Air Conditioner
• Uses ozone layer friendly refrigerant R410A.
• Utiliza refrigerante R410A que no daña la capa
de ozono.
• Utilizza il refrigerante R410A che non danneggia
il buco nell'ozono.
• Usa refrigerante R410A amigo da camada de
ozono.
• Utilise un réfrigérant qui n'attaque pas la couche
d'ozone, le R410A.
INDOOR UNIT
UNIDAD INTERIOR
UNITA' INTERNA
UNIDADE INTERIOR
UNITE INTERIEURE
GS-XP07FR
GS-XP09FR
GS-XP12FR
GS-XP18FR
GS-XP24FR
GS-XP27FR
* Plasmacluster is trademark of SHARP
Corporation.
R
OUTDOOR UNIT
UNIDAD EXTERIOR
UNITA' ESTERNA
UNIDADE EXTERIOR
UNITE EXTERIEURE
AE-X7FR
AE-X9FR
AE-X12FR
GU-XR18FR
GU-XR24FR
GU-XR27FR
GS-XP07FR
GS-XP09FR
GS-XP12FR
GS-XP18FR
GS-XP24FR
GS-XP27FR
FLOOR/CEILING TYPE
ROOM AIR CONDITIONER
OPERATION MANUAL
TIPO DE SUELO/TECHO
ACONDICIONADOR DE AIRE
PARA HABITACIÓN
MANUAL DE INSTRUCCIONES
TIPO DI PAVIMENTO/SOFFITTO
CONDIZIONATORE D'ARIA PER
ABITAZIONI
MANUALE DI ISTRUZIONE
TIPO CHÃO/TECTO
AR CONDICIONADO DE SALA
MANUAL DE INSTRUÇÕES
CLIMATISEUR DOMESTIQUE
DE TYPE AU SOL/PLAFOND
NOTICE D'UTILISATION
Advertisement
Table of Contents
Related Manuals for Sharp AE-X7FR AE-X9FR
Summary of Contents for Sharp AE-X7FR AE-X9FR
- Page 1 INDOOR UNIT OUTDOOR UNIT UNIDAD INTERIOR UNIDAD EXTERIOR NOTICE D'UTILISATION UNITA' INTERNA UNITA' ESTERNA UNIDADE INTERIOR UNIDADE EXTERIOR UNITE INTERIEURE UNITE EXTERIEURE GS-XP07FR AE-X7FR GS-XP09FR AE-X9FR GS-XP12FR AE-X12FR GS-XP18FR GU-XR18FR GS-XP24FR GU-XR24FR GS-XP27FR GU-XR27FR * Plasmacluster is trademark of SHARP Corporation.
- Page 2 If the product is used for business purposes and you want to discard it: Please contact your SHARP dealer who will inform you about the take-back of the product. You might be charged for the costs arising from take-back and recycling.
-
Page 3: Table Of Contents
ENGLISH Thank you for purchasing a SHARP air conditioner. Please read this manual carefully before operating the product. CONTENTS • IMPORTANT SAFETY INSTRUCTIONS ..E-1 • ONE-HOUR OFF TIMER ..... E-11 • ADDITIONAL NOTES ON OPERATION ..... E-3 • TIMER OPERATION ......E-12 •... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTIONS FOR USE Open a window or door periodically to ventilate the room, especially when using gas appliances. Insufficient ventilation may cause oxygen shortage. Do not operate the buttons with wet hand. It may cause electric shock. For safety, turn the circuit breaker off when not using the unit for an extended period of time. -
Page 5: Additional Notes On Operation
ADDITIONAL NOTES ON OPERATION OPERATING TEMPERATURE RANGE INDOOR TEMP. OUTDOOR TEMP. 32˚C D.B. 43˚C D.B. upper limit 23˚C W.B. COOLING 21˚C D.B. 21˚C D.B. lower limit 15˚C W.B. 27˚C D.B. 24˚C D.B. upper limit 18˚C W.B. HEATING 20˚C D.B. -7˚C D.B. lower limit -8˚C W.B. -
Page 6: Part Names
PART NAMES INDOOR UNIT (When installed on the floor) 1 Outlet (Air) 2 Vertical Adjustment Louvres 3 Horizontal Adjustment Louvres 4 Indicator Panel 5 Air Filters 6 Intake Grille 7 Inlet (Air) 8 Remote Control 9 OPERATION Lamp (red 0 TIMER Lamp (orange q PLASMACLUSTER Lamp (blue) w RECEIVER Window... - Page 7 REMOTE CONTROL 1 TRANSMITTER 2 DISPLAY (Liquid Crystal Display) 3 PLASMACLUSTER Button 4 ON/OFF Button 5 THERMOSTAT Button 6 FULL POWER Button 7 MODE Button 8 ONE-HOUR OFF TIMER Button 9 TIMER ON Button (for setting the timer) 0 TIMER OFF Button (for setting the timer) q TIME ADVANCE Button w TIME REVERSE Button e FAN Button...
