- Page 1 Grandstream Networks, Inc. GVC3200 Video Conferencing System for Android User Guide...
-
Page 2: Table Of Contents
GVC3200 User Guide Index CHANGE LOG......................8 FIRMWARE VERSION 1.0.0.X.......................... 8 WELCOME........................9 PRODUCT OVERVIEW..................11 FEATURE HIGHTLIGHTS..........................11 SAFETY COMPLIANCES..........................13 WARRANTY................................13 INSTALLING GVC3200..................14 EQUIPMENT PACKAGE CONTENT......................14 CONNECTING GVC3200..........................14 GETTING TO KNOW GVC3200................. 19 REMOTE CONTROL............................19 USING THE REMOTE CONTROL......................21 PAIRING AND CONNECTING THE REMOTE CONTROL..............22 USING MOUSE &... - Page 3 TRANSFER FILES WITH BLUETOOTH....................30 USING BLUETOOTH HEADSET......................30 VPN SETTINGS..............................30 VLAN SETTINGS...............................32 LLDP SETTINGS............................... 32 802.1X MODE..............................33 CAMERA.........................34 PRESET................................34 ADD/EDIT PRESET...........................34 DELETE PRESET............................35 APPLY PRESET............................35 CAMERA PARAMETERS CONFIGURATIONS.................... 35 PERIPHERAL......................38 EXTERNAL USB DEVICE..........................38 USING USB MOUSE/KEYBOARD......................38 USING USB STORAGE DEVICE......................38 SD CARD................................
- Page 4 DND (DO NOT DISTURB)..........................45 MISSED CALL..............................46 CALL FORWARD...............................46 CONFERENCE..............................46 LAYOUT...............................46 INITIATING CONFERENCE........................46 ANSWERING AN INCOMING CALL IN CONFERENCE..............46 CONFERENCE MANAGEMENT......................47 END CONFERENCE..........................53 SCHEDULE.................................53 VIEW CONFERENCE DETAILS......................54 ADD SCHEDULED CONFERENCE....................... 55 EDIT SCHEDULED CONFERENCE...................... 56 RESCHEDULE CONFERENCE......................56 DELETE SCHEDULED CONFERENCE....................56 VOICEMAIL.................................56 OTHER FUNCTIONS....................58 REMOTE CONTROL APPLICATION......................58...
- Page 5 BROWSER................................73 CUSTOM APP ON HOME SCREEN......................73 UNINSTALL APPLICATION..........................73 GS MARKET......................75 SEARCH APPS..............................75 DOWNLOAD AND INSTALL APPS......................... 75 UPDATE APPS..............................75 GVC3200 WEB UI FEATURES................76 ACCESSING GVC3200 WEB GUI........................76 SAVING CHANGES............................76 DEFINITIONS..............................77 TOOLBAR................................77 CALL PAGE.................................78 MAKING A CALL............................78 CONFERENCE CONTROL........................78 CONTACTS PAGE.............................79 CONTACTS..............................79...
- Page 6 Table of Tables GVC3200 User Guide Table 1 GVC3200 Technical Specifications......................11 Table 2 GVC3200 Package List..........................14 Table 3 GVC3200 Front Panel..........................15 Table 4 GVC3200 Back Panel..........................15 Table 5 GVC3200 Optional Equipment List......................16 Table 6 GVC3200 Remote Control Keys......................19 Table 7 GVC3200 OLED Screen Status Descriptions..................
- Page 7 Table of Figures GVC3200 User Guide Figure 1 GVC3200 Front Panel..........................15 Figure 2 GVC3200 Back Panel..........................15 Figure 3 GVC3200 Back Panel Connection Diagram..................18 Figure 4 Deploy Multiple GVC3200s with Other Devices................. 18 Figure 5 GVC3200 Remote Control........................19 Figure 6 GVC3200 Soft Keyboard - English Input Method................
- Page 8 Figure 40 Video Screen............................70 Figure 41 Backup Screen............................71 Figure 42 Auto Backup Screen..........................71 Figure 43 Restore Backup Screen........................72 Figure 44 GVC3200 Diagnosis Screen....................... 73 Figure 45 GVC3200 GS Market..........................75 Figure 46 GVC3200 Web GUI - Login......................... 76 Figure 47 GVC3200 Web UI Tool Bar........................77 Figure 48 GVC3200 Web UI - Call........................
