DIGITAL CAMERA
Instruction Manual
Thank you for purchasing our digital camera. Before you start to use your new camera, please
read these instructions carefully to enjoy optimum performance and a longer service life.
Be sure you have read and understood the contents of "9. SAFETY PRECAUTIONS", before using
this product. Keep these instructions available for future reference.
We recommend that you take test shots to get accustomed to your camera before taking important
photographs.
The screen and camera illustrations shown in this manual were produced during the development
stages and may differ from the actual product.
If there are additions and/or modifications of functions due to firmware update for the camera, the
contents will differ. For the latest information, please visit our website.
Table of Contents
Quick task index
1.
Preparation
2.
Shooting
3.
Playback
4.
Menu functions
Connecting the camera to a
5.
smartphone
Connecting the camera to a
6.
computer
7.
Cautions
8.
Information
9.
SAFETY PRECAUTIONS
Model No.: IM024

Advertisement

Table of Contents
loading

Related Manuals for Olympus Pen E-P7

Summary of Contents for Olympus Pen E-P7

  • Page 1 Table of Contents Quick task index Preparation DIGITAL CAMERA Shooting Playback Instruction Manual Menu functions Connecting the camera to a smartphone Connecting the camera to a computer Cautions Information SAFETY PRECAUTIONS Model No.: IM024 Thank you for purchasing our digital camera. Before you start to use your new camera, please read these instructions carefully to enjoy optimum performance and a longer service life.

  • Page 2: Before You Begin

    Be prepared to provide the camera serial number when downloading the software. https://support.olympus-imaging.com/owdownload/ OLYMPUS Image Share (OI.Share) You can load images in the camera to a smartphone. You can also operate the camera remotely and take pictures from a smartphone.

  • Page 3: Product Manuals

    Manual can be downloaded from our website or directly using the Playback Instruction Manual Menu functions Connecting the camera to a smartphone “OLYMPUS Image Share” (OI.Share) smartphone app. Connecting the camera to a computer Cautions Information SAFETY PRECAUTIONS Model No.: IM024 Thank you for purchasing our digital camera.

  • Page 4: Table Of Contents

    Table of Contents Switching Displays with Before You Begin the u (Shortcut) Button ...33 Letting the camera choose Product Manuals aperture and shutter speed (Program mode) ......35 Quick task index Choosing aperture (Aperture Priority mode) ....37 Names of parts Choosing shutter speed (Shutter Priority mode) ....39 Preparation Choosing aperture and shutter...
  • Page 5 Shooting a Panorama ....66 Shooting without the vibration caused by shutter button [Keystone Compensation] ..67 operations (Anti-Shock r) ..88 [AE Bracketing]: Varying Exposure The Electronic Shutter over a Series of Shots ....68 (Silent s) ........88 [Focus Bracketing]: Calling shooting options ...89 Varying Focus Distance over a Series of Shots ......69 Choosing a focus mode...
  • Page 6 Adjusting the tone of monochrome Selecting Multiple Pictures pictures (0, Erase Selected, Share (Monochrome Color)....109 Order Selected) ......122 Adjusting i-Enhance effects Creating a print order (Effect) ........110 (DPOF) ........123 Setting the color reproduction Removing all or selected pictures format (Color Space) ....110 from the print order ....124 Changing the brightness Adding Audio to Pictures...
  • Page 7 Wireless remote control flash Shutter speeds when the flash photography (# RC Mode) ..135 fires (# X-Sync./# Slow Limit) ..........154 Using the Video Menu ....136 Combinations of JPEG image Using the Playback Menu ..137 sizes and compression rates Automatically Rotating Portrait- (K Set) .........154 Orientation Pictures for Playback (R) ........137...
  • Page 8 Cautions Batteries ........166 Using your USB-AC adapter abroad ........166 Usable cards ......167 Interchangeable lenses ....167 MF Clutch Lenses .....168 Compatible Flash Units ...169 Wireless remote control flash photography......170 Other external flash units ..171 System chart ......172 Information Cleaning and storing the camera ...........174 Cleaning the camera ....174 Storage ........174...

  • Page 9: Quick Task Index

    Quick task index Shooting Just shoot without making any difficult AUTO mode (B) settings Shooting in the way you want without Live Guide needing to know technical terms Taking self-portraits Self-portraits Taking stylish pictures Art filter Quickly matching settings to the scene Scene mode (SCN) Live Guide Taking pictures with a blurred...
  • Page 10 Live Guide Changing photo coloring Picture Mode White balance Picture Mode Processing pictures to match the Art filter (ART) subject/Taking monotone pictures Profile control Enhancing images Profile control Live Guide Taking pictures that stop the subject in Scene mode (SCN) motion or convey a sense of motion Shutter priority shooting Tap AF (Using the touch...
  • Page 11 Playback/Retouch HDMI Viewing images on a TV Playback on TV Viewing slideshows with background Slideshow music Brightening shadows Shadow Adj (JPEG Edit) Dealing with red-eye Redeye Fix (JPEG Edit) Printing made easy Creating a print order Transferring images to a Viewing pictures on a smartphone smartphone Automatically uploading...

  • Page 12: Names Of Parts

    Names of parts 1 Mode dial ........P. 29 b Hot shoe cover 2 Shutter button .........P. 30 c Built-in flash ........P. 84 3 Rear dial (o) .....P. 35-41, 118 d Stereo microphone ....P. 124, 136 4 u (Shortcut) button .......P. 33 e Lens release button ......P.
  • Page 13 F (Up) / ISO button (P. 83) H (Left) / N (AF target) button I (Right) / (P. 81) # (Flash) button (P. 84) Q button (P. 90, 118) G (Down) / jY (Sequential shooting/Self-timer) button (P. 86) 1 Flash pop-up button ......P. 84 9 Micro-USB connector....P.

  • Page 14: Preparation

    Preparation Unpacking the box contents At purchase, the package contains the camera and the following accessories. If anything is missing or damaged, contact the dealer from whom you purchased the camera. Camera Body cap * Hot shoe cover * Strap USB cable Lithium-ion battery USB-AC adapter F-5AC...

  • Page 15: Attaching The Strap

    Attaching the Strap Before attaching the strap, remove the end from the keeper loop and loosen the strap as shown. Keeper loop Pass the end of the strap through the strap eyelet and back through the keeper loop. Pass the end of the strap through the buckle and tighten as shown. •...

  • Page 16: Inserting And Removing The Battery And Card

    Inserting and Removing the Battery and Card In this manual, all storage devices are referred to as “cards.” The camera uses third-party SD, SDHC, or SDXC memory cards conforming to the SD (Secure Digital) standard. Cards must be formatted with this camera before first use or after being used with other cameras or computers.

  • Page 17: Removing The Battery

    Loading the card. • Slide the card in until it is locked into place. g “Usable cards” (P. 167) Terminal area • Do not forcibly insert a damaged or deformed card. Doing so may damage the card slot. Closing the battery/card compartment cover.

  • Page 18: Charging The Battery

    Charging the Battery Confirm that the ON/OFF lever is in the OFF position. Check that the battery is in the camera, and connect the USB cable and USB-AC adapter. USB-AC adapter (supplied) AC outlet Micro-USB connector USB cable (supplied) • Never use cable other than the USB cable supplied or specified by our company (P.
  • Page 19 The USB-AC Adapter • Be sure to unplug the USB-AC adapter for cleaning. Leaving the USB-AC adapter plugged in during cleaning could result in injury or electric shock.

  • Page 20: Attaching A Lens To The Camera

    Attaching a lens to the camera Confirm that the ON/OFF lever is in the OFF position. Rear cap Remove the rear cap of the lens and the body cap of the camera. Align the lens attachment mark (red) on the camera with the alignment mark (red) on the lens, then insert the lens into the camera’s body.

  • Page 21: Removing Lenses

    Removing Lenses Confirm that the ON/OFF lever is in the OFF position. Hold the lens release button and rotate the lens as shown. Lens release button Interchangeable lenses Read “Interchangeable lenses” (P. 167).

