- Page 1 Invacare SoftCloud family ® Top, Air, Ace, Pro Alternating mattress systems Service Manual PROVIDER: Keep this manual. The procedures in this manual MUST be performed by a qualified technician.
- Page 2 All rights reserved. Republication, duplication or modification in whole or in part is prohibited without prior written permission from Invacare. Trademarks are identified by ™ and ®. All trademarks are owned by or licensed to Invacare Corporation or its subsidiaries unless otherwise noted.
-
Page 3: Table Of Contents
4.1.9 Replacing the IEC Socket ....14 4.2 SoftCloud Top/Air ..... . .15 4.2.1 Replacing the Air Filter . -
Page 4: General
Confirm the mains cable is firmly attached and the Find the user manual on Invacare’s website or contact system is connected to a working power source. your Invacare representative. See addresses at the 2. -
Page 5: Safety
- are only available as a kit. Always use the complete new kit when replacing a part. – Spare parts kits can be ordered from Invacare. Refer to your local Invacare website to access the electronic spare parts catalogue (ESPC). -
Page 6: Digital Control Unit
Invacare ® SoftCloud family 3 Digital Control Unit 3.1 Components Overview 3.2 Circuit Board (PCB) Overview 3.2.1 Ace/Pro PCB Fig. 3-2 Power switch connector Pressure sensor Compressor connector Flexible printed circuit (FPC) connectors Speaker connector Fig. 3-1 Motor connector IEC Mains connector Top housing 3.2.2 Top/Air PCB... -
Page 7: Service | Digital Control Unit
Failure to keep the filters clean will result in system downtime and increase repair costs. It is recommended that the air filter be replaced annually. Replacement air filters are available from an Invacare Service Centre. Switch off the control unit and disconnect from mains supply. -
Page 8: Replacing The Top Housing
Invacare ® SoftCloud family 4.1.2 Replacing the Top Housing efers to spare parts kit SP1631544 Risk of damaging the PCB by electro- static discharge Handle PCB's only in Electrostatic Protected Areas T10, T20 Torx keys Removing Housing Switch off the control unit and disconnect from mains supply. -
Page 9: Replacing The Pcb
Invacare ® SoftCloud family Installing Housing 11. Plug both FPC's and the speaker cable. 12. Install the new housing. Ensure no cable or tube is kinked or clamped. 13. Hold the unit firmly. Turn it upside down. 14. Install the five provided screws and tighten the new housing. -
Page 10: Replacing The Dual Compressor
Invacare ® SoftCloud family 6. Loosen and remove the four screws I using the appropriate Torx key. 7. Discard the nonfunctioning PCB. 8. Install the new PCB and secure it with the four provided screws. 9. Install all the parts in reverse order. Ensure no cable or tube is kinked or clamped. -
Page 11: Replacing The Motor
Invacare ® SoftCloud family 7. Loosen and remove the eight screws C fixing the compressor bracket. 8. Remove the nonfunctioning dual compressor and discard it. 9. Install the new dual compressor and fix it with the eight provided screws. 10. Plug the compressor cable and the earth wire. -
Page 12: Replacing The Air Tube Connector
Invacare ® SoftCloud family 4.1.6 Replacing the Air Tube Connector Refers to spare parts kit SP1631535 Risk of damaging the PCB by electro- static discharge Handle PCB's only in Electrostatic Protected Areas T10, T20 Torx keys Switch off the control unit and disconnect from mains supply. -
Page 13: Replacing The Bottom Housing
Invacare ® SoftCloud family 4.1.7 Replacing the Bottom Housing Refers to spare parts kit SP1631540 Risk of damaging the PCB by electro- static discharge Handle PCB's only in Electrostatic Protected Areas T10, T20 Torx keys Wire clippers Switch off the control unit and disconnect from mains supply. -
Page 14: Replacing The Tube Subassembly