-
Page 9: Change Log
CHANGE LOG GVC3200 user manuals. Only This section documents significant changes from previous versions of major new features or major document updates are listed here. Minor updates for corrections or editing are not documented here. FIRMWARE VERSION 1.0.0.X This is the initial version. Firmware Version 1.0.0.X GVC3200 User Guide Page 8 of 86... -
Page 10: Welcome
Reproduction or transmittal of the entire or any part, in any form or by any means, electronic or print, for any purpose without the express written permission of Grandstream Networks, Inc. is not permitted. FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. - Page 11 Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
-
Page 12: Product Overview
PRODUCT OVERVIEW FEATURE HIGHTLIGHTS Runs Android ™ 4.4 and offers full access to all video conferencing apps in the Google Play Store (such as Skype™, Microsoft Lync™, Google Hangout™, etc.) Proprietary, patent pending embedded MCU supports up to 4-way 1080p Full HD (or 5-way 720p HD, or 9-way VGA) video conferencing, collaborative sharing of computer screen at 1080p resolution, and cross-protocol local conference mixing between SIP and any other Android ™... - Page 13 Remote Control Bluetooth remote control with multi-touch touchpad Auxiliary Ports 1x USB 2.0, SD, external speaker port, reset pin Graphic Display Graphic Display with 128x32 resolution G.711μ/a, G.722 (wide-band), G.726-32, iLBC (pending), Opus, G.722.1, G.722.1c Voice Codecs (pending), in-band and out-of-band DTMF (In audio, RFC2833, SIP INFO) H.264 BP/MP/HP, video resolution up to 1080p, frame rate up to 30 fps, bitrate up to Video Codecs 4Mbps...
-
Page 14: Safety Compliances
universal power supply, network cable (1.5 meters), USB extension cable (5 meters), mounting kit, 3 HDMI cables (two 1.5 meter cables and one 5 meter cable), quick installation guide, brochure, GPL license Temperature and Operation: 0°C to 40°C, Storage: -10°C to 60°C, Humidity: 10% to 90% Non- Humidity condensing FCC: Part 15 (CFR 47) Class B;... -
Page 15: Installing Gvc3200
INSTALLING GVC3200 EQUIPMENT PACKAGE CONTENT The GVC3200 package contains the following items: Table 2 GVC3200 Package List Name Number GVC3200 Main Case External USB Speakerphone Remote Control (No lithium battery) 12V Universal Power Adapter Power Cable 1.5m Ethernet Cable 5m USB Extension Cable 3m HDMI Cable 1.5m HDMI Cable Wall Mount Kit (including top bracket, bottom... -
Page 16: Table 3 Gvc3200 Front Panel
Figure 1 GVC3200 Front Panel Table 3 GVC3200 Front Panel Name Explanation 1/3" 2 Megapixel CMOS 1920Hx1080V@30fps Camera 70°(W)*- 6.3°(T) field of view Vertical Rotating +/-23° tilt Stent Horizontal Rotating +/-90° pan Platform Power on: Green Standby: Flash red LED Indicator Shutdown: Red Pressing any key on the remote control: Green light flashes once OLED Display... -
Page 17: Table 5 Gvc3200 Optional Equipment List
Connect to HDMI input devices. Note: HDMI Input Interface The HDMI input interface has higher priority than the VGA interface when both are connected. Connect to HDMI display devices. There are 3 HDMI output ports. And the interface marked with number "1"... - Page 18 It can be used to help input characters when operating the GVC3200 besides remote control. For example, USB Keyboard Optional typing in username and password to log in Skype app installed on GVC3200. Please connect the GVC3200 according to the following procedures: Connect the primary video output device (e.g., high-definition TV) to HDMI output interface 1 on GVC3200 with HDMI cable.