  • Page 22: Turning The Camera On

    Turning the camera on Set the ON/OFF lever to the ON position. • When the camera is turned on, the monitor will turn on. • To turn the camera off, return the lever to the OFF position. Battery level The battery level icon will be displayed. j (green): The camera is ready to shoot.

  • Page 23: Initial Setup

    Initial setup After turning the camera on for the first time, perform the initial setup by choosing a language and setting the camera clock. • Date and time information is recorded on the card together with the images. • The file name is also included with the date and time information. Be sure to set the correct date and time before using the camera.
  • Page 24 Set the date, time, and date format. • Use HI to highlight items. Time • Use FG to change the highlighted item. 2021 Y/M/D • The clock can be adjusted at any time from the e setup menu. g [X] (P. 143) Cancel The time is displayed using a 24-hour clock.

  • Page 25: Camera Displays Unreadable/Not In The Selected Language

    Camera displays unreadable/not in the selected language If the camera displays are in an unfamiliar language or use characters you are unable to read, you may have accidentally selected the wrong language in the language- selection dialog. Follow the steps below to change languages. Press the MENU button to display เมนู...

  • Page 26: Shooting

    Shooting Information displays while shooting Monitor display during still photography 7 8 9 0 Wi-Fi HDR1 S-IS ON S-IS ON S-IS ON S-IS ON ISO-A ISO-A AUTO AUTO Wi-Fi HDR1 S-AF S-AF S-IS ON S-IS ON ISO-A AUTO -3 -3 -3 -3 S-AF 1:02:03...
  • Page 27 1 Card write indicator ......P. 17 p Aspect ratio ........P. 97 2 Bluetooth connection status q Image quality (still images) .....P. 98 ® ..........P. 155 – 163 r Record mode (movies) ....P. 99 3 Wireless LAN connection starting up s Available recording time ....P. 187 ..........P.

  • Page 28: Switching The Information Display

    Switching the information display You can switch the information displayed in the monitor during shooting using the INFO INFO button button. S-IS ON S-IS ON INFO INFO ISO-A 1:02:03 250 F5.6 1023 Basic Information* Image Only INFO INFO INFO INFO S-IS ON S-IS ON S-IS ON...

  • Page 29: Choosing A Shooting Mode And Taking Photos

    Choosing a shooting mode and taking photos Use the mode dial to select the shooting mode, Indicator Mode icon and then shoot the image. Types of shooting modes For how to use the various shooting modes, see the following. Program AE (P. 35) Aperture-priority AE (P.
  • Page 30 Rotate the mode dial to a mode. Indicator Frame the shot. • Be careful that your fingers or the camera strap do not obstruct the lens or AF illuminator. Landscape position Portrait position Adjust the focus. • Display the subject in the center of the monitor, and lightly press the shutter button down to the first position (press the shutter button halfway).

  • Page 31: Taking High Angle And Low Angle Shots

    Taking high angle and low angle shots You can change the orientation and angle of the monitor. Lower angle Upper angle Rotating the Monitor: Cautions • Rotate the monitor gently within the limits shown. Do not use force; failure to observe this precaution could damage the connectors.

  • Page 32: Shooting With Touch Screen Operations

    Shooting with touch screen operations Tap d to cycle through touch screen settings. ISO-A 1:02:03 250 F5.6 1023 Tap a subject to focus and automatically release the shutter. This feature is not available in movie mode and during bulb, time, or composite photography.

  • Page 33: Switching Displays With The U (Shortcut) Button

    Switching Displays with the u (Shortcut) Button Press the u button to switch to each screen of the selected shooting mode between shots. u (Shortcut) button Mode dial P/A/S/M/B • When the profile control switch is not in the COLOR/MONO position LV super control panel (P.
  • Page 34 Art filter mode (P. 70) Advanced photo mode (P. 60) Live Composite Effect Pop Art Movie mode (P. 75) 34 EN...

  • Page 35: Letting The Camera Choose Aperture And Shutter Speed (Program Mode)

    Letting the camera choose aperture and shutter speed (Program mode) The camera chooses the optimal aperture and shutter speed according to subject brightness. Rotate the mode dial to P. Focus and check the display. S-IS ON S-IS ON • The shutter speed and aperture chosen by the camera ISO-A are displayed.
  • Page 36 • You can choose processing options using the profile control. Rotate the profile control switch to the COLOR/MONO position to display the profile control. When the profile control is not display while the profile control switch is in the COLOR/MONO position, press u button to display the control.

  • Page 37: Choosing Aperture (Aperture Priority Mode)

    Choosing aperture (Aperture Priority mode) In this mode, you choose the aperture (f/-number) and the camera automatically sets the shutter speed for optimal exposure according to subject brightness. Lower aperture values (larger apertures) reduce the depth of the area that appears to be in focus (depth of field), blurring the background.
  • Page 38 • You can choose processing options using the profile control. Rotate the profile control switch to the COLOR/MONO position to display the profile control. When the profile control is not display while the profile control switch is in the COLOR/MONO position, press u button to display the control.

  • Page 39: Choosing Shutter Speed (Shutter Priority Mode)

    Choosing shutter speed (Shutter Priority mode) In this mode, you choose the shutter speed and the camera automatically sets aperture for optimal exposure according to subject brightness. Faster shutter speeds appear to “freeze” fast-moving subjects. Slower shutter speeds add blur to moving objects, lending them a sense of motion for a dynamic effect.
  • Page 40 Warning display Status Action example (blinking) The subject is Set the shutter speed slower. 2000 2000 F2.8 F2.8 underexposed. • Choose a faster shutter speed. Shutter speeds as fast as 1/16000 s are available in silent mode. g “The Electronic Shutter (Silent s)”...

  • Page 41: Choosing Aperture And Shutter Speed (Manual Mode)

    Choosing aperture and shutter speed (Manual mode) In this mode, you choose the aperture and shutter speed. You can adjust settings according to your goals, for example by combining fast shutter speeds with small apertures (high f/-numbers) for increased depth of field. Rotate the mode dial to M.

  • Page 42: Long Exposures (Bulb/Time)

    Long Exposures (Bulb/Time) Leave the shutter open for a long exposure. You can preview the photo in live view and end the exposure when the desired results have been achieved. Use when long exposures are required, for example when photographing night scenes or fireworks. “Bulb”...
  • Page 43 Press the Q button to select the highlighted option. • The menus will be displayed. Press the MENU button to exit the menus. • If an option other than [Off] is selected, [LIVE BULB] or [LIVE TIME] will appear in the display.

  • Page 44: Lighten Blending (Live Composite Photography)

    Lighten Blending (Live Composite Photography) Leave the shutter open for a long exposure. You can view the light trails left by fireworks or stars and photograph them without changing the exposure of the background. The camera combines multiple shots and records them as a single photograph.
  • Page 45 Press the shutter button all the way down to ready the camera. ISO-A • The camera is ready to shoot when [Ready for composite shooting] is displayed. Ready for composite shooting 30 p 30 p 1:02:03 LIVECOMP F5.6 1023 Press the shutter button to start shooting. •...

  • Page 46: Shooting Enhanced Images (Profile Control)

    Shooting enhanced images (Profile Control) Use the profile control switch to switch to profile control photography. You can choose image enhancement options on the profile control screen. • Profile control photography is available only when the mode dial is rotated to P, A, S, M, •...
  • Page 47 Use FG to choose an option and adjust the settings (P. 48). Press the Q button. Shoot. • To go back to the profile control screen, press the u button.
  • Page 48 Image enhancement options for monochrome profile control „ Color Filter Effect You can apply a color filter effect to monochrome pictures, choosing from eight colors and three intensity levels. Choose Color Filter Effect using FG on the Color Filter Color Filter profile control screen.
  • Page 49 „ Highlight&Shadow Control Adjust brightness separately for highlights, mid-tones, and shadows. You gain greater control over exposure than you would with exposure compensation alone. You can selectively make highlights darker or shadows brighter. Choose Highlight&Shadow Control using FG HighLight±0 on the profile control screen. MONO MONO •...
  • Page 50 • When you choose a profile on the profile control screen using FG and press and hold the Q button, the Color Filter (P. 48)/Shading (P. 48)/Highlight&Shadow MONO MONO (P. 49) settings for the selected profile ([Mono1/2/3/4]) reset to the default values. The following settings also reset to the default values at the same time.

