ATEN Secure KVM User Manual EMC Information FEDERAL COMMUNICATIONS COMMISSION STATEMENT: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: China Rohs
ATEN Secure KVM User Manual China RoHS... -
Page 4: User Information
ATEN Secure KVM User Manual User Information Online Registration Be sure to register your product at our online support center: https://eservice.aten.com/eServiceCx/Common/productRegister.do Telephone Support For telephone support, call this number: International +886-2-8692-6959 China +86-10-5255-0110 Japan +81-3-5615-5811 Korea +82-2-467-6789 North America +1-888-999-ATEN ext 4988... -
Page 5: Package Contents
© Copyright 2011–2017 ATEN® International Co., Ltd. Manual Version: v1.03 Manual Date: 2021-1-25 ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved. All other brand names and trademarks are the registered property of their respective owners. -
Page 6: Table Of Contents
Cables ..........................4 Operating Systems ......................5 Components ........................6 Front View (of ATEN Secure KVM Switch) ..............6 Rear View (of ATEN Secure KVM Switch) ..............7 Front View (of ATEN Remote Port Selector) ..............11 Chapter 2 ..........................13 Hardware Setup ........................ - Page 7 ATEN Secure KVM User Manual LED Display ........................20 Chassis Intrusion Detection .................... 22 Smart Card and CAC Reader ..................22 Appendix ..........................23 Safety Instructions ......................23 General ..........................23 Consignes de Sécurité ..................... 25 Général ..........................25 Technical Support ......................27 International ........................
-
Page 8: About This Manual
This user manual is intended for system administrators and end users. This user manual is provided to help you get the most from your ATEN Secure KVM Switch system. It covers all aspects of installation, configuration and operation. An overview of the information found in the manual is provided below. -
Page 9: Overview
ATEN Secure KVM User Manual Overview Chapter 1, Introduction, introduces you to the ATEN Secure KVM Switch system. Its purpose, features and benefits are presented, and its front and back panel components are described. Chapter 2, Hardware Setup, provides step-by-step instructions for setting up your installation. -
Page 10: Conventions
Product Information For information about all ATEN products and how they can help you connect without limits, visit ATEN on the Web or contact an ATEN Authorized Reseller. Visit ATEN on the Web for a list of locations and telephone numbers: International https://www.aten.com/global/en/... - Page 11 ATEN Secure KVM User Manual This Page Intentionally Left Blank...
-
Page 12: Chapter 1
By combining physical security with controlled USB connectivity and controlled unidirectional data flow from devices to connected computers only, the ATEN Secure KVM Switch series offers you the means to consolidate multiple workstations of various security classification levels with one keyboard, monitor and mouse (KVM) console. -
Page 13: Features
ATEN Secure KVM User Manual Features FEATURES BENEFITS 2/4/8-Port USB DVI/HDMI/DisplayPort Reduces the costs involved in controlling up to 8 ■ Single/Dual Display Secure KVM Switch* Single/Dual Display computers while offering data isolation between shared peripherals and computers Superior ultra high video resolution up to Supports resolutions up to 3840 x 2160 @ 60Hz with ■... - Page 14 ATEN DVI-to-HDMI KVM cables. *** Remote Port Selector is not supplied in the package and requires a separate purchase **** Only analogue speaker data input is supported. The ATEN Secure KVM Switch does not convert digital audio to analogue audio.
-
Page 15: Requirements
ATEN Secure KVM User Manual Requirements Console DVI (for DVI-interfaced Secure KVM), HDMI (for HDMI interfaced Secure KVM), or DisplayPort (for DisplayPort-interfaced Secure KVM) monitor capable of the highest resolution that you will be using on any computer in the installation... -
Page 16: Operating Systems
ATEN Secure KVM User Manual Operating Systems Suggested operating systems are shown in the table, below: Note: Supports Linux Kernel 2.6 and higher. -
Page 17: Components
ATEN Secure KVM User Manual Components Front View (of ATEN Secure KVM Switch) CS1188D4C CS1142H4 CS1184DP4C... -
Page 18: Rear View (Of Aten Secure Kvm Switch)
Rear View (of ATEN Secure KVM Switch) CS1188D4C CS1142H4 CS1184DP4C Note: This user manual uses CS1188D4C, CS1142H4, CS1184DP4C to demonstrate each interface (DVI/HDMI/DisplayPort), port number (2/4/8- Port), CAC support (Yes/No), and number of displays (single/dual) supported by the ATEN Secure KVM Switch. - Page 19 Port and CAC LEDs also indicate the status of the Secure KVM self-test status. See Operation section for further details Press this button to reset the ATEN Secure KVM Switch. Note: When you perform a reset by pressing the reset button for more than 5...
