All manuals and user guides at all-guides.com HS-PX607 AH,YH,AE SERVICE MANUAL STEREO BASIC TAPE MECHANISM : 7ZM-1 P3NF CASSETTE PLAYER • This Service Manual is the "Revision Publishing" and replaces "Simple Manual" (S/M Code No. 09-004-432-4T1). S/M Code No. 09-006-432-4R1...
All manuals and user guides at all-guides.com SPECIFICATIONS Maximum output: 4 mW + 4 mW (EIAJ 32 ohms)<AH,YH> 4 mW + 4 mW (EIAJ 16 ohms)<AE> Power sources: DC 1.2 V using supplied rechargeable battery NB-5G, DC 1.5 V using R6 (size AA) dry cell battery, AC house current using the optional AC adaptor Maximum dimensions: 79.1 (W) x 110 (H) x 20.8 (D) mm (excluding projecting parts and controls)
All manuals and user guides at all-guides.com ELECTRICAL MAIN PARTS LIST REF. PART NO. KANRI DESCRIPTION REF. PART NO. KANRI DESCRIPTION C201 87-016-526-080 C-CAP,S 0.47-16 BK<AE> C202 87-012-274-080 CHIP CAP,U 1000P-50B<AE> 87-A21-179-040 C-IC,TA2123AF C203 87-A11-733-080 C-CAP,S 1-16 Z F<AE> 87-A20-818-040 C-IC,NJM2185AV<AE>...
All manuals and user guides at all-guides.com CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code Value of resistor Chip resistor Dimensions (mm) Symbol Wattage Type Tolerance Resistor Code Form 1/16W 1005 0.35 1/16W 1608 0.45 1/10W 2125 1.25 0.45 1/8W...
Page 5
All manuals and user guides at all-guides.com WIRING - 5 -...
Page 6
All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM - 6 -...
Page 7
All manuals and user guides at all-guides.com IC BLOCK DIAGRAM - 7 -...
Page 8
All manuals and user guides at all-guides.com IC DESCRIPTION IC, ML63512A – A03 Pin No. Pin Name Description AF IN Sound detection input terminal. S C L K Serial clock input terminal. M U T E H : MUTE OFF L : MUTE ON S D A T A Serial data output terminal.
Page 9
All manuals and user guides at all-guides.com Pin No. Pin Name Description HI – S P L H : HI-SP L level L : HI-SP H level POWER ON H : POWER ON L : POWER OFF DSL 1 Output ON when in DSL 1 mode. DSL ON Output ON when in DSL ON mode.
Page 10
All manuals and user guides at all-guides.com ADJUSTMENT MAIN C.B J101 VOLUME PHONES VR101 (RCH) TP1(LCH) (GND) SFR301 1. Dolby Level Adjustment <AE> 2. Tape Speed Adjustment Setting : • Test tape : TTA – 200 Settings : • Test tape : TTA –...
All manuals and user guides at all-guides.com TAPE MECHANISM PARTS LIST 1 / 1 REF. PART NO. KANRI DESCRIPTION REF. PART NO. KANRI DESCRIPTION 87-ZM1-230-010 HLDR,HEAD 87-ZM1-265-010 HLDR,CAM 87-ZM1-254-110 ARM ASSY,PINCH R 87-ZM1-261-010 LEVER,SW 87-ZM1-287-010 SPR-T,PINCH BACK R 87-ZM1-250-210 FLY-WHL ASSY,R 87-ZM1-285-010 SPR-T,PINCH R 87-ZM1-272-010...
All manuals and user guides at all-guides.com ACCESSORIES / PACKAGE LIST REF. PART NO. KANRI DESCRIPTION REF. PART NO. KANRI DESCRIPTION 8A-HK5-902-010 IB,H(ECC) S<AH> 8A-HK5-903-010 IB,YHS(EC)S<YH> 8A-HK5-905-010 IB,E(EGFSI)S<AE> 8A-HK5-906-010 IB,E(EDPHNCZ)S<AE> 8A-HK5-951-010 RC UNIT,RC607 87-B30-390-010 HEADPHONE,HP-M041(S)S 87-B30-298-010 BAT,NB-5G(S) 87-B30-083-010 CHARGER,RB-107 E<AE> 8Z-HK4-090-010 BOX,BAT ASSY SIL 82-HK3-951-010...
Page 16
All manuals and user guides at all-guides.com 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9630469 0251431 Printed in Singapore...