  • Page 51: Shooting Pictures With Individual

    Shooting pictures with individual colors adjusted (Color Profile Control) You can adjust the saturation of each color (Saturation Level), change the amount of peripheral light (Shading), and adjust bright and dark areas of the picture (Highlight&Shadow Control). Rotate the profile control switch to COLOR/MONO.
  • Page 52 Image enhancement options for color profile control „ Saturation Level The saturation of twelve different colors can be adjusted by up to ±5 while checking the effect on the screen. Choose Saturation Level using FG on the profile control screen. Color Color COLOR...
  • Page 53 „ Highlight&Shadow Control Adjust brightness separately for highlights, mid-tones, and shadows. You gain greater control over exposure than you would with exposure compensation alone. You can selectively make highlights darker or shadows brighter. Choose Highlight&Shadow Control using FG HighLight±0 on the profile control screen. COLOR COLOR •...

  • Page 54: Letting The Camera Choose The Settings (Auto Mode)

    Letting the camera choose the settings (AUTO mode) The camera adjusts settings to suit the scene; all you have to do is press the shutter button. Use live guides to easily adjust such parameters as color, brightness, and background blurring. Set the mode dial to B.
  • Page 55 Shoot. • To clear the live guides from the display, press the MENU button. • If [RAW] is currently selected for image quality, image quality will automatically be set to RAW+JPEG. • Certain live guide settings are not applied to the RAW copy. •...

  • Page 56: Shooting In Scene Mode (Scn Mode)

    Shooting in scene mode (SCN mode) The camera automatically optimizes settings for the subject or scene. Rotate the mode dial to SCN. Use FGHI to highlight a scene and press the Q button. People Nightscapes Motion Scenery Indoors Close-ups Use HI to highlight a scene mode and press the Portrait Q button.
  • Page 57 Subject type Scene mode Description Suitable for tripod shooting of night scenes. G Nightscape Use of a tripod and remote control via OI.Share is recommended (P. 161). Suitable for portrait shooting against a background of night view. Portrait + Raise the flash (P. 84). Nightscape Use of a tripod and remote control via OI.Share is recommended (P.
  • Page 58 Subject type Scene mode Description Suitable for shooting landscapes. F Landscape Emphasizes sharpness and contrast. Suitable for shooting the setting/rising sun. ` Sunset Reproduces colors vividly. Suitable for shooting snow-capped mountains, g Beach & Snow landscapes, white sand beaches, etc. Take panoramic photos with a wider angle of view than other shots.
  • Page 59 Subject type Scene mode Description i Macro Suitable for close-ups. j Nature Macro Suitable for vivid close-ups of flowers or insects. Suitable for photos of timetables or other documents. d Documents The camera heightens the contrast between the text and background. Close-ups The camera takes eight photos, varying the focus distance with each shot.

  • Page 60: Shooting In Advanced Photo Mode (Z Mode)

    Shooting in advanced photo mode ( Z mode) Use for quick access to advanced shooting settings. Rotate the mode dial to Z. Use HI to highlight an AP mode. Live Composite • Some modes offer additional options that can be accessed using G.

  • Page 61: [Live Composite]: Live Composite Photography

    AP mode Description Each time the shutter button is pressed, the camera takes Focus Bracketing a series of eight photos, varying the focus distance with each shot. [Live Composite]: Live Composite Photography Create photos that record light trails from stars and other objects without changing the brightness of the background;...

  • Page 62: [Live Time]: Live Time Photography

    [Live Time]: Live Time Photography You can make long exposures without having to keep the shutter button pressed. The changing result can be viewed in the monitor during shooting. Highlight [Live Time] on the AP-mode-selection screen (P. 60). Press G, use HI to choose the maximum Live Time exposure time, and press the Q button.

  • Page 63: [Multiple Exposure]: Shooting Multiple Exposures

    [Multiple Exposure]: Shooting Multiple Exposures Combine two different images on top of one another. Highlight [Multiple Exposure] on the AP-mode-selection screen (P. 60) and press the Q button. Press the shutter button halfway down to focus. • If the focus indicator blinks, the camera is not in focus. Press the shutter button all the way down for the first shot.

  • Page 64: [Hdr]: Taking Composite Photos With Hdr

    [HDR]: Taking Composite Photos with HDR Capture details in both highlights and shadows. The camera varies exposure over a series of four shots and combines them into a single image. Highlight [HDR] on the AP-mode-selection screen (P. 60). Press G, use HI to choose [HDR1] or [HDR2], and press the Q button.

  • Page 65: [Silent S] Mode

    [Silent s] Mode Disable camera sounds and lights in situations in which they may be unwelcome. Highlight [Silent s] on the AP-mode-selection screen (P. 60) and press the Q button. Press the shutter button halfway down to focus. • If the focus indicator blinks, the camera is not in focus. Press the shutter button all the way down to shoot.

  • Page 66: Shooting A Panorama

    Shooting a Panorama Pan the camera following an on-screen guide to create a single wide-angle (panorama) photo. Highlight [Panorama] on the AP-mode-selection screen (P. 60). Press G, then use HI to highlight the desired Panorama panorama type and press the Q button. Take panorama photos with a wider angle of view than other shots.

  • Page 67: [Keystone Compensation]

    [Keystone Compensation] Keystone distortion due to the influence of lens focal length and proximity to the subject can be corrected, or enhanced to exaggerate the effects of perspective. Keystone compensation can be previewed in the monitor during shooting. The corrected image is created from a smaller crop, slightly increasing the effective zoom ratio.

  • Page 68: [Ae Bracketing]: Varying Exposure Over A Series Of Shots

    [AE Bracketing]: Varying Exposure over a Series of Shots Take a series of photos, varying the exposure with each shot. Highlight [AE Bracketing] on the AP-mode-selection screen (P. 60). Press G, use HI to choose the number of shots, AE Bracketing and press the Q button.

  • Page 69: [Focus Bracketing]: Varying Focus Distance Over A Series Of Shots

    [Focus Bracketing]: Varying Focus Distance over a Series of Shots Each time the shutter button is pressed, the camera takes a series of eight photos, varying the focus distance with each shot. Highlight [Focus Bracketing] on the AP-mode-selection screen (P. 60). Press G, use HI to choose the amount focus Focus Bracketing distance changes with each shot, and press the Q...

  • Page 70: Using Art Filters (Art Mode)

    Using art filters (ART mode) Using art filters, you can easily have fun with artistic effects. Rotate the mode dial to ART. Use HI to highlight a filter. • The slider appears on the display when [Pop Art I/II], [Soft Focus], [Pin Hole I/II/III], [Cross Process I/II] or Effect [Instant Film] is highlighted.
  • Page 71 • [Color Filter] (P. 108) and [Monochrome Color] (P. 109) options are available with some art filters. • After you press the Q button in Step 5, the front dial can be used for exposure compensation (P. 81) and the rear dial for program shift (P. 36). •...

  • Page 72: Types Of Art Filters

    Types of art filters Pop Art I/II Creates an image that emphasizes the beauty of color. Soft Focus Creates an image that expresses a soft tone atmosphere. Creates an image that expresses warm light by scattering overall Pale&Light Color I/II light and slightly overexposing the image.

  • Page 73: Adjusting The Degree Of The Art Filter Effect (Fine-Tuning)

    Adjusting the degree of the art filter effect (Fine-Tuning) You can adjust the degree of the filter effect for Pop Art, Soft Focus, Pin Hole, Cross Process, and Instant Film before taking pictures. Select [Pop Art I/II], [Soft Focus], [Pin Hole I/II/ III], [Cross Process I/II], or [Instant Film] on the art-filter-selection screen (P.

