range Protection Boot From Auto Recovery Halt On Error Copy Main ROM Data to Backup Load Default Settings Save Settings to CMOS...
  • Page 36 6VXDR7 Motherboard Boot From : Main BIOS (Default), Backup BIOS Status 1: The user can set to boot from main BIOS or Backup BIOS. Auto Recovery : Enabled(Default), Disabled When one of the Main BIOS or Backup BIOS occurs checksum failure, the working BIOS will automatically recover the BIOS of checksum failure.
  • Page 37 Dual BIOS Introduction DualBIOS Technology FAQ GIGABYTE Technology is pleased to introduce DualBIOS technology, a hot spare for your system BIOS. This newness “Value-added” feature, in a long of innovations from GIGABYTE, is available on GA-6VXDR7 motherboard. Future GIGABYTE motherboards will also incorporate this innovation.
  • Page 38 6VXDR7 Motherboard I. Q: What is DualBIOS technology? Answer: DualBIOS technology is a patented technology from Giga-Byte Technology. The concept of this technology is based on the redundancy and fault tolerance theory. DualBIOS simply means there are two system BIOSes (ROM) integrated onto the motherboard. One is a main BIOS, and the other is a backup BIOS.
  • Page 39 III. Q: How does DualBIOS technology work? Answer: 1. DualBIOS technology provides a wide range of protection during the boot up procedure. It protects your BIOS during system POST, ESCD update, and even all the way to PNP detection/assignment. 2. DualBIOS provides automatic recovery for the BIOS.
  • Page 40 Another advantage you gain from Giga-Byte’s DualBIOS ability to upgrade from dual 2 Mbit BIOS to dual 4 Mbit BIOS in the future if extra BIOS storage is need. detects that the main BIOS is corrupt, the technology examines the...
  • Page 41: Advanced Networking Services For Windows Nt* 4 And Windows

    Advanced Networking Services for Windows NT* 4 and Windows 2000 (Teaming) Please make sure the Intel LAN Adapter teaming driver Install complete. refer to page 74) 1. Intel LAN Adapter Teaming Adapter Teaming Installation Notes for the PRO/100 S Server Adapter Under Windows NT 4.0 and Windows 2000.
  • Page 42 6VXDR7 Motherboard 2. Adapter Fault Tolerance (AFT) 2.1 OverView A method of safeguarding the network link to the server switch or network service using transparent backup links. Adapter Fault Tolerance (AFT) requires two adapters and an intelligent software agent that continuously monitors both links. If any component of one link fails, the redundant link takes over within seconds—typically, without users (connected via a hub or switch) even noticing the exchange.
  • Page 43 3. Adaptive Load Balancing (ALB) 3.1 Overview Also known as asymmetric port aggregation—is a method of ensuring consistent high server throughput and transparent backup connections by using multiple network interface cards and balancing the data transmissions across them. As many as four Intel® server adapters, connected to a switch, can be configured to work together as a "team"...
  • Page 44: General Instructions

    6VXDR7 Motherboard 4. General Instructions 4.1 Perform Teaming In Windows NT4.0 Or Windows 2000 Setup Intel PROSet II. Then, double-click on the Intel (R) PROSet II icon in the Control Panel will launch the PROSet utility. 2. Create a new team .
  • Page 45 Advanced Networking Services 3. At the Teaming Wizard dialog, select the type of team you want to create and click Next. 4. Add a check in the checkbox for each adapter you want as a part of the team and click Next.
  • Page 46 6VXDR7 Motherboard 5. Click OK to close PROSet. II You should notice a new listing in the Network control panel, which is the team you have created. 6. After the team created, a Intel® Advanced Network Services Virtual Adapter will appear on Network in the Control Panel.
  • Page 47: Memory Installation

    Memory Installation The motherboard has 4 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
  • Page 48: Page Index For Bios Setup

    6VXDR7 Motherboard Page Index for BIOS Setup The Main Menu Standard CMOS Setup BIOS Features Setup Chipset Features Setup Power Management Setup PNP/ PCI Configuration Load BIOS Defaults Load Setup Defaults Integrated Peripherals Hardware Monitor Supervisor Password / User Password IDE HDD Auto Detection Save &...
  • Page 49 BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Power ON the computer and press <Del>...
  • Page 50: Getting Help

    6VXDR7 Motherboard GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 51 • Chipset Features Setup This setup page includes all the items of chipset special features. • Power Management Setup This setup page includes all the items of Green function features. • PnP/PCI Configurations This setup page includes all the configurations of PCI & PnP ISA resources. •...
  • Page 52: Standard Cmos Setup