Invacare ® SoftCloud family 4.1.8 Replacing the Tube Subassembly Refers to spare parts kit SP1633185 Risk of damaging the PCB by electro- static discharge Handle PCB's only in Electrostatic Protected Areas T10, T20 Torx keys Wire clippers Switch off the control unit and disconnect from mains supply. -
Page 15: Softcloud Top/Air
Failure to keep the filters clean will result in system downtime and increase repair costs. It is recommended that the air filter be replaced annually. Replacement air filters are available from an Invacare Service Centre. Switch off the control unit and disconnect from mains supply. -
Page 16: Replacing The Pcb
Invacare ® SoftCloud family Open housing. Unplug the speaker wire B and FPC's C and D. 6. Detach housing. Preparing Housing 7. Open the spare parts kit. Use the old housing as a guide, and apply the fuse type and insulation class stick-on labels on the new housing. -
Page 17: Replacing The Compressor
Invacare ® SoftCloud family 5. Loosen and remove the five screws F with the appropriate Torx key. 6. Replace the nonfunctioning PCB and secure the new one with the five provided screws. 7. Plug the power switch cable, motor, compressor, and mains cables. -
Page 18: Replacing The Motor
Invacare ® SoftCloud family 7. Unplug the yellow earth wire C from its socket. 8. Remove the nonfunctioning compressor and install the new one. 9. Install the six provided screws and tighten them. 10. Plug the compressor cable and the earth wire. -
Page 19: Replacing The Air Tube Connector
Invacare ® SoftCloud family 4.2.6 Replacing the Air Tube Connector Refers to spare parts kit SP1631447 Risk of damaging the PCB by electro- static discharge Handle PCB's only in Electrostatic Protected Areas T10, T20 Torx keys Switch off the control unit and disconnect from mains supply. -
Page 20: Replacing The Tube Subassembly
Invacare ® SoftCloud family 5. Unplug the compressor and sensor cables from the PCB (see 4.2.3). 6. Loosen and remove the five PCB screws with the appropriate Torx key (see 4.2.3). 7. Cut the cable tie that holds the compressor T-valve to the bottom housing. -
Page 21: Replacing The Iec Socket
Invacare ® SoftCloud family 4.2.9 Replacing the IEC Socket Refers to spare parts kit SP1631538 Risk of damaging the PCB by electro- static discharge Handle PCB's only in Electrostatic Protected Areas PH1 Phillips key T20 Torx key Wire clippers Switch off the control unit and disconnect from mains supply. -
Page 22: Service | Mattress
Invacare ® SoftCloud family 5 Service | Mattress 5.1 Replacing the Air Cell Refers to spare parts kits: SP1633189, SP1633190, SP1633192, SP1633193, SP1633194, SP1633195, SP1633196, SP1633197, SP1633203, SP1633204, SP1633205, SP1633206 Wire clippers Switch off the control unit and disconnect from mains supply. - Page 23 Invacare ® SoftCloud family 4. Facing towards the mattress, on the left-hand side, two L-shaped blue tubes connect the air cell to the bolster on that side. Using the wire clippers, cut both cable ties A securing them. 5. Carefully cut the end of the L-shaped tube connected to the side bolster using the wire cutters and unplug it.
-
Page 24: Replacing The Heel Cell (Ace/Pro)
Invacare ® SoftCloud family 5.2 Replacing the Heel Cell (Ace/Pro) Refers to spare parts kits: SP1633198, SP1633199, SP1633200, SP1633201, SP1633207, SP1633208 Wire clippers Switch off the control unit and disconnect from mains supply. 2. Open the bed cover zipper and take off the top cover (see 5.1). -
Page 25: Replacing A Side Bolster (Pro)
Invacare ® SoftCloud family 5.3 Replacing a Side Bolster (Pro) Refers to spare parts kits: SP1633209, SP1633210 Wire clippers Switch off the control unit and disconnect from mains supply. 2. Open the zipper of the bed cover and take off the top cover (see Fig. - Page 26 Invacare ® SoftCloud family (page left intentionally blank) 60129675-B...