  • Page 74: Recording Movies In Photo Shooting Modes

    Recording movies in photo shooting modes The R button can be used for movie recording even when the mode dial is not in the n position. • Be sure that [R REC] is assigned to the R button (P. 112). Press the R button to begin recording.

  • Page 75: Recording Movies In Movie Mode

    Recording movies in movie mode When the mode dial is rotated to n, movies can be recorded using functions such as the slow-motion mode. • Adjust aperture and shutter speed to suit your artistic intent. g “Choosing an Exposure Mode (n Mode (Movie Exposure Modes))” (P. 115) Rotate the mode dial to n.

  • Page 76: Movie Mode Options

    Movie Mode Options Movie mode Description o 4K Shoot 4K movies. ― n Standard Shoot standard movies. ― p High-speed Record slow-motion movies. Sound will not be recorded. • The picture modes available vary with the movie mode. • When recording movies, use an SD card that supports an SD speed class of 10 or higher. •...

  • Page 77: Recording Slow Motion Movies

    Recording Slow Motion Movies Record slow-motion movies. Footage shot at 120 fps plays back at 30 fps; quality is equivalent to [HD]. Highlight [High-speed] in the movie mode option (P. 76) and press the Q button. Press the R button to start shooting. •...

  • Page 78: Taking Photos In Self-Portrait Mode

    Taking Photos in Self-Portrait Mode Inverting the monitor allows you to take pictures of yourself while you preview the frame. If the monitor is open, close it. Open the monitor downward. • Read “Rotating the Monitor: Cautions” (P. 31) before moving the monitor.
  • Page 79 Frame the shot. • Be careful that your fingers or the camera strap do not obstruct the lens. Touch C and shoot. • You can also shoot by touching the subject displayed in the monitor, or by pressing the shutter button. •...

  • Page 80: Using Various Settings

    Using various settings Buttons and dials Frequently used photographic functions can be assigned to the buttons and dials. Button/dial Assigned function Front dial Exposure compensation* Movie recording** R button AEL/AFL button AEL/AFL** 112, 151 AF Area/AF target position 81, 82 N button (H) ISO button (F) ISO sensitivity...

  • Page 81: Controlling Exposure (Exposure F)

    Controlling exposure (Exposure F) The exposure selected automatically by the camera can be altered to suit your artistic intent. Choose positive values to make pictures brighter, negative values to make them darker. Exposure compensation can be adjusted by up to ±5.0 EV. Negative (–) No compensation (0) Positive (+)

  • Page 82: Setting The Location Of The Focus

    Setting the location of the focus (AF target position) You can position the target over your subject. Press the N (H) button to display the AF target. • If [o (All Targets)] is selected, select [I (Single Target)] or [J (9-Target Group)] using the front dial.

  • Page 83: Changing Iso Sensitivity (Iso)

    • Face priority is also available in [MF] (P. 92). Faces detected by the camera are indicated by white frames. Changing ISO sensitivity (ISO) Select a value according to subject brightness. Higher values let you photograph darker scenes but also increase image “noise” (mottling). Select [AUTO] to let the camera adjust sensitivity according to lighting conditions.

  • Page 84: Using A Flash (Flash Photography)

    Using a flash (Flash photography) The flash can be used for flash photography in a variety of shooting conditions. Press the flash pop-up button to raise the flash. Flash pop-up button Press the # (I) button. Select an item using HI, and then press the Q button. •...
  • Page 85 Flash modes that can be set by shooting mode Shooting Flash Monitor Flash mode Shutter speed limit mode timing Fill In 1st curtain 30 sec. – 1/250 sec.** Redeye Flash Off — — Red-Eye Slow Slow synchronization (1st curtain/ Red-eye reduction 1st curtain flash) Slow...

  • Page 86: Performing The Sequential/Self-Timer Shooting

    Performing the sequential/self-timer shooting Adjust settings for burst or self-timer photography. Choose an option according to your subject. Other options, including anti-shock and silent modes, are also available. Press the jY (G) button. Use HI to select an option. • Custom self-timer options can be viewed by pressing the INFO button (P. 87). Single-frame advance.

  • Page 87: Self-Timer Options (C Custom Self-Timer)

    • Fix the camera securely on a tripod for self-timer shooting. • If you stand in front of the camera to press the shutter button when using the self-timer, the picture may be out of focus. • When you are using S, tS or ♥S, live view is displayed. In T or ♥T, the display shows the last photograph taken during the sequential shooting.

  • Page 88: Shooting Without The Vibration Caused By Shutter Button Operations (Anti-Shock R)

    Shooting without the vibration caused by shutter button operations (Anti-Shock r) Reduce the slight blur caused by shutter motion. Use this option when even slight camera motion can cause blur, for example during macro or telephoto photography. • The delay between the shutter button being pressed all the way down and the start of shooting can be selected using [Anti-Shock r/Silent s] >...

  • Page 89: Calling Shooting Options

    Calling shooting options „ LV super control panel The LV super control panel lists shooting settings and their current values. Recommended ISO A ± 0 Natural Auto Auto G ± 0 ± 0 ± 0 S-AF ± 0 Normal ± 0.0 sRGB S-IS On M-IS...
  • Page 90 „ Using the LV Super Control Panel Press the Q button. Recommended ISO • The LV super control panel will be displayed. A ± 0 Natural Cursor Auto Auto G ± 0 ± 0 ± 0 When the mode dial is rotated to n, the LV S-AF ±...
  • Page 91 „ LV control You can use LV control to select the shooting function while checking the effect on the screen. LV control screen AUTO Functions AUTO AUTO S-AF S-AF W Keep Warm Color WB Auto Settings AUTO AUTO „ Available settings Picture mode ........P.

  • Page 92: Choosing A Focus Mode (Af Mode)

    Choosing a focus mode (AF Mode) You can select a focusing method (focus mode). Press the Q button to display the LV super KAF Mode control panel. Natural A ± 0 Auto Auto G ± 0 ± 0 ± 0 S-AF ±...

  • Page 93: Choosing How The Camera Measures Brightness (Metering)

    • The camera may be unable to focus if the subject is poorly lit, obscured by mist or smoke, or lacks contrast. • AF mode is unavailable when a Four Thirds system lens is used. • AF mode is unavailable when the lens MF focus clutch is set to MF. •...

  • Page 94: Adjusting Color

    Adjusting color (WB (white balance)) White balance (WB) ensures that white objects in images recorded by the camera appear white. [AUTO] is suitable in most circumstances, but other values can be selected according to the light source when [AUTO] fails to produce the desired results or you wish to introduce a deliberate color cast into your images.
  • Page 95 „ One-touch white balance Measure white balance by framing a piece of paper or other white object under the lighting that will be used in the final photograph. Use this option to fi ne-tune white balance when you find it hard to obtain the desired results with white balance compensation or preset white balance options such as 5 (sunlight) or O (overcast).

  • Page 96: Making Fine Adjustments To White Balance (Wb Compensation)

    Making fine adjustments to white balance (WB Compensation) You can set and finely adjust the compensation values for both auto white balance and preset white balance. Before proceeding, choose a white balance option to which to make fine adjustments. g “Adjusting color (WB (white balance))” (P. 94) Press the Q button to display the LV super control panel.

  • Page 97: Setting The Image Aspect

    • The edges of the frame are cropped out when [M-IS ] is selected, reducing the area recorded. • The image stabilizer cannot correct excessive camera shake or camera shake that occurs when the shutter speed is set to the slowest speed. In these cases, it is recommended that you use a tripod.

  • Page 98: Photo File And Image Size

    “.ORF”) for pictures that will later be enhanced. - Cannot be viewed on other cameras - Can be viewed on computers using Olympus Workspace Digital Photo Managing software - Can be saved in JPEG format using the [RAW Data Edit] (P. 137) retouch option in...

