Zenith Z52SZ80 Service Manual page 30

LOCA. NO PART NO
C843 0CK104CF56A 0.1UF 1608 16V 10%
C843 0CE476SF6DC 47UF MVG 16V 20%
C844 0CK104CF56A 0.1UF 1608 16V 10%
C845 0CK104CF56A 0.1UF 1608 16V 10%
0CE106SF6DC 10UF MVG 16V 20%
C845
C846 0CK104CF56A 0.1UF 1608 16V 10%
C847 0CK104CF56A 0.1UF 1608 16V 10%
C848 0CE105SK6DC 1UF MVG 50V 20%
C851 0CE476SF6DC 47UF MVG 16V 20%
1UF STD 50V M
C857 0CE105DK618
C861 0CK104CF56A 0.1UF 1608 16V 10%
C862 0CE106SF6DC 10UF MVG 16V 20%
C864 0CE106SF6DC 10UF MVG 16V 20%
0CE108DF618 1000UF STD 16V M
C871
C872 0CE477BH618 470UF KME TYPE 25V M
C873 181-091Q R 470PF 1KV 10%,-10%
C873 0CE108DK61A 1000UF STD 50V 20%
C881 0CE227DH618 220UF STD 25V M
220UF STD 25V M
C882 0CE227DH618
C883 181-091Q R 470PF 1KV 10%,-10%
C892 0CE227DK618 220UF STD 50V M
C893 181-091Q R 470PF 1KV 10%,-10%
0CE476DK618 47UF STD 50V M
C895
47UF STD 50V M
C897 0CE476DK618
C898 181-120L 3300PF 4KV M
C899 181-035U DE1B3KX471KA5B 470PF 250V 10%
C901 0CK104CF56A 0.1UF 1608 16V 10%
0CK104CF56A 0.1UF 1608 16V 10%
C902
C904 0CK104CF56A 0.1UF 1608 16V 10%
C905 0CK104CF56A 0.1UF 1608 16V 10%
C906 0CK104CF56A 0.1UF 1608 16V 10%
C907 0CN105EJ56A 1.0UF 3216 35V 10%
0.1UF 1608 16V 10%
C908 0CK104CF56A
C909 0CK104CF56A 0.1UF 1608 16V 10%
C910 0CK104CF56A 0.1UF 1608 16V 10%
C911 0CK104CF56A 0.1UF 1608 16V 10%
0CN106FF66A 10UF 3225 16V 20%
C912
0.1UF 1608 16V 10%
C913 0CK104CF56A
C914 0CN105EJ56A 1.0UF 3216 35V 10%
C915 0CN106KH67A 10UF 4532 25V 20%
C919 0CK104CF56A 0.1UF 1608 16V 10%
0CK104CF56A 0.1UF 1608 16V 10%
C920
C921 0CK104CF56A 0.1UF 1608 16V 10%
C922 0CK104CF56A 0.1UF 1608 16V 10%
C923 0CN105EJ56A 1.0UF 3216 35V 10%
C943 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C947 0CK104CF56A
C949 0CK104CF56A 0.1UF 1608 16V 10%
C950 0CK104CF56A 0.1UF 1608 16V 10%
C951 0CE335SK6DC 3.3UF MVG 50V 20%
0CE335SK6DC 3.3UF MVG 50V 20%
C952
All manuals and user guides at all-guides.com
REPLACEMENT PARTS LIST
DESCRIPTION
- 30 -
LOCA. NO PART NO
C957 0CK104CF56A 0.1UF 1608 16V 10%
C958 0CK104CF56A 0.1UF 1608 16V 10%
C959 0CK104CF56A 0.1UF 1608 16V 10%
C960 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C963 0CK104CF56A
C964 0CK104CF56A 0.1UF 1608 16V 10%
C965 0CK272CK46A 2700PF 1608 50V 5%
C966 0CK472CK56A 4700PF 1608 50V 10%
C967 0CK272CK46A 2700PF 1608 50V 5%
0.22UF 2012 25V 10%
C968 0CK224DH56A
C969 0CN105EJ56A 1.0UF 3216 35V 10%
C970 0CK104CF56A 0.1UF 1608 16V 10%
C971 0CC102CK41A 1000PF 1608 50V 5%
0CC102CK41A 1000PF 1608 50V 5%
C972
C973 0CC102CK41A 1000PF 1608 50V 5%
C974 0CK104CF56A 0.1UF 1608 16V 10%
C975 0CK104CF56A 0.1UF 1608 16V 10%
C976 0CE335SK6DC 3.3UF MVG 50V 20%
4.7UF 3216 10V 20%
C981 0CN475ED66A
C982 0CE335SK6DC 3.3UF MVG 50V 20%
C989 0CE476SF6DC 47UF MVG 16V 20%
C990 0CE476SF6DC 47UF MVG 16V 20%
COIL & TRANSFORMER
J4 0LA0102K119 INDUCTOR,10UH K
J5 0LA0102K119 INDUCTOR,10UH K
L1 0LA0102K119 INDUCTOR,10UH K
6140VB0023A COIL,CHOKE SB7032-751 750UH
L100
L105 6140VB0024A COIL,CHOKE LPK-1322A 22UH +-10%
L106 6140VB0024A COIL,CHOKE LPK-1322A 22UH +-10%
L107 6140VB0024A COIL,CHOKE LPK-1322A 22UH +-10%
L108 6140VB0024A COIL,CHOKE LPK-1322A 22UH +-10%
L403 6140VR0009A COIL,SP7835-331 1UEW 0.15PIE 330UH 15%
L831 150-C02V COIL,CHOKE 10UH R 1318
L841 150-C02V COIL,CHOKE 10UH R 1318
L881 150-C02V COIL,CHOKE 10UH R 1318
150-C02V
L891 COIL,CHOKE 10UH R 1318
L903 6140VR0007A COIL,DT1608C-223 22UF+-20%
L904 6140VR0007A COIL,DT1608C-223 22UF+-20%
T830 6170VMCC01X TRANSFORMER,SMPS[COIL] EER5345 450UH
CONNECTOR
C1 6631V00030G CONNECTOR ASSEMBLY,8P 400MM
C10 6631V12044G CONNECTOR ASSEMBLY,7P 1.25MM 400MM
C11 6631V12046L CONNECTOR ASSEMBLY,5P 1.25MM 700MM
C12 6631V20046J
CONNECTOR ASSEMBLY,8P 2.0MM 500MM
C13 6631V00015B CONNECTOR ASSEMBLY,2P 8.0MM 400MM
C14 387-907K CONNECTOR ASSEMBLY,1P NON 600MM
C15 6631V20019E CONNECTOR ASSEMBLY,3P 2.0MM 300MM
C16 387-J12K CONNECTOR ASSEMBLY,12P 2.5MM 600MM
387-G03P
C17 CONNECTOR ASSEMBLY,3P 2.5MM 1000MM
DESCRIPTION