    6VXDR7 Motherboard Standard CMOS Setup The items in Standard CMOS Features Menu (Figure 2) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. AMIBIOS SETUP –...
  • Page 53 • Time The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. • Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer.
  • Page 54 6VXDR7 Motherboard • Boot Sector Virus Protection If it is set to enable, the category will flash on the screen when there is any attempt to write to the boot sector or partition table of the hard disk drive. The system will halt and the following error message will appear in the mean time.
  • Page 55: Bios Features Setup

    BIOS Features Setup AMIBIOS SETUP – BIOS FEATURES CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved 1st Boot Device :Floppy 2nd Boot Device :SCSI 3rd Boot Device :CDROM S.M.A.R.T for Hard Disks :Disabled BootUp Num-Lock Floppy Drive Seek :Enabled Password Check :Setup...
  • Page 56 6VXDR7 Motherboard • Boot Up Num-Lock Keypad is number keys. (Default Value) Keypad is arrow keys. • Floppy Drive Seek During POST, BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. 360 type is 40 tracks while 720 , 1.2 and 1.44 are all 80 tracks. Enabled BIOS searches for floppy disk drive to determine if it is 40 or 80 tracks.
  • Page 57: Chipset Features Setup

    Chipset Features Setup AMIBIOS SETUP –CHIPSET FEATURE CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved *** DRAM Timing *** Top Performance :Disabled SDRAM Timing by SPD :Disabled SDRAM CAS# Latency :Auto CPU/DRAM Frequency :Auto C2P Concurrency & Master :Enabled DRAM Integrity Mode :Disabled...
  • Page 58 6VXDR7 Motherboard 2. System Bus Speed: 133MHz Auto Set CPU/DRAM Frequency to Auto. (Default Value) 133/100MHz Set CPU/DRAM Frequency is 133/100MHz. 133/133MHz Set CPU/DRAM Frequency is 133/133MHz. • C2P Concurrency & Master Enabled Enabled C2P Concurrency & Master. (Default Value) Disabled Disabled C2P Concurrency &...
  • Page 59: Power Management Setup

    Power Management Setup AMIBIOS SETUP –POWER MANAGEMENT SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved USB Wakeup From S4~S5 :Disabled Video Power Down Mode :Stand By Hard Disk Power Down Mode :Stand By Suspend Time Out(Minute) :Disabled Display Activity :Ignore IRQ3...
  • Page 60 6VXDR7 Motherboard • Suspend Time Out (Minute.) Disabled Disabled Suspend Time Out Function. (Default Value) Enabled Suspend Time Out after 1min. Enabled Suspend Time Out after 2min. Enabled Suspend Time Out after 4min. Enabled Suspend Time Out after 8min. Enabled Suspend Time Out after 10min. Enabled Suspend Time Out after 20min.
  • Page 61 • Modem Ring On/Wake On Lan Disabled Disabled Modem Ring On/Wake On Lan. Enabled Enabled Modem Ring On/Wake On Lan. (Default Value) • PME Event Wake up Disabled Disabled PME Event Wake up function. Enabled Enabled PME Event Wake up function. (Default Value) •...
  • Page 62: Pnp/Pci Configuration

    6VXDR7 Motherboard PnP/PCI Configuration AMIBIOS SETUP –PNP/PCI CONFIGURATION SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Plug and Play Aware O/S Reset Configuration Data VGA Boot From :AGP PCI VGA Palette Snoop :Disabled DMA Channel 0 :PnP DMA Channel 1 :PnP DMA Channel 3...
  • Page 63 • DMA Channel (0,1,3,5,6,7) The resource is used by PnP device. ISA / EISA The resource is used by ISA / EISA device (PCI or ISA). • IRQ (3,4,5,7, 9,10,11,14,15) PCI/PnP The resource is used by PCI/PnP device. ISA / EISA The resource is used by ISA / EISA device (PCI or ISA).
  • Page 64: Load Bios Defaults

    6VXDR7 Motherboard Load BIOS Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION Load BIOS Defaults (Y/N)? N LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ↑↓→←...
  • Page 65: Load Setup Defaults

    Load Setup Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP Load SETUP Defaults (Y/N)? N PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ↑↓→←...
  • Page 66: Integrated Peripherals

    6VXDR7 Motherboard Integrated Peripherals AMIBIOS SETUP –INTEGRATED PERIPHERAL ( C ) 1999 American Megatrends, Inc. All Rights Reserved OnBoard IDE :Both OnBoard FDC :Auto OnBoard Serial Port 1 :Auto Onboard IR :Disanled IR Mode :N/A Duplex Mode :N/A OnBoard Parallel Port :Auto Parallel Port Mode :ECP...
  • Page 67 • Onboard IR (This item allows you to determine which Serial Port 2 Mode of onboard I/O chip) Disabled Disable onboard IR function. (Default Value) Enabled Enable onboard IR function. • IR Mode (This item allows you to determine which Serial Port 2 Mode of onboard I/O chip) ASK IR Set onboard I/O chip Serial Port 2 to ASK IR Mode.
  • Page 68 6VXDR7 Motherboard • Parallel Port IRQ Set Parallel Port IRQ is 7. Auto Set Auto to parallel Port IRQ DMA Channel. (Default Value) Set Parallel Port IRQ is 5. • OnBoard AC’97 Audio Auto Set OnBoard AC’97 Audio to Auto. (Default Value) Disabled Disabled OnBoard AC’97 Audio.
  • Page 69: Hardware Monitor

