Installing the Gateway

•
•
•
•
•
Installing the Gateway
This section provides instructions for installing the IG21, IG21R, and IG31R gateways. The following table
describes the installation options.
Table 2: Gateway Installation Options
Option
Mounting on a DIN rail
Mounting on a flat vertical surface
using mounting brackets
Mounting on a flat vertical surface
using keyholes on the back of the
gateway
Mounting on a flat horizontal
surface
Install the gateways in an area in which structures, trees, or hills do not obstruct radio signals to and from the
devices.
Cisco IG21 IoT Gateways, Cisco IG21R Rugged IoT Gateways, and Cisco IG31R Rugged IoT Gateways Hardware Installation Guide
Installing the Gateway, on page 19
Mounting Kits Contents, on page 20
DIN Rail Mounting, on page 20
Surface Mounting with Wall Brackets, on page 25
Surface Mounting with Keyholes, on page 27
C H A P T E R
Supported Devices
IG21
IG21R
IG31R
IG21
IG21R
IG31R
IG21
IG21
3
Notes
See DIN Rail Mounting, on page
20
See Surface Mounting with Wall
Brackets, on page 25
See Surface Mounting with
Keyholes
The IG21 can be placed on a flat
horizontal surface such as a desk
19