  • Page 99: (Movie Quality, Nk)

    Frame Size, Rate, and Compression (Movie quality, nK) Choose the image quality options available for movie recording. When choosing an option, consider how the movie will be used: for example, are you planning to process it on a computer, or is it intended for upload to a website? Press the Q button to display the LV super control panel.
  • Page 100 Movie quality Movie quality components 1280×720 Normal 30p 1920×1080 Super Fine 50p 1920×1080 Super Fine 25p 1280×720 Super Fine 25p Choose the desired combination of frame size, 1920×1080 Fine 50p bit rate, and frame rate. 1920×1080 Fine 25p 1280×720 Fine 25p 1920×1080 Normal 50p 1920×1080 Normal 25p 1 Frame size...
  • Page 101 The following options are available when the mode dial is rotated to n and [4K] is selected for movie mode * Movie quality Movie quality components Choose the desired combination of frame size and frame rate. 3840×2160 30p 3840×2160 25p 1 Frame size : 3840×2160 3840×2160 24p...
  • Page 102 The following options are available when the mode dial is rotated to n and [Standard] is selected for movie mode: Movie quality Movie quality components 1920×1080 Super Fine 60p 1920×1080 Super Fine 30p 1280×720 Super Fine 30p 1920×1080 Fine 60p 1920×1080 Fine 30p 1280×720 Fine 30p 1920×1080 Normal 60p...

  • Page 103: Adjusting Flash Output

    Adjusting flash output (Flash intensity control) Flash output can be adjusted if you find that your subject to appears overexposed, or is underexposed even though the exposure in the rest of the frame is just right. Press the Q button to display the LV super control panel.
  • Page 104 „ Picture mode options The camera adjusts colors and contrast for optimal results A i-Enhance according to the type of subject (P. 110). B Vivid Choose for vivid colors. C Natural Choose for natural colors. D Muted Choose for pictures that will later be retouched. E Portrait Enhance skin tones.

  • Page 105: Adjusting Overall Color (Color Creator)

    Adjusting overall color (Color Creator) The overall color of the image can be adjusted using any combination of 30 hues and 8 saturation levels. • Adjustments may not be available depending on the shooting mode and picture mode. Press the Q button to display the LV super Picture Mode control panel.

  • Page 106: Making Fine Adjustments To Sharpness (Sharpness)

    Making fine adjustments to sharpness (Sharpness) Adjust image sharpness. Outlines can be emphasized for a sharp, clear picture. Settings are stored separately for each picture mode. • Adjustments may not be available depending on the shooting mode and picture mode. Sharpness Press the Q button to display the LV super control panel.

  • Page 107: (Film Grain Effect)

    Adding a film grain effect to the Monochrome Profile (Film Grain Effect) An effect similar to the grain seen in black-and-white film can be added to the in [MONO Profile 1/2/3/4] picture mode (P. 103) for later use. • You can select these options while the profile control switch is in the COLOR/MONO position.

  • Page 108: Making Fine Adjustments To Tone (Gradation)

    Making fine adjustments to tone (Gradation) Adjust color brightness and shading. Bring pictures closer to what you envisage by, for example, brightening the entire picture. Settings are stored separately for each picture mode. • Adjustments may not be available depending on the shooting mode and picture mode. Gradation Press the Q button to display the LV super control panel.

  • Page 109: Adjusting The Tone Of Monochrome Pictures (Monochrome Color)

    N:None Creates a normal black and white image. Ye:Yellow Reproduces clearly defined white cloud with natural blue sky. Or:Orange Slightly emphasizes colors in blue skies and sunsets. Strongly emphasizes colors in blue skies and brightness of crimson R:Red foliage. G:Green Strongly emphasizes colors in red lips and green leaves.

  • Page 110: Adjusting I-Enhance Effects (Effect)

    Adjusting i-Enhance effects (Effect) Choose the strength of the i-Enhance effect when [i-Enhance] is selected for picture mode (P. 103). Picture Mode Press the Q button to display the LV super control panel. Effect Use FGHI to highlight picture mode, and then A ±...

  • Page 111: (Highlight&Shadow Control)

    Changing the brightness of highlights and shadows (Highlight&Shadow Control) Adjust brightness separately for highlights, mid-tones, and shadows. You gain greater control over exposure than you would with exposure compensation alone. You can selectively make highlights darker or shadows brighter. • Adjustments may not be available depending on the shooting mode. Press the Q button to display the LV super control Highlight&Shadow Control panel.

  • Page 112: Assigning Functions To Buttons (Button Function)

    Assigning functions to buttons (Button Function) Other roles can be assigned to buttons in place of their existing functions. „ Customizable Controls Button Default t Function AEL/AFL R Function R REC To change the function assigned to a button, follow the steps below. Press the Q button to display the LV super control Button Function panel.

  • Page 113: Zoom Frame Af/Zoom Af

    Press the button to adjust exposure compensation. F (Exposure In P, A, S, ART, Z, and movie modes, you can adjust compensation) exposure compensation by pressing the button and using HI or the front or rear dial to choose the desired value. In M mode, you can adjust shutter speed or aperture by pressing the button and using FGHI or the front or rear dial to choose the desired values.
  • Page 114 Press the button to which [a] (magnify) is S-IS ON S-IS ON assigned. ISO-A • The zoom frame will be displayed. • The frame is displayed in the same position as the target most recently used for autofocus. 1:02:03 250 F5.6 1023 Use FGHI to position the zoom frame.

  • Page 115: Choosing An Exposure Mode (N Mode (Movie Exposure Modes))

    Choosing an Exposure Mode (n Mode (Movie Exposure Modes)) Adjust aperture and shutter speed to suit your artistic intent. This option takes effect when the mode dial is rotated to n. Rotate the mode dial to n. Press the Q button and use FG to highlight AUTO AUTO AUTO...

  • Page 116: Playback

    Playback Information display during playback Playback image information Simplified display 7 89 ×10 100-0015 4 : 3 2021.04.01 12:30:00 Overall display ×10 ×10 F5.6 F5.6 +2.0 45mm 45mm +1.0 +1.0 AUTO ISO 400 ISO 400 sRGB Natural Natural 5184×3888 100-0015 4 : 3 2021.04.01 12:30:00 116 EN...

  • Page 117: Switching The Information Display

    1 Battery level ........P. 22 f Aspect border .........P. 97 2 Bluetooth connection status g AF area pointer .......P. 82 ® ..........P. 155 – 163 h Shooting mode......P. 29–75 3 Wireless LAN connection..P. 155–163 i Shutter speed ......P. 35–41 4 Including GPS information ....P. 162 j Exposure compensation ....P.

  • Page 118: Viewing Photographs And Movies

    Viewing photographs and movies Press the q button. • A photograph or movie will be displayed. • Select the desired photograph or movie using the front dial or HI. • To return to shooting mode, press the shutter button halfway or press the q button. Front dial Displays Displays...

  • Page 119: Finding Pictures Quickly (Index And Calendar Playback)

    Finding Pictures Quickly (Index and Calendar Playback) • In single-frame playback, rotate the rear dial to G (q) for index playback. Rotate further for calendar playback. • Turn the rear dial to a (p) to return to single-frame playback. 2021.4 100-0020 2021.04.01 12:30:00...

  • Page 120: Viewing Images As A Slideshow (L)

    Viewing Images as a Slideshow This function displays images stored on the card one after another. Press the Q button in the playback display. JPEG JPEG Edit Select [L] and press the Q button. Share Order Rotate Back Adjust settings. Start the slideshow.

  • Page 121: Watching Movies

    Deletes all parts of a split movie [Erase]: Deletes files separately • We recommend using the latest version of Olympus Workspace to play back movies on a computer. Before launching the software for the first time, connect the camera to the computer.

  • Page 122: Selecting Pictures For Sharing (Share Order)

    Selecting Pictures for Sharing (Share Order) You can select images you want to transfer to a smartphone in advance. You can also use OI.Share to browse the images included in the share order. Display the image you want to transfer and press the h (R) button to set a share order. A h icon will appear on the image.

