- Page 1 PROGRAMMABLE DISPLAY WHA1 Series User's Manual WUME-WHA1-01 2020.12 panasonic.net/id/pidsx/global...
- Page 2 Copyright / Trademarks ・ This manual and its contents are copyrighted. ・ You may not copy this manual in whole or part, without written consent of Panasonic Industrial Devices SUNX Co., Ltd. ・ Windows is a registered trademark of Microsoft Corporation in the United States and other countries.
- Page 3 PROGRAMMABLE DISPLAY WHA1 Advanced Model Information Security Precautions When use this product you might receive damage as listed below. (1) Information leakage or outflow through this product (2) Fraudulent operation of this product by a malicious third party (3) Obstructing or stopping this product by a malicious third party Sufficient measures, including the following measures, should be taken at your own risk to prevent such damages.
- Page 4 Types of Manual ・ There are different types of user’s manual for the WHA1 series, as listed below. Please refer to a relevant manual for the unit and purpose of your use. ・ The manuals can be downloaded on our download center: https://industrial.panasonic.com/ac/j/dl_center/.
-
Page 5: Table Of Contents
PROGRAMMABLE DISPLAY WHA1 Advanced Model Table of Contents 1 System Configuration 1.1 WH series Advanced Model Main Unit 1.2 Screen Creating Tool 1.3 Remote monitoring Tool 2 Names and Functions of Parts 2.1.1 AWHA1C105 2.1.2 AWHA1C070, AWHA1C101, AWHA1C156, AWHA1C215 2.2 Wiring the Power Supply 2.3 Grounding 2.4 Serial Port 2.4.1 Wiring Example of Serial Port... - Page 6 PROGRAMMABLE DISPLAY WHA1 Advanced Model Before You Start ■ Usage conditions ・ Ambient temperatures: -20 to 50 °C ・ Ambient humidity should be 5 to 85% RH (at +25 °C and non-condensing.) ・ Usable altitude: 2000 m above sea level or lower ・...
- Page 7 PROGRAMMABLE DISPLAY WHA1 Advanced Model ■ LCD panel ・ Do not drop or have a strong impact on the programmable display unit as glass is used for the LCD panel. ・ The liquid in the LCD panel is a hazardous substance. If the LCD panel is broken, do not put the leaked crystalline liquid into your mouse.
-
Page 8: System Configuration
Studio xAscender Suite. You can download from our website. (https://www3.panasonic.biz/ac/e/index.jsp) (Member registration is necessary, free of charge.) (Notes) xAscender cannot start normally due to the computer management software used as a security measure. In that case, try starting xAscender with administrator privileges. In addition, exclude from the monitoring target by setting the whitelist etc. -
Page 9: Names And Functions Of Parts 2.1.1 Awha1C105
PROGRAMMABLE DISPLAY WHA1 Advanced Model 2 Names and Functions of Parts 2.1.1 AWHA1C105 Description SD Card Slot Do not use *Do not remove the protection seal on the rear. USB Port (1 Port) Ethernet Port 0 Ethernet Port 1 Power Serial Port 2.1.2 AWHA1C070, AWHA1C101, AWHA1C156, AWHA1C215 Description... -
Page 10: Wiring The Power Supply
PROGRAMMABLE DISPLAY WHA1 Advanced Model 2.2 Wiring the Power Supply Use an external 24 V DC power supply. Suitable wires Size Nominal cross sectional area Rated temperature Tightening torque AWG 24 to 14 0.2 to 2mm 105℃ or more 0.4 to 0.5 N･m (Note 1) If the power supply is incorrect, the internal electronic components may be damaged. -
Page 11: Grounding
PROGRAMMABLE DISPLAY WHA1 Advanced Model 2.3 Grounding Use dedicated grounding: ・ make the grounding point as close as possible to the GT and keep the distance of the grounding wire short. ・ sharing the ground with another device may have an adverse effect. Therefore, be sure that grounding is dedicated. -
Page 12: Wiring Example Of Serial Port
PROGRAMMABLE DISPLAY WHA1 Advanced Model 2.4.1 Wiring Example of Serial Port Use a loose wire for the connection on the PLC side. It can be used in combination with our PLC equipped with an adaptive interface. Serial Configuration RS-232C communication communication RS-422 /485... -
Page 13: Ethernet Port
PROGRAMMABLE DISPLAY WHA1 Advanced Model 2.5 Ethernet Port The Ethernet port have two LED indicators for status. Please see description below. Green Yellow Remarks No LAN cable connected BLINK Link at 100 Mbit/s BLINK Link at 10 Mbit/s 2.6 DISPOSE OF BATTERIES These devices are equipped with rechargeable Lithium battery, not user-replaceable. -
Page 14: Installation
PROGRAMMABLE DISPLAY WHA1 Advanced Model 3 Installation 3.1 Installation Environment In order to meet the front panel protection classifications, proper installation procedure must be followed: ・ the borders of the cutout must be flat ・ screw up each fixing screw until the plastic bezel corner get in contact with the panel. ・... -
Page 15: Specifications
