LOCA. NO
PART NO
R868
0RD2001F609
2K OHM 1/6 W 5%
R891
0RD1002H609
10K OHM 1/2 W 5.00%
R894
0RD1001F609
1K OHM 1/6 W 5%
R895
0RN2201F409
2.2K OHM 1/6 W 1.00%
8.2K OHM 1/6 W 1.00%
R896
0RN8201F409
R897
0RD1001F609
1K OHM 1/6 W 5%
R899
0RKZVTA001B
4.7M OHM 1/2 W 5%
SWITCH
SWITCH,PUSH SPBS222EP011
SW01
140-275E
SW1
140-313B
SWITCH,TACT 2LEAD 160G(TA)
SW100
140-313A
SWITCH,TACT 2LEAD 100G(TA)
SW2
140-313B
SWITCH,TACT 2LEAD 160G(TA)
140-313B
SWITCH,TACT 2LEAD 160G(TA)
SW3
SW4
140-313B
SWITCH,TACT 2LEAD 160G(TA)
SW5
140-313B
SWITCH,TACT 2LEAD 160G(TA)
SW6
140-313B
SWITCH,TACT 2LEAD 160G(TA)
SW7
140-313B
SWITCH,TACT 2LEAD 160G(TA)
FILTER & CRYSTAL
FB801
125-022K
FILTER,EMC 62MM 1UH
FB831
125-123A
FILTER,EMC FERRITE BFD3565R2F
125-123A
FILTER,EMC FERRITE BFD3565R2F
FB841
FILTER,EMC FERRITE BFD3565R2F
FB871
125-123A
FB881
125-123A
FILTER,EMC FERRITE BFD3565R2F
FB892
125-123A
FILTER,EMC FERRITE BFD3565R2F
L1100
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
L1103
L405
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
L406
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
L505
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
L602
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
FILTER,EMC MLB-201209-0120P-N2 5A
L603
0LCML00003B
L604
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
L605
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
L606
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
L607
L700
0LCML00004A
FILTER,EMC MLB-160808-0068L-N2 1A
L702
0LCML00004A
FILTER,EMC MLB-160808-0068L-N2 1A
L705
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
L800
0LCML00004A
FILTER,EMC MLB-160808-0068L-N2 1A
6200JB8012T
FILTER,EMC SQE2828 17.2MH
L801
L802
6200JB8012T
FILTER,EMC SQE2828 17.2MH
L803
6200J000066
FILTER,EMC SQE3535 25MH
L901
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
L902
0LCML00004A
FILTER,EMC MLB-160808-0068L-N2 1A
FILTER,EMC MLB-201209-0120P-N2 5A
L906
0LCML00003B
L908
0LCML00004A
FILTER,EMC MLB-160808-0068L-N2 1A
L909
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
L910
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
L911
All manuals and user guides at all-guides.com
REPLACEMENT PARTS LIST
DESCRIPTION
- 32 -
LOCA. NO
PART NO
L912
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
L913
0LCML00003B
FILTER,EMC MLB-201209-0120P-N2 5A
T400
6200QJ3001A
FILTER,EMC BMS400 25V 200MA
T400
6200VJT006A
FILTER,EMC STC222D 50VOLT 4A 2200PF
FILTER,EMC BMS400 25V 200MA
T401
6200QJ3001A
T401
6200VJT006A
FILTER,EMC STC222D 50VOLT 4A 2200PF
T402
6200QJ3001A
FILTER,EMC BMS400 25V 200MA
T402
6200VJT006A
FILTER,EMC STC222D 50VOLT 4A 2200PF
T403
6200VJT006A
FILTER,EMC STC222D 50VOLT 4A 2200PF
FILTER,EMC STC222D 50VOLT 4A 2200PF
T404
6200VJT006A
T408
6200VJT006A
FILTER,EMC STC222D 50VOLT 4A 2200PF
T409
6200VJT006A
FILTER,EMC STC222D 50VOLT 4A 2200PF
T410
6200VJT006A
FILTER,EMC STC222D 50VOLT 4A 2200PF
6200VJT006A
FILTER,EMC STC222D 50VOLT 4A 2200PF
T411
T414
6200QJ3001A
FILTER,EMC BMS400 25V 200MA
T415
6200QJ3001A
FILTER,EMC BMS400 25V 200MA
T416
6200QJ3001A
FILTER,EMC BMS400 25V 200MA
T417
6200QJ3001A
FILTER,EMC BMS400 25V 200MA
FILTER,EMC BMS400 25V 200MA
T418
6200QJ3001A
T512
6200VJT006A
FILTER,EMC STC222D 50VOLT 4A 2200PF
T513
6200VJT006A
FILTER,EMC STC222D 50VOLT 4A 2200PF
T514
6200VJT006A
FILTER,EMC STC222D 50VOLT 4A 2200PF
6200VJT006A
FILTER,EMC STC222D 50VOLT 4A 2200PF
T515
RESONATOR,CRYSTAL HC49U 8.000MHZ
X1
156-A01P
X100
6212AB2861A
RESONATOR,CRYSTAL HC-49/SM 10.00000MHZ
X1202
6212AA2009A
RESONATOR,CRYSTAL HC-49U 4.00000MHZ
X1203
6212BA2002C
RESONATOR,CERAMIC CSALA2M69G4ZF01-B0
6212AB2860A
X300
RESONATOR,CRYSTAL HC-49/SM 20.25000MHZ
X600
6212AA2010A
RESONATOR,CRYSTAL HC-49U 18.43200MHZ
X602
6212AB2845A
RESONATOR,CRYSTAL ABLS-27.000MHZ
X800
6212AB2862A
RESONATOR,CRYSTAL HC-49/SM 24.57600MHZ
MISCELLANEOUS
C20
6851V00018H
CABLE,DVI-D TO DVI-D UL20276 AWG30 500MM
C21
6634VDN002K
ADAPTER,RF UMX-NT-024 75 OHM
C22
6851V00022D
CABLE,COAXIAL(250MM),UL1365#26 VW-1
0FS5001B51D
F800
FUSE,SLOW BLOW 5000MA 250V
IC1
6927V0161AA
SOFT WARE,2.00V 6109 MD PJT NB05ED
IC101
6927V0162AA
SOFT WARE,2.00V E3D4 MD PJT NB05ED
IC102
6927V0163AA
SOFT WARE,2.00V 2879 MD PJT NB05ED
IC312
6204B62702A
OSCILLATOR,27.00000MHZ +/- 100 PPM
6204B47985C
IC704
OSCILLATOR,SCO-103 100MHZ
PA1
6726VH0001A
REMOTE CONTROLLER RECEIVER,38KHZ
TH801
163-048D
THERMISTOR,NTC KL15L2R5 +/- 15%
TH802
163-048D
THERMISTOR,NTC KL15L2R5 +/- 15%
TU104
6700NFNS04H
TUNER,TDVL-H702P
VA600
6102W5V016A
VARISTOR,AVRL161A1R1NT
VA601
6102W5V016A
VARISTOR,AVRL161A1R1NT
VA602
6102W5V016A
VARISTOR,AVRL161A1R1NT
VA603
6102W5V016A
VARISTOR,AVRL161A1R1NT
6102W5V016A
VA604
VARISTOR,AVRL161A1R1NT
DESCRIPTION
