- Page 1 LevelOne Installation Guide FCS-4020 Day & Night Speed Dome Network Camera Ver 1.0...
- Page 2 Warning Before Installation Power off the Network Camera as Refer to your user’s manual for the soon as smoke or unusual odors are operating temperature. detected. Contact your distributor in the event of occurrence. Do not touch the Network Camera Do not disassemble the Network during a lightning storm.
-
Page 3: Package Contents
Package Contents FCS-4020 Black Cover / Dome Cover Wall Mount Bracket Power Adapter Silica Gel / Metal Ring O-ring and Screws / Alignment Sticker Quick Installation Guide RJ45 Female/Female Coupler Warranty Card Software CD... -
Page 4: Physical Description
Physical Description Inner View SD Card Slot Status LED Reset Button Lens Outer View General I/O Terminal Block Ethernet 10/100 RJ45 Plug Audio Out (green) Microphone In (pink) Power Cord Socket (black) Ground... - Page 5 Hardware Installation Mounting the Network Camera 1. Attach the alignment sticker to the wall. 2. Drill four pilot holes into the wall. 3. Attach the black cover to the Network Camera using the supplied four black screws. 4. Stick the supplied two pieces of silica gel symmetrically to the inner side of the dome cover.
-
Page 6: Network Deployment
Network Deployment 1. If you have external devices such as sensors and alarms, connect them to the general I/O terminal block. G N D : Ground D I 4 : Digital Input D I 3 : Digital Input 2. Use the supplied RJ45 female/female D I 2 : Digital Input coupler to connect the Network Camera D I 1 : Digital Input... -
Page 7: Assigning Ip Address
1. Install "Installation Wizard " from the Software Utility directory on the software CD. 2. The program will search for LevelOne Network Cameras on the same LAN. 3. After searching, the main installer window will pop up. Click on the MAC that matches the one labeled on the side of the camera lens or S/N number on the label of carton to connect the Internet Explorer to the Network Camera. -
Page 8: Ready To Use
Ready to Use 1. Access the Network Camera from the Internet. 2. Retrieve live video through web browsers or recording software. For further setup, please refer to the user's manual on the software CD.