- Page 20 Note: The Scroll Lock LED on the keyboard will be disabled due to security requirements. Lights green to indicate that the ATEN Secure KVM Switch is powered Power LED The USB keyboard and mouse plug into these ports. The USB console keyboard port (lower port) and mouse port (upper port) support the following –...
- Page 21 The USB cable that attaches to your computer's USB Smart Card / (Common Access Card) CAC reader plugs in here. Reader Port This is a standard rocker switch that powers the ATEN Secure KVM Power Switch Switch on and off. Power Socket...
-
Page 22: Front View (Of Aten Remote Port Selector)
ATEN Secure KVM User Manual Front View (of ATEN Remote Port Selector) Component Description Pressing a Port Selection Pushbutton brings together the keyboard, mouse, video, audio, and CAC reader focus to the computer attached to its corresponding port. Note: Port Selection... - Page 23 ATEN Secure KVM User Manual security requirements. Lights green to indicate the Scroll Lock function has been turned on. Scroll Lock LED Note: The Scroll Lock LED on the keyboard will be disabled due to security requirements. The CAC LED is located on the far right of the upper bar (on the panel) to indicate CAC reader selection status.
-
Page 24: Chapter 2
ATEN dealer. The ATEN Secure KVM Switch and ATEN RPS are equipped with active always-on chassis intrusion detection: If a mechanical intrusion is detected on the switch, the switch (without RPS connected) will be permanently disabled and all the front panel LEDs (except the Power LED) will flash continuously. - Page 25 13. Any cable connector or non-ATEN remote controller plugged into the console RPS port will be ignored. Secure Installation Do not attempt to connect or install the following devices to the computers connected to the ATEN Secure KVM Switch: TEMPEST computers; telecommunication equipment; frame grabber video cards; or special audio processing cards.
-
Page 26: Stacking
Installation To set up your ATEN Secure KVM Switch installation, refer to the installation diagram on page 18 (the numbers in the diagrams correspond to the steps below), and do the following: Plug your USB keyboard and USB mouse into the USB console ports located on the unit’s rear panel. - Page 27 Plug your console monitor(s) into the console video port(s) located on the unit’s rear panel and power on the monitor. Note: When the ATEN Secure KVM Switch is powered on, the Video LED lights green when the video connection is up and running. The Video LED flashes when a non-qualified monitor is connected.
- Page 28 Any connection of RPS after the ATEN Secure KVM Switch is powered-on will not be detected by the switch. Plug the female end of the power cord into the ATEN Secure KVM Switch power socket; plug the male end into an AC power source.
-
Page 29: Installation Diagram
ATEN Secure KVM User Manual Installation Diagram Rear View Front View... -
Page 30: Chapter 3
Chapter 3 Operation Powering On When you power on, reset, or power cycle the ATEN Secure KVM Switch, the switch will perform a self-test to check the unit’s integrity and security functions. During the self-test All Port LEDs, all CAC LEDs (if supported), Num Lock LED, Caps Lock LED, and Scroll Lock LED on the Secure KVM will turn ON and then OFF. -
Page 31: Manual Switching
Port ID Numbering Each KVM port on the ATEN Secure KVM Switch is assigned a port number (1–2 for the 2-Port models; 1–4 for the 4-Port models; 1–8 for the 8-Port models). The port numbers are marked on the rear of the switch. - Page 32 ATEN Secure KVM User Manual Indication Power LED The Power LED is on the front panel and lights green to indicate that (on the Secure KVM switch) the KVM switch is powered on. The Video LED is located on the back panel next to each video connector.