    Hardware Monitor AMIBIOS SETUP –HARDWARE MONITOR ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Shut Down Temp. :Disabled CPU Temp. Alarm :Enabled CPU1 Fan Fail Alarm :Yes CPU2 Fan Fail Alarm :Yes Reset Case Open Status Case Status :Opened CPU2 Present :OK!
  • Page 70 6VXDR7 Motherboard • Reset Case Open Status • Case Status If the case is closed, “Case Status” will show “Closed”. If the case have been opened, “Case Status” will show “Closed”. If you want to reset “Case Status” value, set “Reset Case Open Status” to “Yes”...
  • Page 71 Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP...
  • Page 72: Ide Hdd Auto Detection

    6VXDR7 Motherboard IDE HDD AUTO Detection AMIBIOS SETUP – STANDARD CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yyyy) : Tue Feb 17, 2000 Time (hh/mm/ss) : 10:36:24 TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE Pri Master :Auto Pri Slave...
  • Page 73: Save & Exit Setup

    Save & Exit Setup AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP SAVE to CMOS and EXIT(Y/N)? Y PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ↑↓→←...
  • Page 74: Exit Without Saving

    6VXDR7 Motherboard Exit Without Saving AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP Quit without saving (Y/N) ? N PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ↑↓→←...
  • Page 75: Appendix

    Appendix Appendix A : VIA Chipsets Driver Installation A.VIA 4 in 1 Service Pack Utility: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “VIA 4in 1 Service Pack Utility”...
  • Page 76 6VXDR7 Motherboard 6.Click “Next”. 9.Click “Next”. 7.Click “Next”. 10.Click “Finish” to restart computer. (10)
  • Page 77 Appendix B : ATi VGA Driver Installation Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “ATI VGA Driver ”. 2.Click “Next”.
  • Page 78 6VXDR7 Motherboard Appendix C : Intel 82559 LAN Driver Installation Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “Control Panel”. 3.Click here.
  • Page 79 8.Type”D:\82559v40” 9.Click Next. 11.Click “Next”. Appendix 10.Click “Next”. 12.Click “Finish” to restart computer. (10)
  • Page 80 6VXDR7 Motherboard Appendix D: Promise PCI Device Installation A. FastTrak Utility Installation: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “Promise FastTrak Utility”.
  • Page 81 7.Click “Next” 9.Click “Next” B. Promise RAID Driver Installation: If you want to realize the setup information in detail, please refer to the “Installing Drivers section of the RAID Manual” for setting your system completely. Appendix 8.Click “Next” 10.Click “Finish” to restart. (10)
  • Page 82 6VXDR7 Motherboard Appendix E: Intel 82559 LAN Utility Installation Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 2.Click here. 1.Click “Intel 82559 LAN Utility”. 3.Click “Install”.
  • Page 83 Appendix F: BIOS Flash Procedure BIOS update procedure: If your OS is Win9X, we recommend that you used Gigabyte @BIOS Program to flash BIOS. Click “Tool” . Click “@BIOS Writer v1.05” Click “ ” . Methods and steps : I. Update BIOS through Internet a.
  • Page 84 In method I, if the BIOS file you need cannot be found in @BIOS server, please go onto Gigabyte's web site for downloading and updating it according to method II. d. Please note that any intercorruption during updating will cause system unbooted...
  • Page 85 Format a bootable system floppy diskette by the command “format a:/s” in command mode. Visit the Gigabyte website at http:// need and download it to your bootable floppy diskette. Insert the bootable diskette containing the BIOS file into the floppy diskette driver.
  • Page 86 6VXDR7 Motherboard Appendix G: Acronyms Acronyms Meaning ACPI Advanced Configuration and Power Interface Advanced Power Management Accelerated Graphics Port Audio Modem Riser Audio Communication Riser BIOS Basic Input / Output System Central Processing Unit CMOS Complementary Metal Oxide Semiconductor CRIMM Continuity RIMM Communication and Networking Riser Direct Memory Access...
  • Page 87 Acronyms Meaning Original Equipment Manufacturer PCI A.G.P. Controller POST Power-On Self Test Peripheral Component Interconnect RIMM Rambus in-line Memory Module Special Circumstance Instructions SECC Single Edge Contact Cartridge SRAM Static Random Access Memory Symmetric Multi-Processing System Management Interrupt Universal Serial Bus Voltage ID Appendix...
