DESCRIPTION OF CONTROLS
Remote Control Key Functions
Remote Control Key Functions
- When using the remote control, aim it at the remote control sensor on the TV.
MODE
Selects the remote operating mode:
TV, VCR, Cable, DVD and Satellite.
Select other operating modes, for the
remote to control external devices.
TV/VIDEO
Selects: Analog, Video1, Video2, Side
video, Component1-2, RGB, HDMI1/DVI
and HDMI2 input sources.
NUMBER KEYPAD
For direct channel selection and
programming functions.
MUTE
Switches the sound on or off.
VOLUME UP/DOWN
Increases/decreases the sound
level.
RATIO
Changes the screen format or aspect
ratio.
MENU
Brings up the main menu to the
screen.
SKIP
Playing CDs: Selects songs.
Playing DVDs: Selects movie chapters.
INDICATOR LIGHTS
Show active remote mode
VCR CABLE DVD SAT
TV
every time any button is
pressed.
MODE LIGHT
POWER
LIGHT
TV/VIDEO TV INPUT INFO
Illuminates the remote con-
trol keys.
EZ Video EZ Sound SLEEP
INFO
1 2 3
When you watch the TV, information dis-
plays on top of the screen. Not available
4 5 6
in Component 1-2, RGB, HDMI1/DVI and
HDMI2 mode.
7 8 9
0
FLASHBK
FAV
MUTE FAV
Scrolls the Favorite channels.
+
SAP ADJUST
VOL CH
-
ADJUST
Adjusts screen position, size, and phase
PIP PIPCH- PIPCH+ SWAP
in PC mode.
PIP INPUT
CC FREEZE PIP INPUT
RATIO
Selects the input source for the sub
picture.
ENTER
When in the menu system and other
on-screen displays, selects highlighted
MENU EXIT
options.
PLAY PAUSE STOP RECORD
EXIT
Clears all on-screen displays and returns
REW FF
to TV viewing from any menu.
SKIP