-
Page 33: Chassis Intrusion Detection
RPS) Chassis Intrusion Detection To help prevent malicious tampering with the ATEN Secure KVM Switch, the switch (or the RPS) becomes inoperable and all front panel LEDs on the Secure KVM switch (except Power) or all Remote Port Selector (RPS) LEDs flash constantly when a chassis intrusion (such as the cover being removed) is detected (by the switch or by the RPS). -
Page 34: Appendix
ATEN Secure KVM User Manual Appendix Safety Instructions General This product is for indoor use only. Read all of these instructions. Save them for future reference. Follow all warnings and instructions marked on the device. Do not place the device on any unstable surface (cart, stand, table, etc.). If the device falls, serious damage will result. - Page 35 ATEN Secure KVM User Manual points or short out parts resulting in a risk of fire or electrical shock. Do not attempt to service the device yourself. Refer all servicing to qualified service personnel. If the following conditions occur, unplug the device from the wall outlet and bring it to qualified service personnel for repair.
-
Page 36: Consignes De Sécurité
ATEN Secure KVM User Manual Consignes de Sécurité Général Ce produit est destiné exclusivement à une utilisation à l’intérieur. Veuillez lire la totalité de ces instructions. Conservez-les afin de pouvoir vous y référer ultérieurement. Respectez l’ensemble des avertissements et instructions inscrits sur l’appareil. - Page 37 ATEN Secure KVM User Manual pas 15 Ampères. Pour contribuer à protéger votre système contre les augmentations et diminutions soudaines et transitoires de puissance électrique, utilisez un parasurtenseur, un filtre de ligne ou un système d’alimentation sans coupure (UPS). Placez les câbles du système et les câbles d’alimentation avec précaution ; veillez à ce que rien ne repose sur aucun des câbles.
-
Page 38: Technical Support
ATEN Secure KVM User Manual Technical Support International For online technical support – including troubleshooting and documentation: http://eservice.aten.com For telephone support, See Telephone Support, page iv: North America Email Support support@aten-usa.com Online Troubleshooting https://eservice.aten.com/eServiceCx/supportIndex.do?lang Technical Documentation =en_US Support Software Updates... -
Page 39: Specifications
ATEN Secure KVM User Manual Specifications ATEN Single Display DisplayPort Secure KVM (CAC and Non-CAC models) Function CS1182DP4C CS1184DP4C CS1188DP4C CS1182DP4 CS1184DP4 CS1188DP4 Computer Direct Connections Max. Console Connections 1 Direct 1 Direct Port Selection Pushbutton, Remote Port Selector Pushbutton, Remote Port Selector... - Page 40 335 x 164 x 432 x 205 x (L x W x H) 44 mm 44 mm 66 mm 44 mm 44 mm 66 mm ATEN Dual Display DisplayPort Secure KVM (CAC and Non-CAC models) Function CS1142DP4C CS1144DP4C CS1148DP4C CS1142DP4 CS1144DP4 CS1148DP4 Computer...
- Page 41 335 x 164 x 432 x 205 x (L x W x H) 66 mm 66 mm 66 mm 66 mm 66 mm 66 mm ATEN Single Display HDMI Secure KVM (CAC and Non-CAC models) Function CS1182H4C CS1184H4C CS1182H4 CS1184H4 Computer Direct Connections Max.
- Page 42 335 x 164 x 44 mm 335 x 164 x 44 mm 335 x 164 x 44 mm 335 x 164 x 44 mm (L x W x H) ATEN Dual Display HDMI Secure KVM (CAC and Non-CAC models) Function CS1142H4C CS1144H4C CS1142H4...
- Page 43 335 x 164 x 66 mm 335 x 164 x 66 mm 335 x 164 x 66 mm 335 x 164 x 66 mm (L x W x H) ATEN Single Display DVI Secure KVM (CAC and Non-CAC models) Function CS1182D4C CS1184D4C CS1188D4C...
- Page 44 44 mm 44 mm 66 mm * DVI Secure KVM Switches offer 3840 x 2160 @ 30 Hz video output on compatible HDMI-interfaced monitors/computers with ATEN DVI-to-HDMI KVM cables ATEN Dual Display DVI Secure KVM (CAC and Non-CAC models) Function...
- Page 45 ATEN Secure KVM User Manual Connections Max. Console Connections 1 Direct 1 Direct Port Selection Pushbutton, Remote Port Selector Pushbutton, Remote Port Selector Keyboard 1 x USB Type A Female 1 x USB Type A Female Video 2 x DVI-I DL Female...
-
Page 46: Limited Warranty
66 mm 66 mm 66 mm * DVI Secure KVM Switches offer 3840 x 2160 @ 30 Hz video output on compatible HDMI-interfaced monitors/computers with ATEN DVI-to-HDMI KVM cables Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED THE PRICE PAID FOR...
