FURUNO
5. ENVIRONMENTAL CONDITION
Category of unit
Ambient Temperature
Relative Humidity
Waterproofing
Vibration
Motion
6. COATING COLOR
Antenna Unit
Communication Unit
ISDN Handset
SP-2
Antenna unit: To be installed in a Exposed area
Others: To be installed in a protected area
Complies with Inmarsat SDM and IEC 60945 (Ed.4)
Antenna unit:
Communication unit: -15°C to +55°C
Handset:
95% at 40°C (Inmarsat SDM 95 & IEC 60945)
Complies with IEC 60529;
Antenna Unit: IPX6
Communication Unit: IPX0
Handset: IPX0
Complies with IEC 60945
● 2 - 5 Hz and up to 13.2 Hz with an excursion of ±1 mm ±10 %
2
(7 m/s maximum acceleration at 13.2 Hz)
● 13.2 - 100 Hz with a constant maximum acceleration of
2
7 m/s
Complies with Inmarsat SDM
ADU: Frequency 4-10 Hz: Max. vibration 2.54 mm
Frequency 10-15 Hz: Max. vibration 0.76 mm
Frequency 15-25 Hz: Max. vibration 0.40 mm
Frequency 25-33 Hz: Max. vibration 0.23 mm
BDU: Frequency 4-15 Hz: Max. vibration 0.76 mm
Frequency 15-25 Hz: Max. vibration 0.40 mm
Frequency 25-33 Hz: Max. vibration 0.23 mm
Frequency 33-40 Hz: Max. vibration 0.13 mm
Frequency 40-50 Hz: Max. vibration 0.07 mm
Roll: ± 30°/8s, Pitch: ± 10°/6s, Yaw: ± 8°/50s, Surge: ± 0.2G,
Sway: ± 0.2G, Heave: ± 0.5G, Rotation: 6°/s, Speed: 30 kt
Munsell N9.5
Munsell N1.0
Munsell N1.0
-25°C to +50°C
-15°C to +55°C
FELCOM 50
