http://www.xiaoyu163.com SPECIFICATIONS 3 7 63 1515 0 Maximum output: 4 mW + 4 mW (EIAJ 32 ohms)<AH,YH> 4 mW + 4 mW (EIAJ 16 ohms)<AE> Power sources: DC 1.2 V using supplied rechargeable battery NB-5G, DC 1.5 V using R6 (size AA) dry cell battery, AC house current using the optional AC adaptor Maximum dimensions: 79.1 (W) x 110 (H) x 20.8 (D) mm (excluding projecting parts and controls)
http://www.xiaoyu163.com IC BLOCK DIAGRAM 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 - 7 - http://www.xiaoyu163.com...
Page 8
http://www.xiaoyu163.com IC DESCRIPTION 3 7 63 1515 0 IC, ML63512A – A03 Pin No. Pin Name Description AF IN Sound detection input terminal. S C L K Serial clock input terminal. M U T E H : MUTE OFF L : MUTE ON S D A T A Serial data output terminal.
Page 9
http://www.xiaoyu163.com Pin No. Pin Name Description 3 7 63 1515 0 HI – S P L H : HI-SP L level L : HI-SP H level POWER ON H : POWER ON L : POWER OFF DSL 1 Output ON when in DSL 1 mode. DSL ON Output ON when in DSL ON mode.
http://www.xiaoyu163.com TAPE MECHANISM PARTS LIST 1 / 1 3 7 63 1515 0 REF. PART NO. KANRI DESCRIPTION REF. PART NO. KANRI DESCRIPTION 87-ZM1-230-010 HLDR,HEAD 87-ZM1-265-010 HLDR,CAM 87-ZM1-254-110 ARM ASSY,PINCH R 87-ZM1-261-010 LEVER,SW 87-ZM1-287-010 SPR-T,PINCH BACK R 87-ZM1-250-210 FLY-WHL ASSY,R 87-ZM1-285-010 SPR-T,PINCH R 87-ZM1-272-010...
