This Service Manual contains information about the difference between HS-PX607(YHS1LF) and HS-PX607(YH). If requiring other information, see Service Manual of HS-PX607(AH,YH,AE), (S/M Code No. 09-006-432-4R1). This Service Manual is for HS-px607 (YHS1LF) blue color. S/M Code No. 09-008-432-4S1...
DC 1.2 V using supplied rechargeable battery NB-5G, DC 1.5 V using R6 (size AA) dry cell battery, AC house current using the optional AC adaptor Aiwa AC-D302 Maximum dimensions: 79.1 (W) x 110 (H) x 20.8 (D) mm (excluding projecting parts and controls) in.)
Page 3
ADJUSTMENT 2. Tape Speed Adjustment Settings : Test tape : TTA - 100 (TAPE CENTER) Test point : PHONES JACK (J101) Adjustment location : SFR301 PAUSE : OFF DSL : OFF TAPE selector : NORMAL (AUTO) ...