  • Page 123: Creating A Print Order (Dpof)

    Creating a print order (DPOF) You can select pictures for printing and choose the number of copies and the information printed on each picture. The pictures can be printed at print shops that support the Digital Print Order Format (DPOF). A digital print order is stored on the memory card.

  • Page 124: Removing All Or Selected Pictures From The Print Order

    Removing all or selected pictures from the print order You can reset all print reservation data or just the data for selected pictures. Press the Q button in the playback display. Select [< (Print Order)] and press the Q button. Select [<] and press the Q button.

  • Page 125: Scrolling Panoramas

    Scrolling Panoramas Panoramas made up of multiple images joined together can be viewed in a scrolling display. Select a panorama in single-frame playback. Turn the rear dial to a. • Use FGHI to scroll. • During playback, you can turn the rear dial further to a to zoom in from 2x to 14x or turn it to G to zoom out.

  • Page 126: Using The Touch Screen

    Using the touch screen You can use the touch screen to manipulate images. • Do not tap the display with your fingernails or other sharp objects. • Gloves or monitor covers may interfere with touch screen operation. Single-frame playback „ Displaying the previous or next image •...

  • Page 127: Selecting And Protecting Images

    Selecting and protecting images To view the touch menu, lightly tap the display (single- frame playback) or tap the icon (index playback). You can then perform the desired operation by tapping the icons in the touch menu. 2021.04.01 12:30:00 Select an image. You can select multiple images and delete them collectively. Images you want to share with a smartphone can be set.

  • Page 128: Menu Functions

    Menu functions Basic menu operations The menus can be used to customize the camera for ease of use and include shooting and playback options not accessible via the LV control, LV super control panel, or the like. Tab name Description Shooting Menu 1 Photography-related items.

  • Page 129: Using Shooting Menu 1/ Shooting Menu 2

    Select an item using FG, and then press the Q button or I to display options for the selected item. The current setting is Function displayed Shooting Menu 1 Shooting Menu 1 Reset Reset Picture Mode Picture Mode Digital Tele-converter Digital Tele-converter Metering Metering...

  • Page 130: Processing Options (Picture Mode)

    Processing options (Picture Mode) You can make individual adjustments to contrast, sharpness and other parameters in [Picture Mode] (P. 103) settings. Changes to parameters are stored for each picture mode separately. Select [Picture Mode] in W Shooting Menu 1 and Shooting Menu 1 Reset press I.

  • Page 131: Choosing A Zoom Speed

    Choosing a Zoom Speed (K Elec. Zoom Speed) Choose the speed at which power zoom lenses zoom in or out when the zoom ring is rotated. Adjust zoom speed if it is so quick that you find it hard to frame your subject. Highlight [K Elec.
  • Page 132 Press the MENU button to exit the menus. • A a icon will be displayed. a icon • If [Overlay] is selected, the chosen photograph will be visible superimposed on the view through the lens. 1:02:03 250 F5.6 0.0 1023 Take pictures.

  • Page 133: Shooting Automatically With A Fixed Interval (Intrvl. Sh./Time Lapse)

    Shooting automatically with a fixed interval (Intrvl. Sh./Time Lapse) You can set the camera to shoot automatically with a set time lapse. The shot frames can also be recorded as into a single movie. This setting is only available in P/A/S/M modes.
  • Page 134 • Frames are shot even if the image is not in focus after AF. If you wish to fix the focus position, shoot in MF. • [Rec View] (P. 143) operates for 0.5 seconds. • If either of the time before shooting, or shooting interval is set to 1 minute 31 seconds or longer, the monitor and camera power will turn off after 1 minute.

  • Page 135: Setting Anti-Shock/Silent Shooting

    Setting anti-shock/silent shooting (Anti-Shockr/Silents) You can set the operation of the shutter and related functions when shooting in the anti-shock mode (P. 88) and the silent mode (P. 88). • These settings are not available in the SCN mode and Z mode. Highlight [Anti-Shockr/Silents] in X Shooting Shooting Menu 2 K Image Stabilizer...

  • Page 136: Using The Video Menu

    Using the Video Menu Movie recording functions are set in the Video Menu. Video Menu Movie R Recording Volume ±0 nAF Mode C-AF nImage Stabilizer M-IS nElec. Zoom Speed Normal Video Frame Rate Video Bit Rate Fine Back Option Description [Off]: Record movies without sound.

  • Page 137: Using The Playback Menu

    Using the Playback Menu Playback Menu y (P. 120) Playback Menu Edit Edit Print Order Print Order (P. 123) Reset Protect Reset Protect (P. 142) Reset share Order Device Connection Reset share Order (P. 122) Back Device Connection (P. 156) Automatically Rotating Portrait-Orientation Pictures for Playback If set to [On], images in portrait orientation are automatically rotated to be displayed in the correct orientation on the playback display.
  • Page 138 Select [Edit] in the q Playback Menu and press Playback Menu Edit Print Order Reset Protect Reset share Order Device Connection Back Use FG to select [Sel. Image] and press the Q button. • The pictures on the memory card will be displayed. Use HI to select the image to be edited and press the Q button.
  • Page 139 To create additional copies from the same original, highlight [Reset] and press the Q button. To exit without creating more copies, highlight [No] and press the Q button. • Selecting [Reset] displays editing options. Repeat the process from Step 5. •...
  • Page 140 Use FG to select [Sel. Image] and press the Q button. • The pictures on the memory card will be displayed. Use HI to select the image to be edited and press the Q button. • Edit menu will be displayed. 100-0015 +RAW +RAW...

  • Page 141: Combining Pictures (Image Overlay)

    • Use FG or to skip multiple frames. • The date of recording of the still may differ from that of the original movie. • We recommend using the latest version of Olympus Workspace to edit movies on a computer.

  • Page 142: Trimming Movies (Movie Trimming)

    Select [Yes] and press the Q button. • The date of recording of the still may differ from that of the original movie. • We recommend using the latest version of Olympus Workspace to edit movies on a computer. Removing Protection from All Pictures (Reset Protect) Protections of multiple images can be canceled at a time.

  • Page 143: Using The Setup Menu

    Using the setup menu Adjust basic camera settings. Examples include language Setup Menu selection and monitor brightness. The setup menu also Card Setup ’--.--.-- --:--:-- contains options used during the initial setup process. English j±0 k±0 Rec View 0.5 sec Wi-Fi/Bluetooth Settings Firmware Back...

  • Page 144: Formatting The Card (Card Setup)

    Formatting the card (Card Setup) Cards must be formatted with this camera before first use or after being used with other cameras or computers. All data stored on the card, including protected images, is erased when the card is formatted. When formatting a used card, confirm there are no images that you still want to keep on the card.

  • Page 145: Using The Custom Menus

    Using the custom menus Camera settings can be customized using the G Custom Menu. Custom Menu AF/MF A. AF/MF Button/Dial AEL/AFL S1/C2/M1 Face Priority N/O Disp/8/PC (P. 146) MF Assist P/Q Exp/ISO/BULB (P. 147) Reset Lens # Custom (P. 148) K/WB/Color (P.

  • Page 146: N Disp/8/Pc

    N Disp/8/PC MENU Option Description K Control For each shooting mode except movie, choose whether Settings pressing the Q button displays LV controls or LV super controls. Choose the information displayed when the INFO button G/Info Settings is pressed. [q Info]: Choose the information displayed in full frame playback.

  • Page 147: P Exp/Iso/Bulb

    P Exp/ISO/BULB MENU Option Description Exposure Shift Adjust correct exposure separately for each metering mode. • This reduces the number of exposure compensation options available in the selected direction. — • The effects are not visible in the monitor. To make normal adjustments to the exposure, perform exposure compensation (P.

  • Page 148: B # Custom

    b # Custom MENU Option Description Choose the shutter speed used when the flash fires. # X-Sync. # Slow Limit Choose the slowest shutter speed available when a flash is used. When set to [On], the exposure compensation value is 81,  ...

  • Page 149: Record

    X Record MENU Option Description File Name [Auto]: Even when a new card is inserted, the file numbers are retained from the previous card. File numbering continues from the last number used or from the highest number available on the card. —...

