Kidde P4010ACSCO User Manual

Smoke and carbon monoxide alarm
Hide thumbs Also See for P4010ACSCO:
Table of Contents

Advertisement

Quick Links

IntellIgent COMBO
Smoke and Carbon Monoxide Alarm User guide
Combination Photoelectric Smoke & Carbon Monoxide Alarm
with Voice and Hardwire Interconnect
Model P4010ACSCO
AMBIent lIgHt SenSOr
Alarm samples the ambient light conditions of its location
and, if possible, determines a Night / Day cycle to delay chirps
during the night until the next Day cycle begins.
COMBInAtIOn AlArM
HArdwIre InterCOnneCt
10-yeAr BAttery BACkUp
VOICe AlArM
AMBIent lIgHt SenSOr
1

Advertisement

Table of Contents
loading

Related Manuals for Kidde P4010ACSCO

Summary of Contents for Kidde P4010ACSCO

  • Page 1 Smoke and Carbon Monoxide Alarm User guide Combination Photoelectric Smoke & Carbon Monoxide Alarm with Voice and Hardwire Interconnect Model P4010ACSCO AMBIent lIgHt SenSOr Alarm samples the ambient light conditions of its location and, if possible, determines a Night / Day cycle to delay chirps during the night until the next Day cycle begins.
  • Page 2 Thank You for Purchasing this Kidde Alarm Hardwired for 120VAC, this model features a non-replaceable, sealed-in battery backup. It also contains a voice message system and SMART HUSH® Control to temporarily silence nuisance alarms. Teach children how to respond to the alarm and that they should never play with the unit. This alarm is a multi-criteria device designed to detect both smoke and carbon monoxide from any source of combustion in a residential environ- ment.

  • Page 3: Table Of Contents

    Contents 1. Smoke Alarm: What To Do When The Alarm Sounds ... . 4 2. Carbon Monoxide Alarm: What To Do When The Alarm Sounds ..5 3.

  • Page 4: Smoke Alarm: What To Do When The Alarm Sounds

    1. Smoke Alarm: What To Do When the Alarm Sounds Smoke alarm pattern is three long beeps with voice “Fire!,” a 1.5 second pause, and three long beeps repeating. The red LED blinks in time with alarm pattern. The smoke alarm takes precedence when both smoke and carbon monoxide are present. •...

  • Page 5: Carbon Monoxide Alarm: What To Do When The Alarm Sounds

    2. Carbon Monoxide Alarm: What To Do When the Alarm Sounds Carbon monoxide (CO) alarm pattern is four quick beeps with voice “Warning! Carbon Monoxide” repeating every 5 seconds. The red LED blinks in time with alarm pattern. Warning: CarbOn MOnOxiDE aLarM aCTivaTiOn inDiCaTEs ThE prEsEnCE Of CarbOn MOnOxiDE (CO) aT high COnCEnTraTiOns WhiCh Can kiLL yOu.

  • Page 6: Other Alarm Visual And Audible Indicators

    3. Other Alarm Visual and Audible Indicators Operational Mode Visual Indications Audible Indications Action/Note: normal (standby) AC power: Green LED on continuously during light conditions, or blink every 60 sec during dark conditions. DC power: Green LED blink approx every 60 sec. test (button press when •...

  • Page 7: Troubleshooting Guide

    Test/Hush® button is push/released once. Report the number of blinks to customer service if needed. If you require further information please contact Product Support at 1-800-880-6788 or write us at: Kidde, 1016 Corporate Park Drive, Mebane, NC 27302. Our internet address is www.kidde.com.

  • Page 8: Introduction, Product Features & Specifications

    5. Introduction, Product Features and Specifications Introduction This alarm detects products of combustion using photoelectric technology and carbon monoxide using an electro- chemical cell. Many times throughout this User Guide, we will refer to Carbon Monoxide as “CO.” Ten (10) years after the unit was installed, this unit will automatically alert you that it is time to replace the unit. This is called “End of Unit Life”...

  • Page 9: Limitations Of Smoke And Carbon Monoxide Alarms

    6. Limitations of Smoke and Carbon Monoxide Alarms wArnIng: pleASe reAd CAreFUlly And tHOrOUgHly product Features and Specifications: • Life safety from fire in residential occupancies is based primarily on early notification to occupants of the need to escape, followed by the appropriate egress actions by those occupants. •...
  • Page 10 wArnIng: pleASe reAd CAreFUlly And tHOrOUgHly • IMPORTANT: This alarm is designed to detect carbon monoxide gas from ANY source of combustion. It is NOT designed to detect any other gas. CAUtIOn: This alarm will only indicate the presence of carbon monoxide gas at the sensor. Carbon monoxide gas may be present in other areas.

  • Page 11: Recommended Locations For Smoke Alarms

    7. Recommended Locations for Smoke Alarms ANYWHERE ALONG THIS BOLD SURFACE • Locate smoke alarms in all sleeping areas. Try to monitor the exit path as the bedrooms are usually farthest from the exit. If more than one sleeping area exists, locate additional alarms in each sleeping area. Locations permitted for smoke ANYWHERE ALONG alarms and smoke detectors...
  • Page 12 • For mobile home installation, select locations carefully to avoid thermal barriers that may form at the ceiling. For more details, see MOBILE HOME INSTALLATION section. • When mounting an alarm on the ceiling, locate it at a minimum of 4” (10 cm) from the side wall. •...

