Summary of Contents for Daewoo TORNADO FREEDOM FLR00044
-
Page 2: Important Safeguards
Tornado Cordless 2in1 Vacuum FLR00044 User Manual IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed. These instructions should be saved for future reference: • Read and familiarise yourself with all operating instructions before using this Vacuum Cleaner. •... - Page 3 Tornado Cordless 2in1 Vacuum FLR00044 User Manual • If the power cable is damaged, it should only be replaced by the manufacturer or a suitable qualified after-sales-service in order to avoid a hazard • Allow the unit to cool before storage. •...
- Page 4 Tornado Cordless 2in1 Vacuum FLR00044 User Manual Description of parts 1. Upright vacuum ON/OFF switch. 2. Speed button 3. Handheld vacuum release button. 4. Handheld vacuum ON/OFFswitch. 5. ON/OFF/charge level indicator 6. Dust cylinder release button. 7. Upright brush head. 8.
- Page 5 Tornado Cordless 2in1 Vacuum FLR00044 User Manual Assembly 1. Fit the handle onto the main body of the vacuum and secure into place by fixing the screw provid- ed into the hole at the rear of the handle. 2. Fit the main body of the vacuum onto the brush head and push home until it clicks into place, then fix the two screws provided into the...
- Page 6 Tornado Cordless 2in1 Vacuum FLR00044 User Manual Charging 1. Plug the power supply jack into the rear of the charging dock and the plug into a suitable socket outlet. 2. Mount the vacuum on the base by aligning the vacuum with the charging mount (12) on the charging dock (11) and allow to drop into place.
- Page 7 Tornado Cordless 2in1 Vacuum FLR00044 User Manual Technical Data Power pack Li-ion battery 22.2V (6x3.7V cells) Battery Capacity 2200mAh Running time 20 mins (high speed), 40 mins (low speed) Power 120W Power supply Input 100-240V 50Hz, 0.5A, 120.0W Output 27.0V DC, 500mA Waste electrical products should not be disposed of with household waste.
-
Page 8: Troubleshooting Guide
Troubleshooting guide Problem Possible reason Solution Motor does not operate • Battery is low on power • Charge the battery • The hand held vacuum • Correctly fit the is not fitted to the main handheld unit to the body. (Power to the main body of the brush head is supplied vacuum... -
Page 9: Warranty
As part of our commitment to quality we are o ering you an extra 2 years warranty in addition to your 1 year guarantee. Your Daewoo vacuum product is guaranteed for 1 year from the date of original purchase, with proof of purchase or receipt. If any defects should arise due to faulty workmanship or material, your faulty vacuum should be returned to the place of purchase, replacement or refund is at the discretion of the retailer.