  • Page 150: K Utility

    c K Utility MENU Option Description Pixel Mapping The pixel mapping feature allows the camera to check and adjust the image pickup device and image processing functions. Level Adjust You can calibrate the angle of the level gauge. [Reset]: Resets adjusted values to the default settings. —...

  • Page 151: Ael/Afl

    AEL/AFL MENU [AEL/AFL] S-AF AEL/AFL Autofocus and metering can be performed by pressing the mode1 AEL/AFL button. Choose a mode for each focus mode. Half Way AEL/S-AF Fully Exposure Assignments of AEL/AFL function Back AEL/AFL button Shutter button pressed Mode Halfway All the way down Kept pressed...

  • Page 152: Adding Information Displays

    Adding information displays [G/Info Settings] MENU q Info (Playback information displays) q Info Use [q Info] to add the following playback information Image Only Overall displays. The added displays are displayed by repeatedly pressing the INFO button during playback. You can also Highlight&Shadow choose to not show displays that appear at the default setting.

  • Page 153: Viewing Camera Images On Tv (Hdmi)

    Viewing camera images on TV (HDMI) [HDMI] MENU Use the separately sold cable with the camera to playback recorded images on your TV. This function is available during shooting. Connect the camera to an HD TV using an HDMI cable to view high-quality images on a TV screen. Turn the camera off and connect it to the TV.

  • Page 154: Shutter Speeds When The Flash Fires (# X-Sync./# Slow Limit)

    Using the TV remote control The camera can be operated by a TV remote control when connected to a TV that supports HDMI control. Select [On] for [HDMI Control]. When [On] is selected, camera controls can be used for playback only. •...

  • Page 155: Connecting The Camera To A Smartphone

    • Operation is not guaranteed on all smartphones. Things you can do with the specified app, OLYMPUS Image Share (OI.Share) • Download images from the camera to the smartphone You can load images in the camera to a smartphone.

  • Page 156: Pairing The Camera And Smartphone

    • The Bluetooth local name and passcode, the Wi-Fi SSID and password, and a QR code are displayed in the monitor. Connection Setup Scan the QR code, using the Olympus Image Share app. QR code Bluetooth local name Bluetooth Passcode...

  • Page 157: Wireless Connection Standby Setting For When The Camera Is On

    Wireless Connection Standby Setting for When the Camera Is On You can choose whether the camera will be on standby for wireless connection with the smartphone when the power is on. Highlight [Wi-Fi/Bluetooth Settings] in the e setup menu and press I. Highlight [Bluetooth] and press I.

  • Page 158: Wireless Settings For When The Camera Is Off

    Wireless Settings for When the Camera Is Off You can choose whether the camera will maintain a wireless connection to the smartphone when off. Highlight [Wi-Fi/Bluetooth Settings] in the e setup menu and press I. Highlight [Power-off Standby] and press I. Highlight the desired option and press the Q button.

  • Page 159: Transferring Images To A Smartphone

    • If left active, the wireless connection will automatically terminate if: - the connection remains inactive for 12 hours - the memory card is removed - the battery is replaced - a charging error occurs during on-board battery charging The connection can be restored by turning the camera on. •...

  • Page 160: Automatically Uploading Images While The Camera Is Off

    Automatically uploading images while the camera is off To configure the camera to automatically upload images to a smartphone while off: • Mark images for sharing (P. 122) • Enable power-off standby (P. 158) • If you are using an iOS device, launch OI.Share •...

  • Page 161: Shooting Remotely With A Smartphone (Live View)

    Shooting remotely with a smartphone (Live View) You can shoot remotely by operating the camera with a smartphone while checking the live view on the smartphone screen. • The camera shows the connection screen and all operations are performed from the smartphone.

  • Page 162: Adding Position Information To Images

    Adding position information to images You can add GPS tags to images that were taken while the GPS log was saving by transferring the GPS log saved on the smartphone to the camera. Before taking pictures with the camera, launch OI.Track on the smartphone to begin saving the GPS log.

  • Page 163: Changing The Password

    Changing the password To change the Wi-Fi/Bluetooth passwords: Select [Wi-Fi/Bluetooth Settings] in the e Setup Menu and press I. Select [Connection Password] and press I. Follow the operation guide and press the R button. • A new password will be set. •...

  • Page 164: Connecting The Camera To A Computer

    Connecting the camera to a computer Copying pictures to a computer Turn the camera off and connect it to the computer. Micro-USB connector Smaller terminal USB port USB cable • The location of the USB port varies with the computer. For details, refer to your computer’s manual.

  • Page 165: Installing The Pc Software

    Install the following software to access the camera while it is connected directly to the computer via USB. Olympus Workspace This computer application is used to download and view photos and movies recorded with the camera. It can also be used to update the camera firmware. The software can be downloaded from the website below.

  • Page 166: Cautions

    Cautions Batteries • The camera uses our lithium-ion battery. Never use any battery other than our genuine batteries. • The camera’s power consumption varies widely with usage and other conditions. • As the following consume a lot of power even without shooting, the battery will be drained quickly.

  • Page 167: Usable Cards

    Usable cards In this manual, all storage devices are referred to as “cards.” The following types of SD memory card (commercially available) can be used with this camera: SD, SDHC, and SDXC. For the latest information, please visit our website. SD card write protect switch The SD card body has a write protect switch.

  • Page 168: Mf Clutch Lenses

    MF Clutch Lenses The “MF clutch” (manual focus clutch) mechanism on MF clutch lenses can be used to switch between auto and manual focus simply by repositioning the focus ring. • Check the position of the MF clutch before shooting. •...

  • Page 169: Compatible Flash Units

    Compatible Flash Units Choose a flash unit to suit your needs, taking into consideration such factors as the output required and whether the unit supports macro photography. Flash units designed to communicate with the camera support a variety of flash modes, including TTL auto and super FP.

  • Page 170: Wireless Remote Control Flash Photography

    Wireless remote control flash photography External flash units that are designated for use with this camera and have a remote control mode can be used for wireless flash photography. The camera can separately control each of three groups of remote flash units, and the internal flash. See the instruction manuals provided with the external flash units for details.

  • Page 171: Other External Flash Units

    Other external flash units Note the following when using a third-party flash unit mounted on the camera hot shoe: • Using obsolete flash units that apply currents of more than about 24 V to the X-contact will damage the camera. •...

  • Page 172: System Chart

    Connection CB-USB12/ Cable Software HDMI Cable* Olympus Workspace Photo editing software SD/SDHC/ OLYMPUS Image Share (OI.Share) Memory Card SDXC Olympus Image Palette (OI.Palette) OLYMPUS Image Track (OI.Track) Smartphone App : E-P7 compatible products : Commercially available products For the latest information, please visit our website.
  • Page 173 Converter Lens Lens* FCON-P01 Fisheye Micro Four Thirds system lenses WCON-P01 Wide MCON-P01 Macro MMF-2/MMF-3 Four Thirds System Lenses Four Thirds Adapter MCON-P02 Macro MC-14 Teleconverter BCL-1580/BCL-0980 Body Cap Lens MC-20 Teleconverter Flash FL-900R FL-700WR STF-8 Electronic Flash Electronic Flash Macro Flash Radiowave System Accessories FC-WR...

  • Page 174: Information

    Information Cleaning and storing the camera Cleaning the camera Turn off the camera and remove the battery before cleaning the camera. • Do not use strong solvents such as benzene or alcohol, or a chemically treated cloth. Exterior: • Wipe gently with a soft cloth. If the camera is very dirty, soak the cloth in mild soapy water and wring well.

  • Page 175: Pixel Mapping - Checking The Image Processing Functions

    Pixel Mapping - Checking the image processing functions The pixel mapping feature allows the camera to check and adjust the image pickup device and image processing functions. Before using the pixel mapping function to ensure that it operates correctly, wait for 1 minute or longer immediately after shooting or playback.