PROGRAMMABLE DISPLAY WHA1 Advanced Model 4 Specifications 4.1.1 General Specifications Specifications Item AWHA1C050 AWHA1C070 AWHA1C101 AWHA1C156 AWHA1C215 Rated Voltage 24V DC Operating voltage range 10 to 32V DC (Note 1) Current rating (at 24VDC) 0.6A or less 0.7A or less 1A or less 1.2A or less 1.7A or less... -
Page 16: Performance Specifications
PROGRAMMABLE DISPLAY WHA1 Advanced Model 4.1.2 Performance Specifications Specifications Item AWHA1C050 AWHA1C070 AWHA1C101 AWHA1C156 AWHA1C215 TFT color LCD TFT color LCD TFT color LCD TFT color LCD TFT color LCD Display Unit 5.0 inch wide 7.0 inch wide 10.1 inch wide 15.6 inch wide 21.5 inch wide 800×480,... -
Page 17: Function Specifications
PROGRAMMABLE DISPLAY WHA1 Advanced Model 4.1.3 Function Specifications Item Specifications Fixed Font True Font Displayable fonts Fonts installed in windows (Note 2) Number of registerable screens (pages) Max. 1000 (Note 1) Pages: 1000 Dialog: 50 Registerable screen number Template: 50 Basic(text, numerics) Button Meter... -
Page 18: Interface
PROGRAMMABLE DISPLAY WHA1 Advanced Model 4.1.4 Interface ■ Serial Port Specifications Item RS-232C type RS-422 / RS-485 type Conforms to RS232C Conforms to RS-422 / RS-485 Communication standard (Non insulation type) (Non insulation type) Port number 1CH *software configurable 1200/2400/4800/9600/ 1200/2400/4800/9600/ Baud rate (bits/s) 19200/38400/57600/115200... - Page 19 PROGRAMMABLE DISPLAY WHA1 Advanced Model ■ Ethernet Port Specifications Item AWHA1C050 AWHA1C070 AWHA1C101 AWHA1C156 AWHA1C215 Port number Interface 100BASE-TX / 10BASET Baud rate (Note 1) 100Mbps / 10Mbps Connecter shape RJ-45 (Note 2) Cable total length 100m (500m when using a repeater) (Note3) Communication cable UTP cable (Category 5) Number of simultaneous...
- Page 20 PROGRAMMABLE DISPLAY WHA1 Advanced Model ■ SD memory card Item Specifications Support media SD memory card, SDHC memory card (Note 1) Conforms to SD standard. (Note2) Supported format standard (Please format with a format software for SD memory cards.) (Note 1) Industrial or business use SD memory cards (SLC type) are recommended. (Note 2) Check the operating temperature range of the SD memory card before use.
-
Page 21: Dimensions
PROGRAMMABLE DISPLAY WHA1 Advanced Model 4.2 Dimensions 4.2.1 AWHA1C050 Model No. 136mm/5.35” 96mm/3.78” AWHA1C050 Model No. 147mm/5.78” 107mm/4.21” 8mm/0.31” AWHA1C050 (52mm/2.04”) (Unit: mm, ”: inch) (Tolerance (except T): ±1mm) (T Tolerance: ±0.5mm) -
Page 22: Awha1C070, Awha1C101, Awha1C156, Awha1C215
PROGRAMMABLE DISPLAY WHA1 Advanced Model 4.2.1 AWHA1C070, AWHA1C101, AWHA1C156, AWHA1C215 Cut out Model No. 176mm/06.90” 136mm/05.35” AWHA1C070 271mm/10.66” AWHA1C101 186mm/07.32” 411mm/16.18” 256mm/10.00” AWHA1C156 541mm/21.30” 336mm/13.22” AWHA1C215 Model No. 187mm/07.36” 147mm/05.79” 8mm/0.31” AWHA1C070 (45mm/01.77”) 282mm/11.10” 197mm/07.75” 8mm/0.31” AWHA1C101 (52mm/02.04”) 267mm/10.50” 8mm/0.31” AWHA1C156 422mm/16.60”... -
Page 23: System Settings
PROGRAMMABLE DISPLAY WHA1 Advanced Model 5 System Settings For more information, refer to the xAscender Studio User's Manual (Basic). The products must be programmed with the software xAscender Studio. When the product is first started, the following image will be displayed. You need to install the xAscender HMI Runtime. - Page 24 PROGRAMMABLE DISPLAY WHA1 Advanced Model Update System Components The system components of the device can update locally using an USB memory key or remotely via web browser. To update system components enter System Settings in Config OS mode via tap-tap procedure on HMI or open web browser to https://<HMI-IP-address>/machine_config and select the “Management”...
- Page 25 PROGRAMMABLE DISPLAY WHA1 Advanced Model The products have a system settings interface to allow configuration of system options. The user interface of System Settings is based on HTML pages accessible from the HMI screen or remotely using a Web browser Chrome v44 or higher using port 443. To connect enter the address https://IP/machine_config where IP is the IP address of the HMI device.
- Page 26 PROGRAMMABLE DISPLAY WHA1 Advanced Model Activation of Systems Settings in System Mode: Normal operation: If xAscender HMI Runtime is not running: Press “System Setting” button on the HMI screen to enter in System Settings in User Mode. Select “Restart” -> “Config OS” to reboot in System Mode.
-
Page 27: Revision History
PROGRAMMABLE DISPLAY WHA1 Advanced Model Revision History Manual no. Date. Record of Changes WUME-WHA1-01 Dec.2020 1st edition... - Page 28 Please contact ..Panasonic Industrial Devices SUNX Co., Ltd. https://panasonic.net/id/pidsx/global Please visit our website for inquiries and about our sales network. © Panasonic Industrial Devices SUNX Co., Ltd. 2020 December, 2020 WUME-WHA1-01...
