Replacing the Gateway M405 Optical Drive This package includes a replacement optical drive for your Gateway M405 notebook and these printed instructions. Tools you need You need a small Phillips and a small flat-blade screwdriver to replace the optical drive.
Turn your notebook over so the bottom is facing up. Remove the battery. See your user guide for more information. Turn your notebook over so the top is facing up. Open the LCD panel to the normal viewing position. www.gateway.com...
Page 3
Pull the bezel off your notebook. You will hear small snapping sounds as the bezel comes away from your notebook. Be careful not to break off the tabs found on the left end of the bezel. www.gateway.com...
Page 4
With a small Phillips screwdriver, remove the four keyboard screws and put them in a safe place. Screws www.gateway.com...
Page 5
Lift the back edge of the keyboard, then slowly rotate it toward you so it lies keys-down on top of your notebook. Be careful not to damage the LCD panel. Important You do not need to disconnect the keyboard from the system board. www.gateway.com...
Page 6
To replace the optical drive: Remove the two screws securing the optical drive to the notebook. Screws www.gateway.com...
Page 7
Slide the old drive out of your notebook. Slide the new drive into your notebook. www.gateway.com...
Page 8
Replace the two optical drive screws. Screws www.gateway.com...
Page 9
Insert the tabs on the front of the keyboard under the palm rest. Gently press the keyboard down until it is flat all the way across. The keyboard should easily fall into place. Be careful not to damage the LCD panel. Tabs www.gateway.com...
Page 10
Replace the four keyboard screws. Slide the two tabs on the left end of the bezel under your notebook frame. Screws www.gateway.com...
Page 11
The bezel should be flat all the way across. Warning If the bezel is not correctly replaced, your notebook could be damaged when you try to close the LCD panel. Replace the battery. Connect the power adapter and modem and network cables, then turn on your notebook. www.gateway.com...
