IR510 WPAN Gateway and IR530 WPAN
Range Extender Hardware Installation Guide
First Published:
2018-06-26
Organization
This guide includes the following sections:
Conventions, page 2
Preface, page 2
IR510 Installation, page 3
page 16
Configuring IR510 and IR530 Systems, page 26
Related Documentation, page 26
Details on style conventions used in the guide.
Provides a general overview of the IR510 and IR530 products. It also
provides important site preparation and safety measures to follow before
installing the system.s
Provides hardware and software specifications, lists Cautions and Warnings
to note before physically installing the systems. Provides steps for
unpacking the system and physically installing the system; and details on
how to monitor the systems (such as LEDs).
Provides details on configuring and monitoring system. Includes CLI
commands and links to the IoT Field Network Director User Guides that
provides management options for the IR510 platform.
Provides links to related Cisco products that the IR510 and IR530 can be
connected to or managed by.
Cisco Systems, Inc.
www.cisco.com
1
Advertisement
Related Manuals for Cisco IR510
Summary of Contents for Cisco IR510
-
Page 1: Table Of Contents
IoT Field Network Director User Guides that provides management options for the IR510 platform. Related Documentation, page 26 Provides links to related Cisco products that the IR510 and IR530 can be connected to or managed by. Cisco Systems, Inc. -
Page 2: Conventions
Review the FCC guidelines for installing and operating outdoor wireless LAN devices at: https://www.cisco.com/c/en/us/products/collateral/routers/3200-series-rugged-integrated-services-routers-isr/data_sheet_c78-647116 .html Perform a site survey before beginning the installation. Install the IR510 WPAN Gateway and IR530 Range Extender in an area where structures, trees, or hills do not obstruct radio signals to and from the devices. -
Page 3: Ir510 Installation
Serial (RS232/RS485), USB (LS/FS/HS), or Fast Ethernet (10/100 Fast Ethernet) ports. Additionally, the gateway employs GPS for time synchronization and location tracking. The IR510 works with the CGR1000 series of routers, primarily in the electrical grid to provide a low cost, low power, small size DA solution. The IR510 Gateway (Figure 1 IR510 in IP30 Enclosure, page 7) comes within a ruggedized IP30 enclosure. - Page 4 DIN Rail assembly (spare) ANT-UN-MP-OUT-QMA Antenna with QMA connector and 5 ft. cable for use with IR510 ANT-UN-MP-OUT-QMA= Antenna with QMA connector and 5 ft. cable for use with IR510 (spare) ANT-WPAN-OM-OUT-N Omni antenna for 900MHz WPAN (Outdoor) IR510 Cautions and Warnings CAUTION: Do not place anything on top of the router that weighs more than 10 pounds (4.5 kilograms), and do not stack routers on a...
- Page 5 Les combinaisons d'équipements dans le système sont sujettes à inspection par les autorités locales qualifiées au moment de l'installation Unpacking the IR510 Note: When you are unpacking the IR510, do not remove the foam blocks attached to the antenna connectors. The foam protects the antenna connectors during installation.
- Page 6 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide IR510 Installation To unpack the IR510: Open the shipping container and carefully remove the contents. Return all packing materials to the shipping container, and save them. Ensure that all items listed in “Package Contents” section are included in the shipment. If any item is damaged or missing, notify your sales representative.
- Page 7 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide IR510 Installation Figure 1 IR510 in IP30 Enclosure Table 1 IR510 Front Panel Status LEDs (see Table 4 on page Console port (RJ45 10/100 Fast Ethernet port) Ground connection point DC power and alarm connector USB 2.0 port (covered by Caution panel).
- Page 8 Alarm port Port has one Isolated input for open and closed relay detection. QMA Antenna Port 900 MHz ISM band, Omni stick, 24 inch, 5 dBi, N(f), Cisco PID ANT-WPAN-OM-OUT-N. Panel-mounted, 50-ohm connector for connecting the antenna to the WPAN gateway.
- Page 9 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide IR510 Installation Table 4 IR510 LEDs Green Yellow Solid: Ethernet Link Established Blinking: Ethernet Activity Detected RS232-DCE Solid: S0 Port is RS232 DCE RS485 Solid: S0 Port is RS485...
- Page 10 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide IR510 Installation Figure 2 IR510 Mounting Clearance Shown for Optimum Airflow- Rack Mount...
- Page 11 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide IR510 Installation Figure 3 IR510 Mounting Clearance Shown for Optimum Airflow- DIN Rail Mount IR510 Mounting Options There are two mounting options for IR510: Rack (Figure 4 on page...