  • Page 176: Shooting Tips And Information

    Shooting tips and information The camera does not turn on even when a battery is loaded The battery is not fully charged • Charge the battery with the USB-AC adapter. The battery is temporarily unable to function because of the cold •...
  • Page 177 No picture is taken when the shutter button is pressed The camera has turned off automatically • The camera automatically enters sleep mode to reduce the drain on the battery if no operations are performed for a set period of time. g [Sleep] (P. 150) Press the shutter button halfway to exit the sleep mode.
  • Page 178 The subject appears distorted The following functions use an electronic shutter: movie recording (P. 74)/silent (P. 88)/the SCN mode panorama (P. 58), “silent” (P. 58), and “multi-focus shot” (P. 59) options/the Z mode “silent” (P. 65), panorama (P. 66), and “focus bracketing” (P. 69) options This may cause distortion if the subject is moving rapidly or the camera is moved abruptly.

  • Page 179: Error Codes

    Error codes Monitor indication Possible cause Corrective action The card is not inserted, or it Insert a card or insert a different cannot be recognized. card. No Card Insert the card again. If the problem persists, format the card. There is a problem with the card. If the card cannot be formatted, it Card Error cannot be used.
  • Page 180 Monitor indication Possible cause Corrective action The camera is not correctly connected to a computer, HDMI Reconnect the camera. display, or other device. No Connection It may not be possible to create print reservations for pictures Print separately via a personal recorded on other cameras via computer, etc.

  • Page 181: Defaults

    Defaults *1: Default can be restored by selecting [Full] for [Reset]. *2: Default can be restored by selecting [Basic] for [Reset]. LV Controls/LV Super Control Panel Shooting mode Item Default AUTO P/A/S/M/ Flash Mode ±0.0 Manual Value #FULL (flash set to [#MANUAL]) S-IS On K Image Stabilizer...
  • Page 182 Shooting mode Item Default Picture Mode Natural n (movie) [P], [A], or [S] selected for [n Mode]: AUTO (fixed) [M] selected for [n Mode]: AUTO ([On] selected for [W Keep Warm Color]) n AF Mode C-AF n Mode a ― RC mode QA group A QB group B...
  • Page 183 n Video Menu Function Default Movie R Recording Volume ±0 a ― n AF Mode C-AF M-IS n Image Stabilizer n Elec. Zoom Speed Normal a ― Video Frame Rate a ― 99,   1 36 Video Bit Rate Fine a ―...
  • Page 184 Function Default Button/Dial t Function AEL/AFL a ― M Button 112,   1 45 Function a ― R Function R REC a ― qR Function Front dial: F Rear dial: Ps Front dial: F Rear dial: FNo. Dial Function a ― Front dial: F Rear dial: Shutter Front dial: FNo.
  • Page 185 Function Default # Custom 148,   b #X-Sync. 1/250 148,   #Slow Limit 1/60 81,   1 03,   a ― #+WB K/WB/Color 148,   K1 YSF, K2 YF, K Set K3 YN, K4 XN AUTO a a 94,   1 48 W Keep Warm Color Color Space sRGB...

  • Page 186: Record Mode And File Size/Number Of Storable Still Pictures

    Record mode and file size/number of storable still pictures Memory Card Capacity: Photos Figures are for a 16 GB SD card used to record photos with an aspect ratio of 4:3. Number of Image size File Record mode Compression File size (MB) storable still (Pixel Count) format...
  • Page 187 Memory Card Capacity: Movies Figures are for a 32 GB SDHC memory card. Frame size Compression Frame rate Capacity (approx.) — 30p, 25p, 24p 39 minutes 1 hour 16 minutes 60p, 50p, 30p, 25p, 2 hours 7 minutes 3 hours 22 minutes 2 hours 25 minutes 60p, 50p, 30p, 25p, 4 hours 11 minutes...

  • Page 188: Specifications

    Specifications „ Camera Product type Product type Digital camera with interchangeable Micro Four Thirds Standard lens system Lens M.Zuiko Digital, Micro Four Thirds System Lens Lens mount Micro Four Thirds mount Equivalent focal length on Approx. twice the focal length of the lens a 35 mm film camera Image pickup device Product type...
  • Page 189 Recording Memory SD, SDHC and SDXC UHS-II compatible Recording system Digital recording, JPEG (DCF2.0), RAW Data Applicable standards Exif 2.31, Digital Print Order Format (DPOF) Sound with still pictures Wave format Movie MPEG-4 AVC/H.264 Audio Stereo, PCM 48kHz Playback Display format Single-frame playback/Close-up playback/Index display/Calendar display Drive Drive mode...
  • Page 190 „ Lithium-ion battery MODEL NO. BLS-50 Product type Rechargeable Lithium ion battery Nominal voltage DC 7.2 V Nominal capacity 1210 mAh No. of charge and discharge times Approx. 500 times (varies with usage conditions) Ambient temperature 0 °C - 40 °C (32 °F - 104 °F) (charging) Dimensions Approx.

  • Page 191: Safety Precautions

    SAFETY PRECAUTIONS SAFETY PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO OUR QUALIFIED SERVICE PERSONNEL. An exclamation mark enclosed in a triangle alerts you to important operating and maintenance instructions in the documentation provided with the product.
  • Page 192 • Keep young children and infants away • To protect the high-precision technology from the camera. contained in this product, never leave the camera in the places listed below, no matter if • Always use and store the camera out of in use or storage: the reach of young children and infants to prevent the following dangerous situations...
  • Page 193 • If rechargeable batteries have not been • Never store batteries where they will be recharged within the specified time, stop exposed to direct sunlight, or subjected to charging them and do not use them. high temperatures in a hot vehicle, near a heat source, etc.
  • Page 194 • Before storing the camera for a long period, batteries. A recommended battery may be remove the batteries. Select a cool, dry difficult to obtain while traveling. location for storage to prevent condensation Using the wireless LAN/ or mold from forming inside the camera. After Bluetooth functions ®...
  • Page 195 Those terms and other third party software and contents of this publication or software notices, if any, may be found in the software without obligation or advance notice. notice PDF file stored at https://cs.olympus-imaging.jp/en/support/imsg/ Trademarks digicamera/download/notice/notice.cfm • Microsoft and Windows are registered trademarks of Microsoft Corporation.
  • Page 196 Index Symbols AEL/AFL ..........151 AE lock ...... 112, 113, 145, 151 8 (Beep sound) .......146 AF illuminator.......30, 130 # Slow Limit......148, 154 AF Mode ..........92 #UP ............84 Movie ..........136 #+WB ..........148 AF target position ........82 # X-Sync........148, 154 AF target settings ........81 # RC Mode ........170 AF tracking ..........92 0 (Protect) ........121...
  • Page 197 Compression rate ....98, 154, 186 Flash intensity control ......103 Computer ...........164 Flicker Reduction .......146 Connection Focus Bracketing .........69 Computer ........164 Focus mode .........92 Smartphone ........155 Focus ring ..........92 Connection Password......163 Format ..........144 Continuous AF ........92 Contrast ..........106 GPS log ..........162 Control Settings .........146 Gradation ...........108 Copyright Settings ......149...
  • Page 198 Keystone Compensation .....67 OI.Palette...........155 OI.Share ..........155 OI.Track ..........155 Language setting (W) .....143 Olympus Workspace .....2, 165 Level Adjust ........150 One-touch white balance (k) ..95, 112 Level gauge .........28 Light Trails ...........57 Live Bulb ........42, 147 P (Program mode) .......35 Live composite photography..44, 61...
  • Page 199 S (Shutter priority mode) .....39 Video Bit Rate ......99, 136 S-AF+MF (Single AF and Manual focus) Video Frame Rate .......99, 136 ............92 Video Menu .......136, 183 S-AF (Single AF)........92 Volume adjustment ......121 Saturation ..........106 SCN (Scene)........56 SD card..........167 WB .............148 Formatting the card ......144 White balance ........94 Self-portraits ........78...
  • Page 200 date of issue 2021.04 https://om-digitalsolutions.com/ 2021 WD807500...

Table of Contents