-
Page 8: Using The Remote Control
USING THE REMOTE CONTROL LOADING BATTERIES Use two size-AAA (R03) batteries. Remove the remote control cover. Remote control cover Insert batteries in the compart- ment, making sure the ± and — polarities are correctly aligned. • The display indicates "AM 6:00"... - Page 9 CAUTION • Do not allow the signal receiver window to receive strong direct sunlight, since it can adversely affect its operation. If the signal receiver window is exposed to direct sunlight, close a curtain to block the light. • Using a fluorescent lamp with a quick starter in the same room may interfere with transmission of the signal.
-
Page 10: Basic Operation
BASIC OPERATION Press the MODE button to select the op- eration mode. AUTO HEAT COOL Press the ON/OFF button to start opera- tion. • The red OPERATION lamp ( ) on the unit will light. Press the THERMOSTAT button to set the desired temperature. - Page 11 TIPS ABOUT AUTO MODE In the AUTO mode, the temperature setting and mode are automatically se- lected according to the room temperature and outdoor temperature when the unit is turned on. Modes and Temperature Settings outdoor (¡C) temp. Cool Cool Cool ( 4¡C) ( 5¡C)
-
Page 12: Adjusting The Air Flow Direction
ADJUSTING THE AIR FLOW DIRECTION VERTICAL AIR FLOW DIRECTION HOW TO ADJUST THE AIR FLOW DIRECTION Press the SWING button on the remote control once. • The vertical adjustment louvre will change its angle continuously. Press the SWING button again when the vertical adjustment louvre is at the desired position. -
Page 13: Full Power Operation
FULL POWER OPERATION In this operation, the air conditioner works at maximum power to makes the room cool or warm so rapidly that you can use it just after you come home. To activate the FULL POWER operation, press the FULL POWER button during operation. -
Page 14: Timer Operation
TIMER OPERATION NOTE: Before setting the timer, make sure the clock is properly set with the current time. TIMER OFF Press the TIMER OFF ( ) button. The TIMER OFF indicator will blink; press the TIME ADVANCE or REVERSE buttons to set the desired time. - Page 15 TIMER ON Press the TIMER ON ( ) button. The TIMER ON indicator will blink; press the TIME ADVANCE or REVERSE buttons to set the de- sired time. (The time can be set in 10-minute increments.) Point the remote control at the signal receiver window on the unit and press the TIMER SET (SET/C) button.
-
Page 16: Tips About Plasmacluster Operation
TIPS ABOUT PLASMACLUSTER OPERATION The Plasmacluster ion generator inside the air conditioner will release positive and negative Plasmacluster ions into the room. Approximately the same numbers of positive and negative ions released into the air will reduce some airborne mold. Plasmacluster ions PLASMACLUSTER OPERATION During operation, press the PLASMACLUSTER... -
Page 17: Auxiliary Mode
AUXILIARY MODE Use this mode when the remote control is not available. TO TURN ON Press the AUX. button using a thin stick on the indicator panel. • The red OPERATION lamp ( ) on the unit will light and the unit will start operating in the AUTO mode. - Page 18 MAINTENANCE CLEANING THE FILTERS The air filters should be cleaned every two weeks. TURN OFF THE UNIT OPEN THE INTAKE GRILLE 1 Slide the stoppers to the left Stopper ( OPEN Two stoppers are provided for each the intake grille. 2 Gently pull and open the intake grille.
-
Page 19: Before Calling For Service
BEFORE CALLING FOR SERVICE The following conditions do not denote equipment malfunctions SWISHING NOISE UNIT DOES NOT OPERATE The soft, swishing noise is the sound of the refrig- The unit will not operate if it is turned on immediately erant flowing inside the unit. after it is turned off. - Page 20 SHARP CORPORATION OSAKA, JAPAN Printed in Thailand TINSEA417JBRZ TH 05D- 1...
