- Page 1 PROGRAMMABLE DISPLAY WHS1 Series User's Manual WUME-WHS1-01 2020.12 panasonic.net/id/pidsx/global...
- Page 2 Copyright / Trademarks ・ This manual and its contents are copyrighted. ・ You may not copy this manual in whole or part, without written consent of Panasonic Industrial Devices SUNX Co., Ltd. ・ Windows is a registered trademark of Microsoft Corporation in the United States and other countries.
- Page 3 PROGRAMMABLE DISPLAY WHS1 Standard Model Information Security Precautions When use this product you might receive damage as listed below. (1) Information leakage or outflow through this product (2) Fraudulent operation of this product by a malicious third party (3) Obstructing or stopping this product by a malicious third party Sufficient measures, including the following measures, should be taken at your own risk to prevent such damages.
- Page 4 Types of Manual ・ There are different types of user’s manual for the WHS1 series, as listed below. Please refer to a relevant manual for the unit and purpose of your use. The manuals can be downloaded on our download center: https://industrial.panasonic.com/ac/e/dl_center/...
-
Page 5: Table Of Contents
PROGRAMMABLE DISPLAY WHS1 Standard Model Table of Contents 1 System Configuration 1.1 WHS1 Standard Model Main Unit 1.2 Screen Creating Tool 1.3 Remote monitoring Tool 2 Names and Functions of Parts 2.1 AWHS1R043, AWHS1R070, AWHS1R101 2.2 Wiring the Power Supply 2.3 Grounding 2.4 Serial Port 2.4.1 Wiring Example of Serial Port... - Page 6 PROGRAMMABLE DISPLAY WHS1 Standard Model Before You Start ■ Usage conditions ・ Ambient temperatures: 0 to +50 °C ・ Ambient humidity should be 5 to 85% RH (at +25 °C and non-condensing.) ・ Usable altitude: 2000 m above sea level or lower ・...
- Page 7 PROGRAMMABLE DISPLAY WHS1 Standard Model ■ LCD panel ・ Do not drop or have a strong impact on the programmable display unit as glass is used for the LCD panel. ・ The liquid in the LCD panel is a hazardous substance. If the LCD panel is broken, do not put the leaked crystalline liquid into your mouse.
-
Page 8: System Configuration
Studio xAscender Suite. You can download from our website. (https://www3.panasonic.biz/ac/e/index.jsp) (Member registration is necessary, free of charge.) (Notes) xAscender cannot start normally due to the computer management software used as a security measure. In that case, try starting xAscender with administrator privileges. In addition, exclude from the monitoring target by setting the whitelist etc. -
Page 9: Names And Functions Of Parts 2.1 Awhs1R043, Awhs1R070, Awhs1R101
PROGRAMMABLE DISPLAY WHS1 Standard Model 2 Names and Functions of Parts 2.1 AWHS1R043, AWHS1R070, AWHS1R101 Description Power Supply Serial Port (D-Sub 9 Pin) Ethernet Port USB Port 2.2 Wiring the Power Supply The power supply terminal block is shown in the figure below. ... -
Page 10: Grounding
PROGRAMMABLE DISPLAY WHS1 Standard Model The unit must always be grounded to earth with 1.5mmsq wire size minimum. The power supply circuit may be floating or grounded. In the latter case, connect to ground the power source common as shown in figure (see below) with a dashed line. When using the floating power scheme, note that the HMI devices internally connects the power common to ground with a 1MΩ... -
Page 11: Serial Port
PROGRAMMABLE DISPLAY WHS1 Standard Model 2.4 Serial Port The serial port is used to communicate with the PLC or with another type of controller. Standards available for the signals in the PLC port connector are: RS-232, RS-422, and RS-485. The serial port is software programmable. Make sure you select the appropriate interface in the programming software. -
Page 12: Ethernet Port
PROGRAMMABLE DISPLAY WHS1 Standard Model RS-232C Communication PLC RS-232C port WHS1 Standard Model Fanction Signal name Pin No. Pin name PLC RS-232C port WHS1 Standard Model Send data PLC RS-232C port WHS1 Standard Model Fanction Signal name Pin No. Pin name Receive data Fanction... -
Page 13: Installation
PROGRAMMABLE DISPLAY WHS1 Standard Model 3 Installation 3.1 Installation Environment In order to meet the front panel protection classifications, proper installation procedure must be followed: ・ the borders of the cutout must be flat ・ screw up each fixing screw until the plastic bezel corner get in contact with the panel. ・... -