-
Page 19: Figure 3 Gvc3200 Back Panel Connection Diagram
Figure 3 GVC3200 Back Panel Connection Diagram The following diagram shows multiple GVC3200s deployed with other VoIP/network devices for video conference and collaboration. Figure 4 Deploy Multiple GVC3200s with Other Devices Firmware Version 1.0.0.X GVC3200 User Guide Page 18 of 86... -
Page 20: Getting To Know Gvc3200
GETTING TO KNOW GVC3200 REMOTE CONTROL Figure 5 GVC3200 Remote Control Table 6 GVC3200 Remote Control Keys Icon Name Explanation Input number 1-9 and letters. The letter input using numeric keys will not be displayed as 1, 2, 3, 4… 9 Numeric Keys letter but it can be used to search for contact in Call interface. - Page 21 Access the dial screen by default when GVC is in standby mode. Enter phone number and press the key to dial out. Dial/Add Contact Access the invite screen to add members in a conference. Press the key to bring out the backstage conference. End Call/Remove Party ...
-
Page 22: Using The Remote Control
Zoom In Zoom in screen or adjust close focus. Zoom Out Zoom out screen or adjust distant focus. Slide on the trackpad to move the mouse cursor. Press the trackpad to confirm operations. Trackpad Using two fingers to press on the trackpad and slide up/down for page up/down. -
Page 23: Pairing And Connecting The Remote Control
PAIRING AND CONNECTING THE REMOTE CONTROL If the user happens to factory reset the GVC3200, the remote control will not be paired to the GVC3200 anymore. Or, if in any other instance that the remote control is not paired with the GVC3200 anymore, please follow the steps below to re-pair and connect the remote control to the GVC3200: 1. -
Page 24: Oled Screen
OLED SCREEN Table 7 GVC3200 OLED Screen Status Descriptions OLED Screen Status Descriptions Booting Display "BOOTING..." when the GVC3200 boots up. Display GVC3200 IP address. For example, IP: 192.168.40.5. Display "Ringing", "Calling", "Talking", "Call Waiting", "Missed Call Status Call", "New Voicemail" and etc. ... -
Page 25: Using The Onscreen Keyboard
Icon Descriptions Icon Descriptions Icon Descriptions Missed Call Ongoing call Auto answer is enabled Trying to connect to the Ethernet is connected Ethernet is disconnected Ethernet PPPoE connection is PPPoE is connected PPPoE is disconnected failed VLAN is successfully VLAN is being configured Unread voicemail configured VPN is connected... -
Page 26: Numbers And Symbols
Figure 7 GVC3200 English Input Method - Capslock NUMBERS AND SYMBOLS To input number and symbols, tap on on the default keyboard to switch to numbers/symbols. Tap for more numbers/symbols. Figure 8 GVC3200 Soft Keyboard - Symbols and Numbers Figure 9 GVC3200 Soft Keyboard - More Symbols and Numbers HOME SCREEN GVC3200 Home screen displays the icons for users to easily access applications, camera, schedule, call, contacts, settings and custom applications. -
Page 27: Figure 10 Gvc3200 Home Screen
Figure 10 GVC3200 Home Screen Firmware Version 1.0.0.X GVC3200 User Guide Page 26 of 86... -
Page 28: Connecting To Network And Devices
CONNECTING TO NETWORK AND DEVICES The GVC3200 supports a variety of network connections (Ethernet, Wi-Fi) and device connections, including USB, SD card and Bluetooth device. For first-time users, please connect to USB mouse for configuration on device, or log in the GVC3200 web UI to use the virtual remote configuration. For more information about using... -
Page 29: Turning Wi-Fi On Or Off
Figure 11 GVC3200 Add Wi-Fi Screen TURNING WI-FI ON OR OFF Once Wi-Fi is turned on, GVC3200 will automatically start the scanning within the range. A list of Wi-Fi networks will be displayed as scanning result. Tap on the SSID and enter the correct password information to connect to the selected Wi-Fi network. -
Page 30: Connecting To A Bluetooth Device
Press button on the remote control and select "Search for devices"; The GVC3200 scans and displays the IDs of all available Bluetooth devices in range. Once the Bluetooth device shows up in the result, tap on it to start pairing. Confirm the passkey in the prompted message (if any). -
Page 31: Figure 13 Always Ring Internal Ringer
2. On the LCD display device, go to Settings->Network->Bluetooth. and click "Search for devices". 3. Select 4. On the remote control you would like to pair with the GVC3200, press "OK" and digit 5 keys at the same time for about 5 seconds. 5. -
