Zenith Z52SZ80 Service Manual page 27

LOCA. NO PART NO
C407 0CE476SF6DC 47UF MVG 16V 20%
C408 0CK104CF56A 0.1UF 1608 16V 10%
C409 0CK103CK56A 0.01UF 1608 50V 10%
C410 0CE476SF6DC 47UF MVG 16V 20%
0CK104CF56A 0.1UF 1608 16V 10%
C411
C412 0CK105CD56A 1UF 1608 10V 10%
C413 0CK104CF56A 0.1UF 1608 16V 10%
C414 0CK104CF56A 0.1UF 1608 16V 10%
C415 0CE106SF6DC 10UF MVG 16V 20%
0.1UF 1608 16V 10%
C416 0CK104CF56A
C417 0CE476SF6DC 47UF MVG 16V 20%
C418 0CE476SF6DC 47UF MVG 16V 20%
C419 0CK104CF56A 0.1UF 1608 16V 10%
0CE107SF6DC 100UF MVG 16V 20%
C422
C424 0CE107SF6DC 100UF MVG 16V 20%
C426 0CE107SF6DC 100UF MVG 16V 20%
C428 0CE107SF6DC 100UF MVG 16V 20%
C471 0CE106SF6DC 10UF MVG 16V 20%
10UF MVG 16V 20%
C475 0CE106SF6DC
C480 0CE106SF6DC 10UF MVG 16V 20%
C5 0CK105DF64A 1UF 2012 16V 20%
C500 0CK104CF56A 0.1UF 1608 16V 10%
0CK104CF56A 0.1UF 1608 16V 10%
C503
100UF MVG 16V 20%
C504 0CE107SF6DC
C511 0CK104CF56A 0.1UF 1608 16V 10%
C512 0CK103CK56A 0.01UF 1608 50V 10%
C513 0CK103CK56A 0.01UF 1608 50V 10%
0CK103CK56A 0.01UF 1608 50V 10%
C514
C515 0CK104CF56A 0.1UF 1608 16V 10%
C517 0CK104CF56A 0.1UF 1608 16V 10%
C519 0CK104CF56A 0.1UF 1608 16V 10%
C523 0CK104CF56A 0.1UF 1608 16V 10%
33UF MVG 25V 20%
C526 0CE336SH6DC
C527 0CE336SH6DC 33UF MVG 25V 20%
C528 0CK104CF56A 0.1UF 1608 16V 10%
C529 0CE336SH6DC 33UF MVG 25V 20%
0CE106DF618 10UF STD 16V M
C53
0.1UF 1608 16V 10%
C530 0CK104CF56A
C531 0CK104CF56A 0.1UF 1608 16V 10%
C532 0CE336SH6DC 33UF MVG 25V 20%
C533 0CK104CF56A 0.1UF 1608 16V 10%
0CK104CF56A 0.1UF 1608 16V 10%
C535
C554 0CE107SF6DC 100UF MVG 16V 20%
C554 0CE476SF6DC 47UF MVG 16V 20%
C555 0CE106SH6DC 10UF MVG 25V 20%
C556 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C557 0CK104CF56A
C600 0CE106SF6DC 10UF MVG 16V 20%
C601 0CE106SF6DC 10UF MVG 16V 20%
C602 0CE106SF6DC 10UF MVG 16V 20%
0CE106SF6DC 10UF MVG 16V 20%
C603
All manuals and user guides at all-guides.com
REPLACEMENT PARTS LIST
DESCRIPTION
- 27 -
LOCA. NO PART NO
C604 0CE335SK6DC 3.3UF MVG 50V 20%
C605 0CE106SF6DC 10UF MVG 16V 20%
C606 0CE106SF6DC 10UF MVG 16V 20%
C606 0CE107DF618 100UF STD 16V M
0CE106SF6DC 10UF MVG 16V 20%
C607
C608 0CE106SF6DC 10UF MVG 16V 20%
C609 0CK104CF56A 0.1UF 1608 16V 10%
C610 0CK104CF56A 0.1UF 1608 16V 10%
C611 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C612 0CK104CF56A
C613 0CE335SK6DC 3.3UF MVG 50V 20%
C614 0CK104CF56A 0.1UF 1608 16V 10%
C615 0CK104CF56A 0.1UF 1608 16V 10%
0CK104CF56A 0.1UF 1608 16V 10%
C616
C616 0CE107DF618 100UF STD 16V M
C617 0CK104CF56A 0.1UF 1608 16V 10%
C618 0CK104CF56A 0.1UF 1608 16V 10%
C619 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C620 0CK104CF56A
C621 0CK104CF56A 0.1UF 1608 16V 10%
C621 0CK105DF64A 1UF 2012 16V 20%
C622 0CK104CF56A 0.1UF 1608 16V 10%
0CK105DF64A 1UF 2012 16V 20%
C622
0.1UF 1608 16V 10%
C623 0CK104CF56A
C624 0CK104CF56A 0.1UF 1608 16V 10%
C625 0CK104CF56A 0.1UF 1608 16V 10%
C626 0CK104CF56A 0.1UF 1608 16V 10%
0CK104CF56A 0.1UF 1608 16V 10%
C627
C628 0CK104CF56A 0.1UF 1608 16V 10%
C628 0CE106DF618 10UF STD 16V M
C629 0CK104CF56A 0.1UF 1608 16V 10%
C630 0CK104CF56A 0.1UF 1608 16V 10%
10UF STD 16V M
C630 0CE106DF618
C631 0CK104CF56A 0.1UF 1608 16V 10%
C631 0CE107DF618 100UF STD 16V M
C632 0CK104CF56A 0.1UF 1608 16V 10%
0CK104CF56A 0.1UF 1608 16V 10%
C633
0.1UF 1608 16V 10%
C634 0CK104CF56A
C635 0CK104CF56A 0.1UF 1608 16V 10%
C636 0CK104CF56A 0.1UF 1608 16V 10%
C637 0CK104CF56A 0.1UF 1608 16V 10%
0CE476SF6DC 47UF MVG 16V 20%
C637
C638 0CK104CF56A 0.1UF 1608 16V 10%
C639 0CK104CF56A 0.1UF 1608 16V 10%
C639 0CE476SF6DC 47UF MVG 16V 20%
C640 0CK104CF56A 0.1UF 1608 16V 10%
0.1UF 1608 16V 10%
C641 0CK104CF56A
C642 0CK104CF56A 0.1UF 1608 16V 10%
C643 0CK104CF56A 0.1UF 1608 16V 10%
C643 0CE476SF6DC 47UF MVG 16V 20%
0CE476DF618 47UF STD 16V M
C643
DESCRIPTION