Page 14: Specifications
PROGRAMMABLE DISPLAY WHS1 Standard Model 4 Specifications 4.1.1 General Specifications Specifications Item AWHS1R043 AWHS1R070 AWHS1R101 Rated Voltage 24V DC Operating voltage range 10 to 32V DC Current rating (at 24VDC) 0.25A or less 0.3A or less 0.38A or less Ambient temperature 0 to +50℃... -
Page 15: Performance Specifications
PROGRAMMABLE DISPLAY WHS1 Standard Model 4.1.2 Performance Specifications Specifications Item AWHS1R043 AWHS1R070 AWHS1R101 TFT color LCD TFT color LCD TFT color LCD Display Unit 4.3 inch wide 7.0 inch wide 10.1 inch wide 480X272, 800X480, 1024X600, Resolution WQVGA WVGA Colors 65,536 colors Display Backlight... -
Page 16: Function Specifications
PROGRAMMABLE DISPLAY WHS1 Standard Model 4.1.3 Function Specifications Item Specifications Fixed Font True Font Displayable fonts Fonts installed in windows (Note 2) Number of registerable screens (pages) Max. 1000 (Note 1) Pages: 1000 Dialog: 50 Registerable screen number Template: 50 Basic(text, numerics) Button Meter... -
Page 17: Interface
PROGRAMMABLE DISPLAY WHS1 Standard Model 4.1.4 Interface ■ Serial Port Specifications Item RS-232C type RS422 / RS485 type Conforms to RS-232C Conforms to RS-422 /RS-485 Communication standard (Non insulation type) (Non insulation type) Port number 1CH *software configurable 1200/2400/4800/9600/ 1200/2400/4800/9600/ Baud rate (bits/s) 19200/38400/57600/115200 19200/38400/57600/115200... - Page 18 PROGRAMMABLE DISPLAY WHS1 Standard Model ■ Ethernet Port Item Specifications Port number Interface 100BASE-TX / 10BASET Baud rate 100Mbps / 10Mbps (Note 1) Connecter shape RJ-45 (Note 2) Cable total length 100m (500m when using a repeater) (Note 3) Communication cable UTP cable (Category 5) Number of simultaneous connections Max.
-
Page 19: Dimensions
PROGRAMMABLE DISPLAY WHS1 Standard Model 4.2 Dimensions Model No. AWHS1R043 136mm/05.35” 96mm/03.78” AWHS1R070 176mm/06.90” 136mm/05.35” AWHS1R101 271mm/10.66” 186mm/07.32” Model No. AWHS1R043 147mm/05.78” 107mm/04.21” 29mm/01.14” 5mm/00.19” AWHS1R070 187mm/07.36” 147mm/05.79” 29mm/01.14” 5mm/00.19” AWHS1R101 282mm/11.10” 197mm/07.75” 28mm/01.10” 6mm/00.23” (Unit: mm, ”: inch) (Tolerance (except T): ±1mm) (T Tolerance: ±0.5mm) -
Page 20: System Settings
PROGRAMMABLE DISPLAY WHS1 Standard Model 5 System Settings For more information, refer to the xAscender Studio User's Manual (Basic). The products must be programmed with the software xAscender Studio. When the product is first started, the following image will be displayed. You need to install the xAscender HMI Runtime. - Page 21 PROGRAMMABLE DISPLAY WHS1 Standard Model Update System Components The system components of the device can update locally using an USB memory key or remotely via web browser. To update system components enter System Settings in Config OS mode via tap-tap procedure on HMI or open web browser to https://<HMI-IP-address>/machine_config and select the “Management”...
- Page 22 PROGRAMMABLE DISPLAY WHS1 Standard Model The products have a system settings interface to allow configuration of system options. The user interface of System Settings is based on HTML pages accessible from the HMI screen or remotely using a Web browser Chrome v44 or higher using port 443. To connect enter the address https://IP/machine_config where IP is the IP address of the HMI device.
- Page 23 PROGRAMMABLE DISPLAY WHS1 Standard Model Activation of Systems Settings in System Mode: Normal operation: If xAscender HMI Runtime is not running: Press “System Setting” button on the HMI screen to enter in System Settings in User Mode. Select “Restart” -> “Config OS” to reboot in System Mode.
-
Page 24: Revision History
PROGRAMMABLE DISPLAY WHS1 Standard Model Revision History Manual no. Date. Record of Changes WUME-WHS1-01 Sep.2020 1st edition... - Page 25 Please contact ..Panasonic Industrial Devices SUNX Co., Ltd. https://panasonic.net/id/pidsx/global Please visit our website for inquiries and about our sales network. © Panasonic Industrial Devices SUNX Co., Ltd. 2020 December, 2020 WUME-WHS1-01...
