DM-RMC-4KZ-SCALER-C
DigitalMedia 8G+® 4K60 4:4:4 HDR Receiver and Room Controller with Scaler
The Crestron®
DM-RMC-4KZ-SCALER-C
and room controller with scaler that supports full 4K60 4:4:4 and high
dynamic (HDR10) video signals. Via a CATx cable, the DM-RMC-4KZ-
SCALER-C connects to a DigitalMedia™ switcher or transmitter or to an
HDBaseT® source. Built-in RS-232, IR, and HDMI® CEC ports enable
programmable control of a display device via a control system.
In the Box
1
DM-RMC-4KZ-SCALER-C DigitalMedia 8G+ 4K60 4:4:4 HDR
Receiver and Room Controller with Scaler
Additional Items
2
Connector, 4-Pin (2003576)
2
Connector, 5-Pin (2003577)
Install the Device
The DM-RMC-4KZ-SCALER-C can be mounted onto a flat surface or
rack rail.
Mounting onto a Flat Surface
Using four mounting screws (not included), mount the device onto a flat
surface such as a wall.
is a DigitalMedia 8G+® receiver
Wall Mounting
Quick Start
1

Advertisement

loading

Related Manuals for Crestron DM-RMC-4KZ-SCALER-C

Summary of Contents for Crestron DM-RMC-4KZ-SCALER-C

  • Page 1 Additional Items Connector, 4-Pin (2003576) Connector, 5-Pin (2003577) Install the Device The DM-RMC-4KZ-SCALER-C can be mounted onto a flat surface or rack rail. Mounting onto a Flat Surface Using four mounting screws (not included), mount the device onto a flat...

  • Page 2: Connect The Device

    (sold separately) can be used to power the DM-RMC-4KZ- SCALER-C. Connection of the CEN-SWPOE-16 to the POE IN ports of DMC- 4KZ-CO-HD output cards in a DigitalMedia switcher can provide PoDM+ power to up to seven DM-RMC-4KZ-SCALER-C devices.
  • Page 3 Quick Start DM-RMC-4KZ-SCALER-C DigitalMedia 8G+® 4K60 4:4:4 HDR Receiver and Room Controller with Scaler Connections, Left and Right Sides...

  • Page 4: Upgrade The Firmware

    − R− Open If the DM-RMC-4KZ-SCALER-C is connected directly to a DigitalMedia 8G+ transmitter (commonly referred to as a standalone configuration in which no DigitalMedia switcher is used), the IP address of the receiver is assigned using DHCP (Dynamic Host Configuration Protocol) by default.

  • Page 5: Select The Input

    Quick Start DM-RMC-4KZ-SCALER-C DigitalMedia 8G+® 4K60 4:4:4 HDR Receiver and Room Controller with Scaler Select the Input Observe the LED Indicators The input source can be switched automatically (default setting) or Refer to the following table for information about the LED indicators on selected manually.
  • Page 6 Service Providers (CSPs) under a limited nonexclusive, nontransferable Software Development Tools License Agreement. Crestron product operating system software is licensed to Crestron dealers, CSPs, and end-users under a separate End-User License Agreement. Both of these Agreements can be found on the Crestron website at www.crestron.com/legal/software_license_agreement. www.crestron.com/model/6508076 The product warranty can be found at www.crestron.com/warranty.
