- Page 1 Two-Port DVI KVM Switch USER MANUAL CS-1262...
-
Page 2: Fcc Information
FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instruction manual, may cause interference to radio communications. -
Page 3: Online Registration
You can register your product at our online support center: International – http://support.aten.com North America – http://www.aten-usa.com/ product_registration Online Support Online technical support is available to ATEN customers through our support center: International – http://support.aten.com North America – http://www.aten-usa.com/support. Troubleshooting, Documentation (including online manuals),... -
Page 4: Package Contents
Copyright © 2004 - 2007 ATEN International Co., Ltd. Manual Part No. PAPE-1259-200G Printing Date: 09/2007 ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. - 4 -... - Page 5 (traditional monitors and TVs). The CS-1262 is audio enabled. A single microphone can provide audio input to each of the computers, and you can listen to the audio output of each computer on a single set of speakers (on a one-at-a-time basis).
- Page 6 Features One console controls two computers DVI digital and analog monitor support – fully compliant with the DVI specification Audio enabled Easy to install – no software required – connecting cables to the computers is all it takes Easy to operate – manual and hotkey computer selection - Auto Scan function to monitor computer operation The KVM and audio focus can be switched together or separately (asynchronous switching)
- Page 7 Requirements Console A DVI monitor A PS/2 mouse A PS/2 keyboard Computers The following equipment must be installed on each computer that is to be connected to the system: A DVI video port A 6-pin mini-DIN (PS/2 style) mouse port A 6-pin mini-DIN (PS/2 style) keyboard port Cables Only CS Custom cable sets specifically designed to work with this...
-
Page 8: Front Panel
Components Front Panel 1&2 Component Description Port Selection Press a pushbutton to bring the KVM and Pushbuttons Audio focus to the computer attached to its respective port. Port LEDs The Port LEDs are built into the Port Selection Pushbuttons. The upper ones are the On Line LEDs;... -
Page 9: Rear Panel
Rear Panel Component Description Console Port The cables from your keyboard, monitor, Section mouse, microphone, and speakers plug in here. Each port is color coded and marked with an appropriate icon. KVM Port The cables that link the switch to your Section computers plug inhere. -
Page 10: Installation
Installation 1. Make sure that the power to all the devices you will be installing has been turned off. You must unplug the power cords of any computers that have the Keyboard Power On function. 2. Make sure that all devices you will be installing are properly grounded. - Page 11 4. Plug the power adapter that came with your switch into an AC power source, then plug power adapter cable into the switch’s Power Jack. - 11 -...
-
Page 12: Operation
3. Wait 10 seconds, then plug the switch’s power adapter cable back in. 4. After the switch is up, Power On the computers. The Beeper The CS-1262 beeps to provide information about its operations as follows: Beeps Meaning Manual port changes... -
Page 13: Port Switching
Port Switching There are two convenient methods to switch the KVM and Audio focus between the computers: Manual – which involves pressing the port selection pushbuttons located on the unit’s front panel; and Hotkey – which involves entering combinations from the keyboard. - Page 14 Auto Scanning: The CS-1262’s Auto Scan feature automatically switches the KVM focus between the two computer ports at regular intervals. This allows you to monitor the computer activity without having to take the trouble of switching from port to port manually. See the table below for details.:...
-
Page 15: Hotkey Summary Table
Hotkey Summary Table [Scroll Lock] [Scroll Lock] Switches the KVM and audio focus from the [Enter] port that currently has the KVM focus to the other port(1 to 2; 2 to 1). Note: The KVM and audio focus both go to this port even if they were on different ports to begin with. -
Page 16: Dvi Pin Assignments
Appendix DVI Pin Assignments Signal Signal TMDS Data2- Hot Plug Detect TMDS Data2+ TMDS Data0- TMDS Data0+ N.C. N.C. N.C. DDC Clock N.C. DDC Data TMDS Clock Shield Analog Vertical Sync. TMDS Clock+ TMDS Data1- TMDS Clock- TMDS Data1+ Analog Red Analog Green N.C. -
Page 17: Specifications
Specifications Function Specification Computer Connections Port Selection Hotkey; Pushbuttons Connectors Console Keyboard 1 x 6-pin Mini-DIN Female (Purple) Ports Video 1 x DVI I Female (White) Mouse 1 x 6-pin Mini-DIN Female (Green) Speaker 1 x Mini Stereo Jack (Green) Microphone 1 x Mini Stereo Jack (Pink) Keyboard... -
Page 18: Limited Warranty
Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT FROM THE DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK OR ITS DOCUMENTATION. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and specially disclaims its quality, performance, merchantability, or fitness for any particular purpose.
