ProScan PS27152JX1 Technical Service Data

SAFETY PRECA SAFETY PRECA
SAFETY PRECA SAFETY PRECA SAFETY PRECAUTIONS
SERVICE SER SER VICE WARNING VICE VICE WARNING WARNING WARNING
SER SER VICE WARNING
Only qualified service technicians who are familiar with safety checks
and guidelines should perform service work. Before replacing parts,
disconnect power source to protect electrostatically sensitive parts. Do
not attempt to modify any circuit unless so recommended by the
manufacturer. When servicing the receiver, use an isolation transformer
between the line cord and power receptacle.
SER SERVICING SER SER SER VICING THE HIGH VICING VICING VICING THE HIGH THE HIGH V V V V V OL THE HIGH THE HIGH OLT T T T T A A A A A GE AND CR OL OL OL GE AND CR GE AND CRT T T T T GE AND CR GE AND CR
Use EXTREME CAUTION when servicing the high voltage circuits. To
discharge static high voltage, connect a 10K ohms resistor in series with a
test lead between the receiver ground and CRT anode lead. DO NOT lift
the CRT by the neck. Always wear shatterproof goggles when handling
the CRT to protect eyes in case of implosion.
X-RAY RADIA X-RA X-RA X-RA X-RA Y RADIA Y RADIATION AND HIGH Y RADIA Y RADIA TION AND HIGH TION AND HIGH TION AND HIGH TION AND HIGH V V V V V OL OL OLT T T T T A A A A A GE LIMITS OL OL GE LIMITS GE LIMITS GE LIMITS GE LIMITS
Be aware of the instructions and procedures covering X-ray radiation. In
solid-state receivers and monitors, the CRT is the only potential source of
X-rays. Keep an accurate high voltage meter available at all times. Check
meter calibration periodically. Whenever servicing a receiver, check the
high voltage at various brightness levels to be sure it is regulating
properly. Keep high voltage at rated value, NO HIGHER. Excessive high
voltage may cause X-ray radiation or failure of associated components.
DO NOT depend on protection circuits to keep voltage at rated value.
When troubleshooting a receiver with excessive high voltage, avoid close
contact with the CRT. DO NOT operate the receiver longer than
necessary. To locate the cause of excessive high voltage, use a variable
AC transformer to regulate voltage. In present receivers, many electrical
and mechanical components have safety related characteristics which are
not detectable by visual inspection. Such components are identified by a
# on both the schematic and the parts list. For SAFETY, use only
equivalent replacement parts when replacing these components.
GENERAL GUIDELINES GENERAL GUIDELINES GENERAL GUIDELINES GENERAL GUIDELINES GENERAL GUIDELINES
Perform a final SAFETY CHECK before returning receiver to customer.
Check repaired area for poorly soldered connections, and check entire
circuit board for solder splashes. Check board wiring for pinched wires or
wires contacting any high wattage resistors. Check that all control knobs,
shields, covers, grounds, and mounting hardware have been replaced. Be
sure to replace all insulators and restore proper lead dress.
HIGH V V V V V OL HIGH HIGH OLT T T T T A A A A A GE SHUTDO OL OL GE SHUTDO GE SHUTDO
HIGH HIGH OL GE SHUTDO GE SHUTDOWN
Apply 120VAC to set, turn set on, and adjust brightness and contrast to maximum. Short
XRP-1 to XRP-2. The set should shut down and then cycle on and off. If the set does not
shut down and then cycle on and off, the shutdown circuoit requires repair. To resume normal
operation remove the short from XRP-1 to XRP-2.