- Page 12 Attaching Mounting Brackets to IR510 to Support Rack Mount Installation Steps for Mounting Brackets Use a ratcheting torque screwdriver to tighten the 4 screws and 2 mounting brackets to the bottom of the IR510 with a torque of 8-11in-lbs. Note: For rear rack mounting, use the 8-32 holes with a max depth of .25.
- Page 13 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide IR510 Installation Figure 5 Attaching DIN Rail Mounting IR510 Hardware Installation Steps for DIN Rail Kit...
- Page 14 IR510 (Figure Use a ratcheting torque screwdriver to tighten the ground screws to the IR510 front panel. The torque should not exceed 8-11 in-lb (0.9 to 1.2 N-m). Attach the other end of the ground wire to a grounded bare metal surface such as a ground bus, a grounded DIN rail, or a grounded...
- Page 15 Power and Alarm Connector for IR510 IR510 requires DC power. You connect the DC power and alarm connections to the IR510 through the Power and Alarm Connector found on the far-right front panel of the IR510 above the Reset Button.
-
Page 16: Ir530 Series Resilient Mesh Range Extender Installation
Mesh Range Extender products in the IR500 family: The IR529 and IR530. IR530 represents a high performance, new generation of the Cisco RF Mesh range extender. The IR530 Range Extenders take full advantage of Cisco networking expertise in IPv6, security. It provides an open, high performance RF mesh solution based on the following standards: ... - Page 17 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide IR530 Series Resilient Mesh Range Extender Installation Figure 9 IR530 - Bottom View Table 8 IR530 Components Antenna port Ground System LED Vent AC input Console Port Access IR530 Range Extender Product IDs Note: You can order the IR530 with a single or dual antenna and a battery.
- Page 18 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide IR530 Series Resilient Mesh Range Extender Installation Table 9 IR530 Product IDs Product ID Description IR530-OFDM-FCC/K9 IR530 with 915MHz-WPAN, utility-grade DC power. For all North and South America except Brazil.
- Page 19 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide IR530 Series Resilient Mesh Range Extender Installation Table 10 IR530 Hardware Specifications Item Description Dimensions (W x D x H) 5.2” x 7.23” x 10.37” Typical weight fully configured 8.4 lbs (3.8 kg)
- Page 20 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide IR530 Series Resilient Mesh Range Extender Installation To unpack the IR530 Resilient Mesh Range Extender: Open the shipping container and carefully remove the contents. Return all packing material to the shipping container and save it.
- Page 21 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide IR530 Series Resilient Mesh Range Extender Installation Figure 10 Attaching IR530 Mounting Bracket to Pole Table 11 Mounting Kit Components Pole Washer U bolt (part number 62-2766-01) Spring loaded washer...
- Page 22 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide IR530 Series Resilient Mesh Range Extender Installation Table 12 IR530 Mounting Components Screws (4) to attach IR530 to mounting bracket Mounting holes (4) Grounding the IR530 Range Extender The accessory kit that ships with the IR530, includes one tabular ground lug and two ground screws to provide protective ground for the...
- Page 23 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide IR530 Series Resilient Mesh Range Extender Installation Figure 12 Grounding Accessory Kit To ground the range extender, use a crimping tool to crimp the 6-gauge ground wire to the grounding lug.
- Page 24 AC Power Cable The IR530 range extender supports the Cisco AC power cable that ships with the unit. One end of the cable has the range extender AC power connector and the other end is unfinished and you must provide and attach an AC power plug or terminate the cable at your installation site.
- Page 25 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide IR530 Series Resilient Mesh Range Extender Installation Use a plug that complies with local and national electrical codes. Verify the connection between the cable and plug is weatherproof.
-
Page 26: Configuring Ir510 And Ir530 Systems
Cisco IR510 WPAN Industrial Routers” section within the “Managing Devices” chapter. Related Documentation Cisco IoT Field Network Director User Guide, Release 4.2.x Cisco Connected Grid WPAN Module for CGR 1000 Series Installation and Cisco Resilient Mesh Configuration Guide (Cisco IOS) - Page 27 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide Related Documentation Connected Grid Module (CGM) WPAN-OFDM-FCC Module - Cisco IOS Release Notes for Cisco Resilient Mesh Release 5.7.27 Release Notes for Cisco Resilient Mesh Release 5.6.21 Cisco 1120 Connected Grid Router Hardware Installation Guide...
- Page 28 IR510 WPAN Gateway and IR530 WPAN Range Extender Hardware Installation Guide Related Documentation...