Page 32: Figure 14 Gvc3200 Add Vpn Files Screen
Figure 14 GVC3200 Add VPN Files Screen Fill in parameters and save, go back to VPN page, you will find the new VPN file you just added; Tap on the VPN file to open the validation page as shown below; Figure 15 GVC3200 VPN Validation Screen Fill in correct username and password to connect to VPN. -
Page 33: Table 10 Gvc3200 Vpn File Parameters
icon displays in the top status bar, please check whether your VPN configuration is correct. Table 10 GVC3200 VPN File Parameters Parameters Descriptions Name Fill in your company address or the server you are connecting to. Set to PPTP, L2TP/IPSec PSK, L2TP/IPSec RSA, IPSec Xauth PSK, IPSeXauth Type RSA or IPSec Hybrid RSA. -
Page 34: Table 13 Gvc3200 802.1X Mode Parameters
Layer 3 QoS for This field defines the layer 3 QoS parameter for audio packets. It is the value used Audio for IP Precedence, Diff-Serv or MPLS. The Default value is 48. Layer 3 QoS for This field defines the layer 3 QoS parameter for video packets. It is the value Video used for IP Precedence, Diff-Serv or MPLS. -
Page 35: Figure 16 Gvc3200 Camera Screen
CAMERA Users could set preset, configure camera parameters, start recording and make screenshots on camera screen. There are 3 ways to access camera screen: Click on icon on home screen. Press key on the remote control. Select on home screen to access Applications. -
Page 36: Figure 17 Gvc3200 Add Preset Screen
Figure 17 GVC3200 Add Preset Screen Select the preset window and press the blue shortcut key on the remote control to access the editing screen. Adjust camera position and zoom in/zoom out using the remote control. On the remote control, press the "OK" key to save the preset, or press Back key to cancel. -
Page 37: Table 14 Gvc3200 Camera Parameters
Figure 18 GVC3200 Camera Parameters Setting Screen Table 14 GVC3200 Camera Parameters Parameters Descriptions The GVC3200 has 4 built-in mode as well as "Manual" for customization. When set to "Manual", press the "OK" key to access each setting to configure sharpness, contrast, saturation and brightness. - Page 38 Blue Shortcut Key Auto focus. (AF) Firmware Version 1.0.0.X GVC3200 User Guide Page 37 of 86...
- Page 39 PERIPHERAL EXTERNAL USB DEVICE The GVC3200 USB interface could be connected to a USB mouse, a USB keyboard, or a USB storage device. USING USB MOUSE/KEYBOARD When a USB mouse is plugged into the GVC3200, users could see the cursor on the screen, move the cursor to perform operations.
- Page 40 MICROPHONE AND SPEAKER GVC3200 is equipped with a built-in microphone; alternatively, you can connect external microphone arrays or other audio devices to the GVC3200 as audio input sources. Before using the GVC3200, connect the required audio input devices to the GVC3200 and set audio input parameters. The GVC3200 supports one speaker output.
-
Page 41: Figure 19 Gvc3200 Sip Account
MAKING PHONE CALLS ACCOUNT The GVC3200 supports up to 9-way video conference, please register the account to the server before making calls. The following figure shows the accounts are successfully registered (account icon is green). This displays on the left side of the top status bar in your LCD display device. Figure 19 GVC3200 SIP Account DIAL SCREEN Once the account is successfully registered, users could use one of the following 3 ways to bring up dial... -
Page 42: Figure 20 Gvc3200 Call Screen
Figure 20 GVC3200 Call Screen Press the red shortcut key on the remote control to bring up call mode setting screen, set call mode to Call, Paging or IP call; Press the yellow shortcut key to set call type to Audio or Video; ... - Page 43 DIALING A NUMBER VIA CALL HISTORY On the LCD display device, access Applications on home screen and access call history by selecting icon The LCD will display all call history types. Navigate in the call history list by selecting the call history category.
-
Page 44: Figure 21 Gvc3200 Multiple Incoming Calls
on the remote control Press to dial out. ANSWERING A CALL SINGLE INCOMING CALL When the device is in idle and there is an incoming video call, the device will show the call screen as below. Select “Video Answer” to answer the call with both video and audio, “Audio Answer” to answer the call with audio only, or "End"...