  • Page 13: Locations To Avoid

    8. Locations to Avoid • In the garage. Products of combustion are present when you start your automobile. • Normal cooking may cause nuisance alarms. If a kitchen alarm is desired, it should have an alarm silence feature or be a photoelectric type. •...

  • Page 14: Wiring / Installation / Activation

    9. Wiring / Installation / Activation wiring requirements • This alarm should be installed on a UL Listed or recognized junction box. All connections should be made by a qualified electrician and all wiring used shall be in accordance with articles 210 and 300.3(B) of the U.S. National Electrical Code ANSI/NFPA 70, NFPA 72 and/or any other codes having jurisdiction in your area.
  • Page 15 • A maximum of 24 Kidde Safety devices may be interconnected in a multiple station arrangement. The intercon- nect system should not exceed the NFPA interconnect limit of 12 smoke alarms and/or 18 alarms total (smoke, CO, Smoke/ CO Combination, heat, etc.). With 18 alarms interconnected, it is still possible to interconnect up to a total of 6 remote signaling devices and /or relay modules (see below for details on interconnecting Kidde devices) •...
  • Page 16 AC connector shipped with product before tightening the screws. Existing Kidde • Plug the AC QUICK CONNECTOR into the wiring harness attached AC Connector (either connector AC connector...
  • Page 17 RF-SM-ACDC, PE120, P12040, Pi2000, Pi2010, KN-COSM-I, KN-COSM-IB, KN-COSM-IBA, KN-COPE-I, KN-COPE-IC, KN-COB-IC, KN-COP-IC, SL177i, SLED177i, HD135F, SM120X, CO120X, i12010S, i12010SCO, P4010ACSCO, P4010ACSCO-W, P4010LACS-W, P4010ACS, P4010ACS-W. The alarm is now activated! After installation / activation, test your alarm as described in Operation and Testing section.

  • Page 18: Operation And Testing

    10. Operation and Testing Operation CO AlArM SenSOr reSpOnSe tIMeS The alarm is operating once it is activated and testing At 70 PPM, the unit must alarm within 60-240 minutes. At 150 PPM, the unit must alarm within 10-50 minutes. is complete (see “TESTING”...

  • Page 19: Recognizing Nuisance Alarms

    Chirping When chirping begins during the next Day cycle, you can temporarily pOSSIBle CHIrpIng reASOnS silence End of Unit Life chirps by pressing the Test/Hush® button. Low Battery chirps cannot be silenced. If a valid Night / Day cycle has not End of Unit Life: will be delayed at night Low battery: will be delayed at night been established because the unit is located in either a constantly dark...

  • Page 20: Battery Backup

    This alarm is designed to minimize nuisance alarms. Cigarette smoke will not normally cause the unit to alarm, unless the smoke is blown directly into the alarm. Combustion particles from cooking may set off the alarm if it is located too close to a cooking appliance.

  • Page 21: Permanently Disable Alarm / Discharge Battery

    13. Permanently Disable Alarm / Discharge Battery wArnIng: FAIlUre tO dISCHArge AlArM BAttery AS InStrUCted prIOr tO dISpOSAl MAy CreAte pOtentIAl FOr lItHIUM BAttery relAted FIre Or HAzArd. wArnIng: dISCHArgIng tHe AlArM BAttery IS perMAnent • Once the alarm battery has been discharged, it cannot be reactivated! •...

  • Page 22: General Carbon Monoxide (Co) Information

    14. General Carbon Monoxide (CO) Information Carbon monoxide (CO) is a colorless, odorless, and tasteless poison gas that can be fatal when inhaled. CO inhibits the blood’s capacity to carry oxygen. possible Sources of CO Inside your home, appliances used for heating and cooking are the most likely sources of CO. Vehicles running in attached garages can also produce dangerous levels of CO.
  • Page 23 HVAC contractors will perform CO inspections. Some contractors may charge for this service. It’s advisable to inquire about any applicable fees prior to having the service performed. Kidde will not pay for, or reimburse the owner or user of this product, for any repair or dispatch calls related to the alarm sounding.

  • Page 24: Cleaning Your Alarm

    15. Cleaning Your Alarm your Alarm Should be Cleaned at least Once a year You can clean the interior of your alarm (sensing chamber) by using compressed air or a vacuum cleaner hose and blow- ing or vacuuming through the openings around the perimeter of the alarm. The outside of the alarm can be wiped with a damp cloth.

  • Page 25: Good Safety Habits

    16. Good Safety Habits develop and practice a plan of escape Prepare and practice a home escape plan twice a year, including drills at night. Know two ways out of every room (door & window) and identify a meeting place outside the home where everyone will gather once they have exited the resi- dence.
  • Page 26 Fire prevention Never smoke in bed, or leave cooking food unattended. Teach children never to play with matches or lighters! Train everyone in the home to recognize the smoke alarm pattern and to leave the home using their escape plan when it’s heard.
  • Page 27 California State Fire Marshal Early warning fire detection is best achieved by the installation of fire detection equipment in all rooms and areas of the household as follows: A smoke alarm installed in each separate sleeping area (in the vicinity, but outside the bedrooms), heat or smoke detectors in the living rooms, dining rooms, bedrooms, kitchens, hallways, attics, furnace rooms, closets, utility and storage rooms, basements and attached garages.

  • Page 28: Service And Warranty

    Kidde warrants that the enclosed alarm will be free from defects in material and workmanship or design under normal use and service for a period of ten years from the date of purchase. The obligation of Kidde under this warranty is limited...
