Omron V600 RFID System Operation Manual page 21

I/O Specifications
Wiring Examples of I/O
Devices
PLC output unit
(C200H-OD211,
C500-OD412, etc.)
NPN transistor output
open-collector type
(3-line sensor, etc.)
Contact type
(pushbutton
switch, etc.)
PLC input unit
(C200H-ID212,
C500-ID218, etc.)
Relay
Note Use the bi-directional Input Unit on the PC.
COM
+V
OUT
RESET
OV(COM)
+
V TRIG
Output
OV
IN1
+
24 VDC
Power
supply
IN2
COM
RUN
IN
CMPL
IN
OUT1
OUT2
+
24
VDC
Power supply
Section 2-3
ID Controller input circuitry
2.2 kΩ
2.2 kΩ
2.2 kΩ
2.2 kΩ
ID Controller output circuitry
11
