Polaris Ranger 1000 Windshield Kit
POLARIS RANGER 900, XP 900, 1000 &
Available Options:
1. Door Kit (P/N: 1POLXP1000DR)
2. Roof Kit (P/N: 1POLXP1000RF)
3. Rear Panel Kit (P/N: 1POLXP1000RP)
Approximate Installation Time *
Experienced Dealer Technician – 15 minutes
Average Dealer Technician – 20 minutes
Do-It-Yourself – 30 minutes
(*=Not including accessories)
Register your new product quickly online at
Curtiscab.com/product-registration/
Curtis encourages all customers to register their
Curtis products. However, failure to do so will not
diminish right to warranty. Curtis Industries does not
sell or share your information with anyone else.
The contents of this envelope are the property of the owner. Leave with the owner when installation is complete.
Kit p/n:1POLXP1000WS
Fits UTV Models:
XP 1000
4. Front Wiper Kit (P/N 1POLXP1000WK)
5. Side View Mirrors (P/N: 9PM5)
6. Door Restraint Kit (P/N: 1POLXP1000GS)
Approximate Product Specifications
Weight: 17.5 lbs.
Download a digital copy of your installation
instructions online at Curtiscab.com/literature/
Curtis strives to continuously improve our products,
technical documentation, etc. Therefore, the
installation manual for this product may have been
updated after your product was packaged. The
latest revision of the installation manual can always
be found at the website above.
1 of 7
Rev. A, 06/30/2021
p/n: IM-1POLXP1000WS
