A. Using the 35mm Slide Template
To scan 35mm slides, use the 35mm Slide Template, which can hold up to 4 mounted
35mm slides at a time.
1. Place the 35mm Slide Template on the scanner glass surface. Make sure to orient
the template with the "Microtek" logo facing up.
Calibration strip
Microtek logo
2. Place the 35mm slides to be scanned inside the individual frames of the 35mm
Slide Template. The shiny base of the 35mm slide should be facing down, and
the emulsion side of the slide should be facing up.
The Grabber is used to remove the
template out of the scanner glass
surface.
Important: Align the template's front
corners firmly against the top corners
(left and right) of the
U-shaped ruler located at the front
of the scanner. During placement
of the template, make sure that the
calibration strip on the scanner glass
surface is kept clear and free of
obstruction at all times.
Align the 35mm slide against the
bottom-left corner of the frame
ScanMaker 1000XL Plus User Guide 11
